X-Vision XSD27ZS Manuel utilisateur

High Resoluon 600 TVL

Speed Dome CCTV Camera

27x Opcal Zoom

User Manual

XSD27ZS

Contents

1. OVERVIEW

1.1 BRIEF INTRODUCTION AND APPLICATION .........................................................

1.2 PRODUCT FEATURES ....................................................................................

1.3 TECHNICAL INDICATORS ................................................................................

2. HARDWARE INSTALLATION ...............................................................................

2.1 ADDRESS SETTING .......................................................................................

3. OPERATION INSTRUCTION ................................................................................

3.1 MAPPING TABLE FOR PRESET LOCATION .........................................................

3.2 KEYBOARD OPERATION ...............................................................................

3.2.1 PRESET LOCATION SCAN .....................................................................

3.2.2 AREA SCANNING ...............................................................................

3.2.3 PATTERN SCANNING ..........................................................................

3.3 MENU SET .................................................................................................

3.3.1 BASIC MENU OPERATION ....................................................................

3.3.2 MENU SET ........................................................................................ 13

3.3.3 SYSTEM INFORMATION ......................................................................

3.3.4 CAMERA SETTING ..............................................................................

3.3.5 AUXILIARY SETTING ............................................................................

3.3.6 SCANNING SET .................................................................................. 15

3.3.7 TITLE SET ..........................................................................................

XSD27ZS - Operang Manual

XSD27ZS Operang Manual

Contents

4. TROUBLESHOOTING .......................................................................................

3.3.8 ALARM LINKAGE ............................................................................... 15

3.3.9 DEFAULTED SETTING .........................................................................

XSD27ZS - Operang Manual

4.1 TROUBLESHOOTING TABLE ...................................................................

XSD27ZS Operang Manual

SAFETY CAUTION

WARNING: User shall be reminded to avoid the risk including potenal deaths or severe

injuries.

1. Please refer to the ambient requirement for equipment when installaon; do not install this

equipment in the environment with too much moisture, dust and smoke dust (which may result

in ﬁre or electric shock).

2. In case that this equipment emits abnormal smell or smoke, please immediately stop it, shut

oﬀ the power and contact the supplier (otherwise this equipment may result in ﬁre or electric

shock).

3. During cleaning this equipment do not directly spray water on any part of this equipment

(which may result ﬁre or electric shock).

4. Please do not place this equipment near a heat source (otherwise, a ﬁre risk is potenal).

5. It is forbidden to store, install and use this product in danger areas with inﬂammable or

explosive substances.

NOTICE: Please carefully read the instrucon book before installaon.

1. During transportaon, storage and installaon, heavy load, violent vibraon and immersion

shall be prevented to avoid the damage of the equipment.

2. Before moving or re-installing this equipment, please be sure that the power is shut oﬀ.

3. This equipment shall be installed at the site with good venlaon.

4. In case that this equipment does not work normally, please contact supplier and do not

disassemble or reform this equipment (Xvision will not take any responsibility for the problem

resulted from unapproved reformaon or repair).

5. During cleaning the surfaces of this equipment, do not use chemical cleaning agent which

may result in the deformaon of equipment surface or damage of covering layer.

6. It is important that the dome camera is not le in a posion where the camera is poinng

directly at the sun or other extremely bright light source. This may result in CCD damage and

poor image quality.

XSD27ZS - Operang Manual

1OVERVIEW

As a high-end monitoring product, the integrated smart high-speed dome camera features strong,

stable and reliable funcon, easy operaon and installaon, etc. It has a good cost performance,

and has become the mainstream product in monitoring industry.

This camera has many funcons such as fast trace, 360° unlimited rotaon, 180°automac

overturn, areas can preset locaon scan, paern scan, screen menu, etc.

The remote head is driven by a stable and reliable step motor that has several speeds.

The camera is designed to watch a moving target in a large area and is a performance unit.

Therefore, it is widely used in various areas such as Airports, staons, Supertores, Banks, and

Hospitals.

1.2 PRODUCT FEATURES

Supporng CVBS standard deﬁnion video signal output

Driven by accurate step motor, with stable running and low noise

Up to 255 programmable preset locaons

Several scan modes such as area scan, preset locaon scan, paern scan, etc.

Mul-funcon Chinese-English menu with ﬂexible and easy conﬁguraon

Vercal and automac over turn funcon can realize the connuous watch without

blind area

Telephoto and limit speed funcon provides a clear and stable monitoring picture

Self-adapve baud rate and communicaon protocol

Non-polarity RS485 supports broadcast address and so address

Supporng failure detecon indicaon for RS485 communicaon

IP66 Protecon grade: IP 66

Ultra lowpower consumpon and ultra-strong stability

1.1 BRIEF INTRODUCTION AND APPLICATION

XSD27ZS - Operang Manual

1.3 TECHNICAL INDICATORS

No. ItemTechnical Indicator

1Video standard PAL/NTSC

2 Horizontalrotaon scope360° connuous rotaon

3Vercalrotaon scope0° ～90°automac overturn

4Horizontaloperaon speed 0.1～300°/s

5Vercal operaon speed 0.1～240°/s

6Prese locaon running

speed300°/s

7Preset locaon accuracy ±0.10°

8Preset locaons255

9Menu operaon Supporng mul language(Chinese and English)

10Funcon display

Yes

11 Coordinatedisplay

Yes

12 Communicaon Failure

detecon and indicaon

Yes

(errorindicaons such as baud rate error,address error,

protocol unmatched, etc.)

13 Editablearea to beblocked8 areas

14 Preset locaon scan4(32 preset locaons foreachroune)

15 Rounescan4(leand right boundaries, speedand area namecan beset)

16 Paern scan4(there are no less than200 instrucons foreachroune)

17 Watch locaon funcon

Yes

18 Timing running Supporng 8meintervals

19 Integratedprotocol PELCO-D,PELCO-P,Industrialprotocol, DH-SD1,YAAN

self-adapon

20Communicaon baud rate2400/4800/9600/19200 bps

21 RS485 Supporng non-polarity

22 Telephoto and limit speed Yes

XSD27ZS - Operang Manual

No. ItemTechnical Indicator

23 Power-oﬀ memory Yes

24 Screen freeze Yes

25 Compable camera Automac Idenﬁcaon (LG/SONY/HITACH/CNB/SAMSUNG)

26 Protecon grade IP66

27 Lighning protecon 4000V

28 Working temp -35

°C

～+35

°C

2HARDWARE INSTALLATION

Address Dial Switch: when the so address is closed, the dome address will be

determined by the dial switch.

So Address: Aer the So address opon is opened, the address dial switch will not

work. The default so address will also be closed.

Broadcasng Address: the ﬁxed broadcasng address of dome if 100; no maer how

the dome address is set, key DVR is able to control the dome through 100 addresses.

Address seng

The address of dome can be set in three ways:

XSD27ZS - Operang Manual

XSD27ZS Operang Manual

Address 1 2 345678

1 ON OFF

2 OFF ON

3 ON ON

4 OFF OFF

5 ON OFF

6 OFF ON

7 ON ON

250OFF ON

251 ON ON

252 OFF OFF

253 ON OFF

254 OFF ON

255 ON ON

Comparison list of address dial switch:

OFF OFF OFF OFF OFF OFF OFF OFF

OFF OFF OFF OFF OFF OFF

ON OFF OFF OFF OFF OFF

OFF ON ON ON ON ON

ON ON ON ON ON ON

XSD27ZS - Operang Manual

XSD27ZS Operang Manual

3. OPERATION INSTRUCTION

3.1 MAPPING TABLE FOR PRESET LOCATION

Preset Locaon Funcon

95+CALL Entering themain menu

XXX+PRESET Saving some preseng point

XXX+CALL Calling some preseng point

40+CALL Operang theﬁrst groupof preset locaon scanning

41+CALL Operang thesecond groupof preset locaon scanning

42+CALL Operang thethird groupof preset locaon scanning

43+CALL Operang thefourth groupof preset locaon scanning

44+CALL Seng theleboundary of area scanning 1

45+CALL Seng the right boundary of area scanning 1

46+CALL Seng theleboundary of area scanning 2

47+CALL Seng the right boundary of area scanning 2

48+CALL Seng theleboundary of area scanning 3

49+CALL Seng the right boundary of area scanning 3

50+CALL Seng theleboundary of area scanning 4

51+CALL Seng the right boundary of area scanning 4

52+CALL Operang area scanning 1

53+CALL Operang area scanning 2

54+CALL Operang area scanning 3

55+CALL Operang area scanning 4

56+CALL Starng theseng of paern scan

57+CALL Saving theseng oheﬁrst groupof paern scanning

XSD27ZS - Operang Manual

58+CALL

59+CALL Saving the seng of the third group of paern scanning

60+CALL

61+CALL Operang theﬁrst groupof paern scanning

62+CALL Operang thesecond groupof paern scanning

63+CALL Operang thethird groupof paern scanning

64+CALL Operang thefourth groupof paern scanning

65+CALL Starng 360° connuous rotaon

67+CALL Arming of alarming input1(forthemachines with this

funcon only)

68+CALL Arming of alarming input2(forthemachines with this

funcon only)

69+CALL Disarming of alarming input1(forthemachines with

this funcon only)

70+CALL Disarming of alarming input2(forthemachines with

this funcon only)

71+CALL Starng alarming output (forthemachines with this

funcon only)

72+CALL Closing alarming output (forthemachines with this

funcon only)

75+CALL Starng thedisplay of status column

76+CALL Closing thedisplay of status column

77+CALL Starng vercalﬂip

78+CALL Closing vercalﬂip

79+CALL Starng guarding funcon

80+CALL Closing guarding funcon

81+CALL Starng the privacy shelter grid(forthemachines with

this funcon only)

Saving the seng of the third group of paern

scanning

Saving the seng of the third group of paern

scanning

XSD27ZS - Operang Manual
