Zte MF51 Manuel utilisateur

ZTE MF51

Quick Guide

ZTE CORPORATION

NO. 55, Hi-tech Road South, ShenZhen, P.R.China

Postcode: 518057

Tel: +86-755-26779999

URL: http://www.zte.com.cn

E-mail: mobile@zte.com.cn

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by

any means, electronic or mechanical, including photocopying and microfilm, without the prior

written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print

errors or update specifications without prior notice.

Version No. : R1.0

Confidential and Proprietary Information of ZTE CORPORATION 1

Quick Guide

Introduction

ZTE MF51 is a 3G mobile hotspot device, working in GPRS/EDGE/WCDMA/HSPA network. It provides

Internet connection via USB or Wi-Fi to clients, enabling you to communicate anytime and anywhere.

Specification

Data Service HSPA:

DL 14.4 Mbps

UL 5.76 Mbps

WCDMA CS: UL 64 kbps/DL 64kbps

WCDMA PS: UL 384 kbps/DL 384kbps

Interface USB and Wi-Fi

Wi-Fi Standard 802.11b/g/n

Wi-Fi Security WEP/WPA/WPA2

USB Version USB 2.0 HIGH SPEED

USB Interface Type Micro USB

Weight 80 g

Dimensions (W×H×D): 102.5 mm*51 mm*13.5 mm

microSD card Support up to 32 GB microSD card

Battery 1500mAh Li-ion battery

*Standby time 100 hours

*Working time 4 hours

Charge time 3 hours

Operate system Windows 7, Windows Vista, Windows XP (SP2 or later), Mac OS (10.5 or later)

Web Browser IE (7.0 or later), Firefox (3.0 or later), Opera (10.0 or later), Safari (4.0 or later), Chrome

(10.0 or later)

Working temperature -10 ℃~ +60℃

Storage temperature -20 ℃~ +70 ℃

2 Confidential and Proprietary Information of ZTE CORPORATION

Charging temperature 0 ℃~ +40 ℃

Humidity 5%~ 95%

Notes:

microSD is a trademark of SD Card Association.

The device’s standby and working time are only for your reference, and based on ideal working

environment.

Getting to Know Your Device

The following figure shows the appearance of the device. It is only for your reference. The actual device

may be different.

Interface and Buttons

1.WPS This button is used to start Wi-Fi Protected Setup authentication process and

enable/disable the Wi-Fi function.

zHold it for about five seconds to activate the WPS process.

zHold it for about two seconds to enable/disable Wi-Fi function.

2.Charger/USB

port

zCharge your device.

zConnect the client to your device via USB cable.

Confidential and Proprietary Information of ZTE CORPORATION 3

3.Power Hold the Power button to switch on/off the device.

4. Indicators Indicates the status of your device.

Notes:

•Press WPS and Power buttons simultaneously, and hold on about three seconds until all LEDs are off,

then release the buttons, the device will restart automatically and restore to the factory default settings.

Indicators

When the device is powered on, the following icons will light, with the corresponding indications listed in

the table below:

Indicators Status Description

Battery Indication

RED glittering Please charge.

RED bright The voltage of battery is low.

GREEN bright The voltage of battery is high.

Fully charged.

GREEN

glittering

Charging when power on

Power off

Low power mode

LED off

Fully charged when power off without USB cable

No charging or fully charged under low power mode without

USB cable

No battery

Wi-Fi Indication BLUE glittering Wi-Fi is active.

BLUE bright WPS is active.

LED off Wi-Fi is inactive or low power mode.

Network

Indication

BLUE glittering 2G Modem data transferring.

BLUE bright Register on 2G network.

GREEN

glittering 3G Modem data transferring.

GREEN bright Register on 3G network.

LED off ERROR or NO network service or No SIM or low power mode.

Hardware Installation

Inserting SIM Card, Memory Card and Battery

1. Use the thumb catch on the device to open the battery cover.

4 Confidential and Proprietary Information of ZTE CORPORATION

2. Insert SIM Card into the slot.

Warning:

Please power off the device and remove the external power adapter before removing or inserting the

SIM card, if not, the device or SIM card may be damaged.

3. Insert the memory card into the memory card holder.

4. Insert the battery as shown with the contacts located against the gold springs.

Confidential and Proprietary Information of ZTE CORPORATION 5

5. Line the battery cover up correctly and press gently to close the case.

Switching On/Off Your Device

Press and hold the Power button to switch on/off the device.

Notes:

Please install battery before power on.

Charging Your Device

1. Insert the charger lead carefully with the correct orientation to the charger port.

The plug only fits one way. Do not use excessive force to insert the plug.

2. Connect the charger to a mains socket.

3. Disconnect when the battery is fully charged.

6 Confidential and Proprietary Information of ZTE CORPORATION

Working Mode

Your device supports three working modes. For the client, we only use PC or laptop as the example in this

document.

USB Mode: Connect the device to your PC or laptop via the included USB cable, then power on your

device. And the following picture is one application example:

Wi-Fi Mode: Power on directly, and then connect the device to your PC or laptop via Wi-Fi. And the

following picture is one application example:

Mixed Mode: Connect to the device with the above two connection methods.

The following picture is the application example. All of the client devices can surf on the Internet at the

same time.

Confidential and Proprietary Information of ZTE CORPORATION 7

Establish a connection between your device and the client

Via USB Cable

1.Connect your device and the client with the USB cable.

2.Install software.

After the installation, the connection between your device and the client will be established successfully a

moment later.

Via Wi-Fi

1. Power on your device directly. It will take 1~2 minutes to initialize, and then Wi-Fi status icon will

light.

2. If the Wi-Fi status shown is blue twinkling, hold the WPS key for about 2 seconds to enable the Wi-Fi

function.

3. Use your normal Wi-Fi application on the client to search the available wireless network.

Notes: You need to check your Wireless Network Connection. Set the client to obtain an

IP address automatically in the Internet protocol (TCP/IP) properties, and the client will get

an IP address like”192.168.0.101”.

4. Select the SSID of your device, and then click Connect.

8 Confidential and Proprietary Information of ZTE CORPORATION

Notes:

There will be a pop-up window to require the password. Please check the label on the battery

compartment of your device to gain the SSID and preset password information.

5. Wait a moment, the connection between your device and the client will be established successfully.

Access the Internet

1. Switch on the device.

2. Establish a connection between your device and the client.

3. After successfully establishing the connection, access the Internet in the Always On or

Manual mode. The default mode is Always On.

Notes:

You can browse the WebGUI Configuration page and select Settings > 3G Settings > Network Select to

set the WAN connection mode.

Access the WebGUI Configuration Page

1. Make sure the connection between your device and the client is correct.
