ACME GLORV FRAMING XP-5000SZF Manuel utilisateur

CONTENTS

1. Safety Instruction ................................................................................................... 2

2. Technical Specification ........................................................................................... 4

3. Control Panel ......................................................................................................... 6

4. Gobo Wheel and Lamp........................................................................................... 7

4.1 Gobo Wheel ..................................................................................................... 7

4.2 Lamp ................................................................................................................ 7

4.3 Change The Lamp............................................................................................. 8

5. How To Set The Unit............................................................................................... 9

5.1 Main Function .................................................................................................. 9

5.2 Home Position Adjustment............................................................................. 18

6. Control By Universal DMX Controller.................................................................... 23

6.1 DMX Connections........................................................................................... 23

6.2 Channel Mode Setting.................................................................................... 24

6.3 Address Setting .............................................................................................. 25

6.4 DMX 512 Configuration .................................................................................. 25

7. Troubleshooting ................................................................................................... 35

8. Fixture Cleaning ................................................................................................... 36

1. Safety Instruction

WARNING

Please keep this User Manual for future consultation. If you sell the unit to another user, be sure

that they also receive this instruction manual.

Important:

Damages caused by the disregard of this user manual are not subject to warranty. The dealer

will not accept liability for any resulting defects or problems.

Unpack and check carefully that there is no transportation damage before using the unit.

The unit is for indoor use only. Use only in a dry location.

Do install and operate by qualified operator.

Do not allow children to operate the fixture.

Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.

The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces.

Be sure that no ventilation slots are blocked; otherwise the unit will be overheated.

Before operating, ensure that the voltage and frequency of power supply matches the power

requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

Maximum ambient temperature TA: 40℃,maximum ambient temperature TA: 0℃.

Don’t connect the device to any dimmer pack.

During initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective, and it will decrease gradually within 15 minutes.

Make sure there are no flammable materials close to the unit while operating to avoid fire

hazard.

Examine the power wires carefully; replace them immediately if there is any damage.

Unit’s surface temperature may reach up to 85℃. Don’t touch the housing bare-handed during

its operation, and allow about 15 minutes for cooling the unit down before replacing bulb or

maintenance as it could be very hot.

Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut

Please read the instruction manual carefully which includes important

information about the installation, usage and maintenance.

off the mains power immediately.

Do not operate in dirty or dusty environment; do clean the fixture regularly.

Do not touch any wire during operation as there might be a hazard of electric shock.

Avoid power wires twist other cables.

The minimum distance between light output and the illuminated surface must be more than 12

meters.

Disconnect mains power before fuse/lamp replacement or servicing.

Replace fuse/lamp only with the same type.

In the event of serious operating problem, stop using the unit immediately.

Never turn on and off the unit time after time.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Do not open the unit as there are no user serviceable parts inside.

Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to

damage or malfunction. Please contact the nearest authorized technical assistance center if

needed.

Disconnect the mains power if the fixture is has not been used for a long time.

Do use the original packing materials before transporting it once again.

To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or

moisture.

Hot lamp explosion hazard. Do not open the unit within 15 minutes after switching off.

Do replace the bulb once it is damaged, deformed or life-expired.

Do not look directly at the light while the bulb is on.

Never touch bulb with bare fingers, as it is very hot after using.

Do not start on the unit without bulb enclosure or when housing is damaged.

Caution:

To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or

moisture.

Hot lamp explosion hazard. Do not open the unit within 15 minutes after switching off.

Do replace the bulb once it is damaged, deformed or life-expired.

Do not look directly at the light while the bulb is on.

Never touch bulb with bare fingers, as it is very hot after using.

Do not start on the unit without bulb enclosure or when housing is damaged.

2. Technical Specification



Power Voltage:

AC 230V, 50/60Hz



Power Consumption:

1790W



Light Source:

Osram HTI 1400W



Color Temperature:

6000K



CRI:

≥90



Zoom Range:

9°~61°



Movement:

Pan: 540°

Tilt: 270°

Pan/Tilt Resolution: 16 bit

Fixation: Pan/Tilt lock



Dimmer/Shutter:

0~100% smooth dimming, various strobe speeds



Color wheel:

6 colors plus open with rainbow effect



Gobo wheel:

1 rotating gobo wheel with 5 gobos plus open



Animation Wheel:

Perfect water wave and flame effects, rotatable and replaceable



Control

DMX Channel: 34/40/25 channels

Control Mode: DMX, Art-Net, RDM

Firmware Upgrade: Update via DMX link



Construction:

Display: LCD display

Battery backup for user operation without connecting to the mains

Data In/Out: 3-pin and 5-pin XLR

Power In/Out: Power Connector in

Protection Rating: IP20



Features:

Motorized focus

CMY color mixing + linear CTO

Excellent color macro effect

4 fast and smooth framing shutters, each shutter blade position and angle can be controlled

individually; Each shutter blade can block out light completely, the framing module can be rotated

at ± 45°

Motorized linear iris

4 facets prism rotating in both directions

Independent frost effect



Dimension/Weight:

454x424x811mm, 40kgs

17.9"x16.7"x31.9"in, 88.2lbs

Photometric Diagram:

Distance(m) 5 10 15 20

9 Lux 55000 13500 6000 3500

61 Lux 1300 360 98 60

Diameter(m) 0.78 1.6 2.14 3.15

Diameter(m) 5.85 11.7 17.6 23.4

61 9

454mm

424mm

811mm

3. Control Panel

1. DISPLAY:

Shows the various menus and the selected functions

BUTTON:

To select the programming functions

To go backward in the selected functions

DOWN

To go forward in the selected functions

ENTER

To confirm the selected functions

2. ETHERNET:

Transfers fixture’s information to a main controller

3. DMX IN:

DMX 512 operation, use 3-pin/5-pin XLR cable to link the unit and DMX controller

4. DMX OUT:

DMX 512 operation, use 3-pin/5-pin XLR cable to link the next units

5. FUSE (T 15A):

Protect the unit from damage of over voltage or short circuit

6. POWER:

Connect to the mains supply

7. BATTERY DISPLAY:

Shows the battery status

8. POWER SWITCH:

Turns On/Off the power

4. Gobo Wheel and Lamp

4.1 Gobo Wheel

Rotation gobo wheel

4.2 Lamp

Osram HTI 1400W

1. Because of its high internal pressure, there might be a risk that the Discharge lamp would

explode during operation. The lamp emits intense UV radiation which is harmful to the eyes and

skin. The high luminance of the arc can cause severe damage to the retina if you take a close

look at the lamp.

2. To protect the lamp, always turn off the lamp first (via control panel or DMX controller) and

let the unit run at least five minutes to cool down before switching off the mains supply. Never

handle the lamp or luminary when it is hot.

3. Do not touch the bulb with bare hands. If this happens, clean the lamp with denatured

alcohol and wipe it with a lint free cloth before installation.

4. The lamp generates UV radiation. Never operate the lamp without appropriate shielding.

5. When ling up, the lamp operates at high pressure and there is a slight risk of arc tube rupture.

The risk increases with age, temperature and improper handling of the lamp. Do not use the lamp

longer than its lifespan.

6. Make sure the lamp is located in the center of the reflector for the best projection.

DANGER!

Install/change the gobo-wheel with the device switched off only.

4.3 Change The Lamp

Loosen the screw at the rear side of the fixture and open the lamp compartment cover.

Remove the old lamp and turn the lamp left in order to take the lamp out, put a new lamp that

must be the same type as the old one. And then place the new lamp into the lamp holder and

turn the lamp right in order to fix. Finally reinstall the lamp compartment cover, fastening it

securely before turning on power.

5. How To Set The Unit

5.1 Main Function

Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until

the required function is shown on the monitor. Select the function by the ENTER button. Use the

UP/DOWN button to choose the submenu, press the ENTER button to store and automatically

return to the last menu. Press the MENU button or let the unit idle one minute to exit menu mode.

The main functions are shown below:
