X-Vision XP3000B Manuel utilisateur

XP3000B

HD IR Waterproof Fixed IP Camera User’s Manual

Version 3.5.0

Welcome

Thank you for purchasing our IP camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conformto your local electrical safety codes.

The power shall conformto the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC or 24V AC in the IEC60950-1.

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series IP camera should be installed in a cool, dry place away fromdirect sunlight, inflammable,

explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

6. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

iii

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name

Amount

Unit

Quick Start Guide

Table of Contents

1General Introduction ..................................................................................................................1

1.1 Overview ........................................................................................................................1

1.2 Features.........................................................................................................................1

1.3 Specifications ................................................................................................................2

1.3.1 Performance...........................................................................................................2

1.3.2 Factory Default Setup...........................................................................................4

2Structure ....................................................................................................................................11

2.1 Multiple-function Combination Cable ......................................................................11

2.2 Framework and Dimension .......................................................................................12

2.3 Bidirectional talk .........................................................................................................13

2.3.1 Device-end to PC-end ........................................................................................13

2.3.2 PC-end to the device-end..................................................................................13

2.4 Alarm Setup.................................................................................................................13

3Device Installation ....................................................................................................................15

4Quick Configuration Tool.........................................................................................................16

4.1 Overview ......................................................................................................................16

4.2 Operation .....................................................................................................................16

5Web Operation..........................................................................................................................19

5.1 Network Connection...................................................................................................19

5.2 Login and Logout........................................................................................................19

6FAQ ............................................................................................................................................22

Appendix Toxic or Hazardous Materials or Elements ...............................................................23

1General Introduction

1.1 Overview

This series IP camera integrates the traditional camera and network video technology. It adopts audio

and video data collection, transmission together. It can connect to the network directlywithout any

auxiliary device.

This XP3000B uses standard H.264 video compression technology and G.711a audio compression

technology, which maximally guarantee the audio and video quality.

It supports the IR night vision function. In the night environments, the device can use the IR light to

highlight the object which is suitable for the surveillance function in the low illumination environments.

The built-in protection enclosure and waterproof design conforms to the IP 66 level. It has the sound

waterproof function suitable for use in the outdoor environments.

It supports real-time monitor and listening at the same time. It supports analog video output and dual-

way bidirectional talk.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the

network and then use a network client-end. Due to its multiple functions and various uses, the

XP3000B is widely used in many environments such office, bank, road monitor and etc.

1.2 Features

User

Management

Different user rights for each group, one user belongs to one group.

The user right shall not exceed the group right.

Storage

Function

Support centralserver backup function in accordance with your configuration

and setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end

PC.

Support built-in SD card.

Do not support local SD card hot swap storage function. Support short-time

storage when encounter disconnection.

Support network storage function such as FTP.

Alarm

Function

Real-time respond to external on-off alarminput, and video detect as user

pre-defined activation setup and generate corresponding message in screen

and audio prompt(allow user to pre-record audio file)

Real-time video detect: motion detect, camera masking.

Network

Monitor

IPC supports one-channel audio/video data transmit to network terminal and

then decode. Delay is within 270ms (network bandwidth support needed)

Max supports 20 connections.

Adopt the following audio and video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access.

Network

Management

Realize IPC configuration and management via Ethernet.

Support device management via web or client-end.

Power

External power adapter DC12V/AC 24V. You can select according to your

actual environments. Please note system can not support these two types of

power supplying at the same time.

Assistant

Function

Log function

Support system resource information and running status real-time display.

Day/Night mode auto switch.

Built-in IR light. Support IR night vision.

Support picture parameter setup such as electronic shutter and gain setup.

Backlight compensation: screen auto split to realize backlight compensation

to adjust the bright.

Support video watermark function to avoid vicious video modification.

The enclosure conformsto the IP 66 protection. Has the waterproof function.

1.3 Specifications

1.3.1 Performance

Please refer to the following sheet for IPC performance specification.

Model

Parameter

XP3000B Series

System

Main Processor

TIDavinci high performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

SD card status, bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/2.8-inch CMOS

Pixel

2048(H)*1536(V)

Day/Night Mode

Support day/night mode switch and IR-CUT at the same time.

Auto Aperture

DC drive

Gain Control

Fixed/Auto

White Balance

Manual/Auto

Exposure Mode

Auto/Low noise/Low motion blur/Defend flicker /Manual

PAL: It ranges from 1/3 to 1/10000

NTSC: It ranges from1/4 to 1/10000

Video

Compression

Standard

H264/H264B/MJPEG

Video Frame

Rate

PAL:

Main stream（2048*1536@15fps），extra stream,（704*576@15fps）

Main stream（1920*1080@25fps），extra stream（704*576@25fps）

NTSC:

Main stream（2048*1536@15fps），extra stream（704*480@15fps）

Main stream（1920*1080@30fps），extra stream（704*480@30fps）

Video Bit Rate

H264/H264B/MJPEG

Video Flip

Support mirror and flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

PrivacyMask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Channel title, time title, motion detect, camera masking.

Information

Lens

8~16mm @F1.6

Lens Interface

C/CS. Lens is the default accessories

Audio

Audio Input

1-channel，LINE IN

Audio Output

1-channel, 3.5mm JACK SPEAK OUT.

Bidirectional

Talk Input

Reuse the first audio input channel

Audio Bit Rate

16kbps 16BIT

Audio

Compression

Standard

G.711a/G.711u/PCM

Video

Motion Detect

396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The

6th level has the highest sensitivity)

Activation event, alarm device, audio/video storage, image snapshot,

log, email SMTP function and etc.

Alarm Input

2-channelinput，1-channeloutput

Record and

Backup

Record Priority

Manual>External alarm >Video detect>Schedule

Local Storage

Support Micro SD card hot swap

Storage

Management

Support display local storage status

Network

Wire Network

1-channel wire Ethernet port, 10/100 Base-T Ethernet

Network Protocol

Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,

SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,

SNMP.

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc

AUX

Interfac

Video Output

1-channel analog video output，BNC port, 9-pin port connection

Reset

9-pin port connection

IR light

42 LED, IR distance 20 to 30 meters.

70 LED, IR distance 30 to 50 meters.

General Parameter

Power

Support AC24V/DC12V power.

Power

Consumption

For –IR2 device: 8W MAX (10WMAX when ICR switch)

For –IR4 device:10W MAX (12W MAX when ICR switch)

Working

Temperature

-10℃~+60℃

Working

Humidify

10%~90%

Dimensions(mm)

288×118×101

Weight

2468G（Excluding box）

Installation

Support various installation modes（Bracket is optional）

1.3.2 Factory Default Setup

Please refer to the following sheet for factory default setup information.

Setup

Item

Default Setup

XP3000BSeries

Camera

Conditions

Brightness

Contrast

Hue

Saturation

Gain Mode

Auto

Gain Limit

Exposure Mode

Auto

Auto Iris

Scene Mode

Auto

Day/night Mode

Auto

BLC

Off

Mirror

Off

Flip

Off

Video

Video bit stream

Main

Stream

Bit stream

type

General

Encode

mode

H.264

Resolution

1080P（1920*1080）

Frame

Rate

（FPS）

PAL: 25

NTSC:30

Bit Rate

Type

CBR

Recomme

nded Bit

3584-6144 Kb/S

Bit Rate

6144

I Frame

Watermark

Enable

Watermark

character

DigitalCCTV

Sub

Stream

Enable

Bit stream

type

General

Encode

mode

H.264B

Resolution

CIF(352*288/352*240)

Frame

Rate

（FPS）

PAL: 25

NTSC:30

Setup

Item

Default Setup

XP3000BSeries

Bit Rate

Type

CBR

Recomme

nded Bit

192-1024Kb/S

Bit Rate

1024

I Frame

Snapshot

Type

General


Size

1080P（1920*1080）

Quality

Interval

Video Overlay

Privacy

Mask

Disable

Channel

Title

Enable

Time Title

Enable

Path

Snapshot

Path

C:\PictureDownload

Record

Path

C:\RecordDownload

Audio

Main Stream

Enable

Encode

Mode

G.711A

Sub Stream

Enable

Disable

Encode

Mode

G.711A

Network

TCP/IP

Host

Name

IPC

Ethernet

Card

Wire(Default)

Mode

Static

Mac

Address

Device MAC address when it is shipped out of the factory

IP Version

IPV4

IP Address

192.168.1.108

Subnet

Mask

255.255.255.0

Default

Gateway

192.168.1.1

Preferred

DNS

8.8.8.8

Alternate

DNS

8.8.8.8

Table des matières

Autres manuels X-Vision Caméra de sécurité

X-Vision

X-Vision XSD27ZDN2 Manuel utilisateur

X-Vision

X-Vision XSD10Z-2 Manuel utilisateur

X-Vision

X-Vision XIR621 Manuel utilisateur

X-Vision

X-Vision XHC1080S10IRN Manuel utilisateur

X-Vision

X-Vision HD 960H Manuel utilisateur

X-Vision

X-Vision PCC422E Manuel utilisateur

X-Vision

X-Vision XSD27ZS Manuel utilisateur

X-Vision

X-Vision Professional NPR Camera Guide de configuration

X-Vision

X-Vision XC960BN Manuel utilisateur

X-Vision

X-Vision VIS430R Mode d’emploi

X-Vision

X-Vision VIS238D Manuel utilisateur

X-Vision

X-Vision XSD27ZDN Manuel utilisateur

X-Vision

X-Vision XSD27ZIR-2 Manuel utilisateur

X-Vision

X-Vision X100 Series Manuel utilisateur

X-Vision

X-Vision XPS036 Manuel utilisateur

X-Vision

X-Vision XIR501 Manuel utilisateur

X-Vision

X-Vision PC810 Manuel utilisateur

X-Vision

X-Vision VIS200DX-3 Manuel utilisateur

X-Vision

X-Vision VIS249DX Manuel utilisateur

X-Vision

X-Vision VIS338D Manuel utilisateur

X-Vision

X-Vision X100 Series Manuel utilisateur

X-Vision

X-Vision XP1080S20 Manuel utilisateur

X-Vision

X-Vision XIR538 Manuel utilisateur

X-Vision

X-Vision XPD700WIR-2 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
