VEVOR 5609 Manuel utilisateur
Technical Support and E-Warranty Certificate
www.vevor.com/support
SPARE TIRE CARRIER
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
SPARE TIRE CARRIER
5609
- 2 -
1. Important Safety Instructions
Warning - To reduce the risk of injury, user must read
instructions manual carefully.
This symbol, placed before a safety comment, indicates a
kind of precaution, warning, or danger. Ignoring this warning
may lead to an accident. To reduce the risk of injury, fire, or
electrocution, please always follow the recommendation
shown below.
Danger!
Risk of personal injury or environmental damage! Risk of
electric shock! Risk of personal injury by electric shock!
Warning- Be sure to wear ear protectors when using this
product.
Warning- Be sure to wear eye protectors when using this
product.
Warning- Be sure to wear dust masks when using this
product.
Warning- Be sure to wear gloves when using this product.
2.
1) Keep this manual for the safety warnings and precautions. The
manual offers important information on how to assemble, use and
maintain this product.
2) Dress appropriately.Never wear loose fitting clothing or jewelry when
working. And keep long hair, clothing and gloves away from moving parts.
3) Use common sense when working. Stay alert and concentrate when
assembling and using the Trailer Spare Tire Caralcohol.Do not assemble
or use when tired or when under the influence of alcohol, drugs or
medication.
- 3 -
4) While assembling and using the Trailer Spare Tire Carrier, keep work
area clean and well lighted. Keep spectators and children out of the work
area.
5) Do not exceed the 160 Lbs load capacity of Spare Tire Carrier .
6) Check wheels of trailer during the installation of this Spare Tire Carrier.
Make sure trailer is on a flat level solid surface
7) Be aware of the danger of “dynamicloading”.This situation arises
when a load is dropped onto the Spare Tire Carrier, resulting in a
short-term excessive load.
8) Dynamic loading can result in damage andfailure of the Spare Tire
Carrier and/or trailer,and personal injury to people in the area.
9) Periodically check the mounted Spare Tire Carrier to make sure all
hardware is tightly secured. Never use a damaged Spare Tire Carrier.
10) Spare Tire Carrier and spare tire location cannot interfere with normal
operation of the trailer.Carrier location cannot interfere with visibility of
trailer lights or license plate.
11) It is the responsibility of trailer’s owner to make sure the use of this
product conforms with all state rules and regulations.
12) Keep in mind that the warning previously discussed cannot cover all
possible events and circumstances.
3. Product Description
1) Name:SPARE TIRE CARRIER
2) Model:5609
3) G.W.: 0.45kg
4) Applicable for 4 or 5,6 cams
5) Load limit:160lbs
6) Zinc plated
- 4 -
4. Operations
1) Check the size:Put the U bolt through the suitable holes of the
wheel.Base width should be no more than 95mm and minimum not
less than 60mm.
2) Put the brackets into the U bolts,and screw it by bolt and nuts. See
picture below.
- 5 -
3) Screw the bending part one by one and get the suitable position,make
the 2 holes together, and you can lock the bending part hole to
prevent lost.
Attention:
1. Not recommended for heavy tires. By using it, please tighten all
screws, and need help. it’s dangerous for one people to finish the
work.
2. Recommended for use in stable places,if you need to use in moving
places, make sure the base have a suitable base size and make safe.
3. You should prepare the lock youself.
- 6 -
Address：Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The Pavilions
Preston, United Kingdom
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
Made In China
