Windsor NMWU225H Caractéristiques techniques

MODELS:

NMWU2250H

10066670

NMWC1350N

10066680

Operating instructions (ENG)

Read these instructions before using the machine.

500 PSI - 17 Gallon

86328170-M

06/11/12

2 86328170 DOMINATOR 17 GAL

Warranty Registration

Thank you for purchasing a Windsor product. Warranty registration is quick and easy.

Your registration will allow us to serve you better over the lifetime of the product.

To register your product go to :

www.windsorind.com/WarrantyRegistration.aspx

For customer assistance:

1-800-444-7654

Machine Data Log / Overview

OVERVIEW

The Dominator is an electric powered carpet extractor intended for commercial use. This appliance applies a

cleaning solution to the carpet and then vacuums the soiled water back into the recovery tank.

Model:

Date of Purchase:

Serial Number:

Dealer:

Address:

Phone Number:

Sales Representative:

86328170 DOMINATOR 17 GAL 3

Table of Contents

Machine Data Log / Overview. . . . . . . . . . . . . . . . . .2

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3

How to Use This Manual . . . . . . . . . . . . . . . . . . . . . .4

Safety

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . 5

HAZARD INTENSITY LEVEL . . . . . . . . . . . . . . . . . . 6

Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Grounding Instructions . . . . . . . . . . . . . . . . . . . . . . .8

Operations

Technical Specifications . . . . . . . . . . . . . . . . . . . . . .9

Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Machine Operation . . . . . . . . . . . . . . . . . . . . . . . . .11

Chemicals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Pre-Run Inspection . . . . . . . . . . . . . . . . . . . . . . . . .12

Equipment Set-up . . . . . . . . . . . . . . . . . . . . . . . . . .12

Heater Operation . . . . . . . . . . . . . . . . . . . . . . . . . .12

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Maintenance

Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . .14

Daily/Regular Maintenance. . . . . . . . . . . . . . . . . . .14

Vacuum Motor Replacement . . . . . . . . . . . . . . . . .15

Solution Pump Replacement . . . . . . . . . . . . . . . . . 16

Pressure Regulator . . . . . . . . . . . . . . . . . . . . . . . . .17

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

PARTS

Control Panel with Heat (Dual Vac) . . . . . . . . . . . 20

Control Panel Without Heat (Single Vac) . . . . . . . 22

Electrical with Heat (Dual Vac) . . . . . . . . . . . . . . . 24

Electrical Without Heat (Single Vac) . . . . . . . . . . 26

Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Pump with Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Recovery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Vacuum with Heat (Dual Vac). . . . . . . . . . . . . . . . 42

Vacuum Without Heat (Single Vac) . . . . . . . . . . . 44

Wand / Hoses - Optional. . . . . . . . . . . . . . . . . . . . 46

Wiring with Heat (Dual Vac) . . . . . . . . . . . . . . . . . 48

Wiring - Without Heat (Single Vac) . . . . . . . . . . . . 50

Suggested Spare Parts. . . . . . . . . . . . . . . . . . . . . 52

Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

4 86328170 DOMINATOR 17 GAL

How to Use This Manual

This manual contains the following sections:

• How to Use This Manual

•Safety

• Operations

• Maintenance

•PartsList

The HOW TO USE THIS MANUAL section will tell you

how to find important information for ordering correct

repair parts.

Parts may be ordered from authorized dealers. When

placing an order for parts, the machine model and

machine serial number are important. Refer to the

MACHINE DATA box which is filled out during the

installation of your machine. The MACHINE DATA box

is located on the inside of the front cover of this manual.

The model and serial number of your machine is

located approximately where shown.

Model:

Date of Purchase:

Serial Number:

Dealer:

Address:

Phone Number:

Sales Representative:

Serial Number

Tag

The SAFETY section contains important information

regarding hazardous or unsafe practices of the

machine. Levels of hazards are identified that could

result in product damage, personal injury, or severe

injury resulting in death.

The OPERATIONS section is to familiarize the operator

with the operation and function of the machine.

The MAINTENANCE section contains preventive main-

tenance to keep the machine and its components in

good working condition. They are listed in this general

order:

• Maintenance

•Lubrication

• Vacuum Motor Replacement

• Solution Pump Replacement

• Troubleshooting

The PARTS LIST section contains assembled parts

illustrations and corresponding parts list. The parts lists

include a number of columns of information:

•REF – column refers to the reference number

on the parts illustration.

•PART NO. – column lists the part number for

the part.

•PRV NO. – reference number.

•QTY – column lists the quantity of the part used

in that area of the machine.

•DESCRIPTION – column is a brief description

of the part.

•SERIAL NO. FROM – If this column has an (*)

and a Reference number, see the SERIAL

NUMBERS page in the back of your manual. If

column has two asterisk (**), call manufacturer

for serial number. The serial number indicates

the first machine the part number is applicable

to. The main illustration shows the most current

design of the machine. When a boxed illustra-

tion is shown, it displays the older design.

•NOTES – column for information not noted by

the other columns.

NOTE: If a service or option kit is installed on your

machine, be sure to keep the KIT INSTRUCTIONS

which came with the kit. It contains replacement parts

numbers needed for ordering future parts.

NOTE: The manual part number is located on the

lower left corner of the front cover.

86328170 DOMINATOR 17 GAL 5

Safety

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precaution

must always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.

This machine is for commercial use.

To reduce the risk of fire, electric shock, or injury:

Connect to a properly grounded outlet. See Grounding Instructions.

Do not leave the machine unattended. Unplug machine from outlet when not in use and before mainte-

nance or service.

Use only indoors. Do not use outdoors or expose to rain.

Do not allow machine to be used as a toy. Close attention is necessary when used by or near children.

Use only as described in this manual. Use only manufacturer's recommended components and attach-

ments.

Do not use damaged electrical cord or plug. Follow all instructions in this manual concerning grounding

the machine. If the machine is not working properly, has been dropped, damaged, left outdoors, or

dropped into water, return it to an authorized service center.

Do not pull or carry machine by electrical cord, use as a handle, close a door on cord, or pull cord around

sharp edges or corners.

Do not run machine over cord. Keep cord away from heated surfaces.

Do not unplug machine by pulling on cord. To unplug, grasp the electrical plug, not the electrical cord.

Do not handle the electrical plug or machine with wet hands.

Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce

airflow.

This machine is intended for cleaning carpet only.

Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

This machine is not suitable for picking up health endangering dust.

Turn off all controls before unplugging.

Machine can cause a fire when operating near flammable vapors or materials. Do not operate this

machine near flammable fluids, dust or vapors.

This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops

and offices for more than normal housekeeping purposes.

Maintenance and repairs must be done by qualified personnel.

If foam or liquid comes out of machine, switch off immediately.

SAVE THESE INSTRUCTIONS

6 86328170 DOMINATOR 17 GAL

Safety

The following symbols are used throughout this guide as indicated in their descriptions:

HAZARD INTENSITY LEVEL

There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY.

The level of hazard intensity is determined by the following definitions:

WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.

CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property damage.

FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.

Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper operating

condition. Following is information that signals some potentially dangerous conditions to the operator or the equip-

ment. Read this information carefully. Know when these conditions can exist. Locate all safety devices on the

machine. Please take the necessary steps to train the machine operating personnel.

FOR SAFETY:

DO NOT OPERATE MACHINE:

Unless Trained and Authorized.

Unless Operation Guide is Read and understood.

In Flammable or Explosive areas.

In areas with possible falling objects.

WHEN SERVICING MACHINE:

Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine.

Use only manufacturer approved replacement parts.

86328170 DOMINATOR 17 GAL 7

Safety

Safety Labels

NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels

become illegible, promptly replace them.

WARNING!

FOR YOUR PROTECTION USE A

GROUND FAULT CIRCUIT INTERRUPTER

Label Circuit Interrupter

86200570

PRV # 170-41

For Model 10066670 Only

Label Warning

86244300

PRV # 500955

For Model 10066670 Only

Label Warning

86333370

For Model 10066680 Only

Label Circuit Interrupter

86333380

For Model 10066680 Only

8 86328170 DOMINATOR 17 GAL

Safety

Grounding Instructions

THIS PRODUCT IS FOR COMMERCIAL

USE ONLY.

ELECTRICAL:

In the USA this machine operates on a standard 15

amp 115V, 60 hz, A.C. power circuit. The amp, hertz,

and voltage are listed on the data label found on each

machine. Using voltages above or below those

indicated on the data label will cause serious damage

to the motors.

EXTENSION CORDS:

If an extension cord is used, the wire size must be at

least one size larger than the power cord on the

machine, and must be limited to 50 feet (15.5m) in

length.

GROUNDING INSTRUCTIONS:

This appliance must be grounded. If it should malfunc-

tion or break down, grounding provides a path of least

resistance for electric current to reduce the risk of

electric shock. This appliance is equipped with a cord

having an equipment-grounding conductor and

grounding plug. The plug must be inserted into an

appropriate outlet that is properly installed and

grounded in accordance with all local codes and ordi-

nances.

This appliance is for use on a nominal 120-volt circuit,

and has a grounded plug that looks like the plug in "Fig.

A". A temporary adaptor that looks like the adaptor in

"Fig. C" may be used to connect this plug to a 2-pole

receptacle as shown in "Fig. B", if a properly grounded

outlet is not available. The temporary adaptor should

be used only until a properly grounded outlet (Fig. A)

can be installed by a qualified electrician. The green

colored rigid ear, lug, or wire extending from the

adaptor must be connected to a permanent ground

such as a properly grounded outlet box cover.

Whenever the adaptor is used, it must be held in place

by a metal screw.

Improper connection of the equipment-grounding

conductor can result in a risk of electric shock.

Check with a qualified electrician or service person

if you are in doubt as to whether the outlet is

properly grounded. Do not modify the plug

provided with the appliance - if it will not fit the

outlet, have a proper outlet installed by a qualified

electrician.

86328170 DOMINATOR 17 GAL 9

Operations

Technical Specifications

MODEL ITEM MEASURE

ALL

Electrical 115 Volt, 60 hz, 15A

Solution Pump 500 psi

Solution Capacity 17 Gal

Recovery Capacity 14 Gal

Height 43 inches

Length 32.5 inches

Width 22.5 inches

10066670

Vacuum Motor Dual 2 Stage

Weight- Empty 139 lbs

Weight-Full Solution 282 lbs

Power cord 2 X 25 feet

Heater 1850 watts

10066680

Vacuum Motor Single 3 Stage

Weight- Empty 122 lbs

Weight-Full Solution 265 lbs

Power cord 1 X 40 feet inline GFCI

Height

Length

Width

This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience or knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for thier safety.

10 86328170 DOMINATOR 17 GAL

Operations

Controls

1. Vacuum Accessory Tool Hook-up

2. Solution Pump Switch

3. Vacuum 1 Switch

4. Vacuum 2 Switch (Dual Vac Units Only)

5. Heater Switch with On Light (Units w/Heat Only)

6. Pressure Gauge

123456

7. Adjustable Pressure Relief Valve

8. Heater Temperature Light (Units w/Heat Only)

9. Breaker for Vacuum 2 (Dual Vac Units Only)

10. Breaker for Vacuum 1

11. Solution Accessory Tool Hook-up

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Windsor Machine de plancher

Windsor

Windsor CDT7IA/10080050 Manuel utilisateur

Windsor

Windsor Admiral ADM8 Manuel utilisateur

Windsor

Windsor COMDU Caractéristiques techniques

Windsor

Windsor 10020430 Manuel utilisateur

Windsor

Windsor Chariot 2 iGloss 20 Manuel utilisateur

Windsor

Windsor STORM SP13 Manuel utilisateur

Windsor

Windsor D250(115V) 10070100 Manuel utilisateur

Windsor

Windsor 1.005.293.0 Manuel utilisateur

Windsor

Windsor Commodore 20 Manuel utilisateur

Windsor

Windsor VOYAGER 2 Manuel utilisateur

Windsor

Windsor EPB2 Manuel utilisateur

Windsor

Windsor CLP12 Manuel utilisateur

Windsor

Windsor ADMIRAL ADM8IA - 10080010 Manuel utilisateur

Windsor

Windsor Dominator 17 NMWU2215N Manuel utilisateur

Windsor

Windsor ADMIRAL Admiral 8 Manuel utilisateur

Windsor

Windsor VOYDU1, VOYXDU 10086130 Manuel utilisateur

Windsor

Windsor Dominator 10070090 Manuel utilisateur

Windsor

Windsor Lightning 1500 Manuel utilisateur

Windsor

Windsor Dri-Matic Manuel utilisateur

Windsor

Windsor MB1500 Manuel utilisateur

Windsor

Windsor COMMODORE CMD Manuel utilisateur

Windsor

Windsor MB2000 Caractéristiques techniques

Windsor

Windsor ADMIRAL ADM8IA - 10080010 Caractéristiques techniques

Windsor

Windsor M17XI Manuel utilisateur

Manuels Machine de plancher populaires d'autres marques

Nilfisk-Advance

Nilfisk-Advance Advance SC370 17B Manuel utilisateur

Numatic

Numatic ET 4045 Manuel utilisateur

HAWK ENTERPRISES

HAWK ENTERPRISES HP1513-180BRUTE Manuel utilisateur

Mytee

Mytee 8070 Mytee-Lite Manuel utilisateur

Kärcher

Kärcher B 140 R Manuel utilisateur

Triple S

Triple S Ace 26T1 Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance SW 750 Manuel utilisateur

Tornado

Tornado Marathon 2000 98190 Manuel

Numatic

Numatic TTB 1117/100 Manuel utilisateur

Tennant

Tennant 8210D Manuel utilisateur

Nobles

Nobles Frontier Manuel du produit

lavina

lavina 21-X Manuel utilisateur

KENT

KENT Edge 28B Manuel utilisateur

Tennant

Tennant 215 Manuel du produit

CleanFreak

CleanFreak DURA-18HD Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance Warrior 34RST Guide de l'administrateur

BETCO

BETCO PB24 Manuel utilisateur

IPC

IPC CT51-71 BT Manuel utilisateur
