Tripp Lite OmniSmart OMNI300NAFTA Manuel utilisateur
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: OMNI300NAFTA
OmniSmart Line Interactive UPS System - NAFTA assembled version of OMNISMART300PNP
Highlights
300VA line interactive tower UPS
Maintains 120V nominal output over an input range of 75 to 147V
Workstation optimized features include USB port and single line TEL / DSL
line surge suppression
Input: NEMA 5-15P (120V 15A) / Output: 3 NEMA 5-15R (120V)
$200,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only)
Description
Tripp Lite's OMNI300NAFTA line-interactive UPS system offers voltage regulation, surge suppression and long-lasting battery support for personal
computers, internetworking equipment and other sensitive electronics. Large internal battery supports entry level PC systems for up to 30 min.
during power failures so that connected equipment can be shutdown without data loss. Automatic voltage regulation (AVR) circuits regulate
brownouts as low as 75V and overvoltages as high as 147V to normal 120V levels without consuming battery power. Offers complete desktop
power protection in an attractive black upright tower configuration. Includes 3 battery-supported outlets with full AC surge suppression.
HID-compliant USB port enables optional unattended system shutdown without data loss in case of extended power failure; USB cable included.
HID-compliant USB port also enables direct integration with built-in power management and auto-shutdown features of Windows and MAC OS X.
PowerAlert Software available via free download from www.tripplite.com. Built-in dataline protection jacks offer protection on a single dialup tel/DSL
line. Built-in audible alarm and 4 front panel LEDs indicate line power status, battery power status, battery low/replace status and voltage regulator
operation. 300VA/180W power-handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone
systems, audio/video equipment and home theater systems. Offers 10.5 min. battery runtime with a full load of 300VA/180W and 27 min. with a half
load of 150VA/90W. Supports battery replacement via built-in access panel. $200,000 connected equipment insurance (USA and Canada Only).
Package Includes
OMNI300NAFTA UPS System
USB and telephone interconnection cables
Instruction manual with warranty information
Features
OMNI300NAFTA line-interactive UPS system offers automatic voltage regulation and battery support, plus complete AC and tel/DSL line
surge suppression
Supports entry-level PC systems for up to 30 min. during power failures to enable a safe system shutdown
Supports a full load of 300VA/180W for 10.5 min. and a half load of 150VA/90W for 27 min.
Automatic voltage regulation (AVR) circuits correct brownouts as low as 75V and overvoltages as high as 147V back to normal 120V levels
without consuming battery power
Attractive black tower configuration
Includes 3 battery-supported AC outlets
Built-in HID-compliant USB port and PowerAlert UPS power management software (available via free download at tripplite.com) and cabling
provide monitoring of in-depth site power conditions, full UPS status and fault warnings, and output load level
HID-compliant USB port also enables direct integration with built-in power management and auto-shutdown features of Windows and MAC
OS X
Supports Tripp Lite's WatchDog Service Monitoring/Rebooting Software (part # WATCHDOGSW)
Built-in dataline suppression jacks protect a single dialup tel/DSL line
Built-in audible alarm and 4 front panel LEDs indicate UPS system and line power status
350VA/180W power-handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment
Supports battery replacement via built-in access panel
Compatible with 120V/60Hz applications for USA, Canada, Mexico and more
$200,000 connected equipment insurance (USA and Canada Only)
Specifications
OUTPUT
Output Volt Amp
Capacity (VA)
300
Output Watt Capacity
(watts)
180
Nominal Output
Voltage(s) Supported
115V; 120V
Frequency
compatibility
60 Hz
Output voltage
regulation (line mode)
-18%, +8%
Output voltage
regulation (Battery
mode)
115V (+/- 5%)
Built-in UPS output
receptacles
3 5-15R outlet(s)
Output AC waveform
(AC mode)
Sine wave
Output AC waveform
(battery mode)
PWM sine wave
INPUT
Rated input current (at
maximum load)
2.1A
Nominal Input
Voltage(s) Supported
120V AC
UPS input connection
type
5-15P; Right-Angled
UPS Input cord length
(ft.)
6
UPS Input cord length
(m)
1.8
Recommended
Electrical Service
15A 120V
BATTERY
Full load runtime
(minutes)
10.5 min. (180w)
Half load runtime
(minutes)
27 min. (90w)
DC system voltage
(VDC)
12
Battery recharge rate
(included batteries)
Less than 3.6 hours from 10% to 90%
Replacement battery
cartridge (internal UPS
battery replacement)
RBC51
Battery Access Battery access door
Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 75 to 147
Overvoltage correction Input voltages between 128 and 147 are reduced by 12%
Undervoltage
correction
Input voltages between 93 and 107 are boosted by 14%
Severe undervoltage
correction
Input voltages between 75 and 92 are boosted by 30%
LEDS ALARMS & SWITCHES
LED Indicators 4 LEDs indicate line power, battery power, overload and battery low/replace status
Alarms Audible alarm indicates power-failure and low-battery conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
480
UPS AC suppression
response time
Instantaneous
UPS Dataline
suppression
1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form
factors supported with
included accessories
Tower
Installation form
factors supported with
optional accessories
Wallmount (UPSWM - tower mounting kit)
Primary form factor Tower
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / inches)
8.5 x 5.2 x 7
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / cm)
21.6 x 13.3 x 17.8
UPS / Power Module
weight (lbs)
14
UPS / Power Module
weight (kg)
6.4
UPS Shipping
dimensions (height x
width x depth / inches)
12 x 10 x 8.2
UPS Shipping
dimensions (height x
width x depth / cm)
30.5 x 25.4 x 21
Shipping weight (lbs) 15.4
Shipping weight (kg) 7
UPS housing material PVC
ENVIRONMENTAL
Operating
Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr.
(full load)
99.6
Battery mode BTU / hr.
(full load)
143.6
COMMUNICATIONS
Communications
interface
USB (HID enabled)
PowerAlert software Free download from www.tripplite.com
Communications cable USB cable included
WatchDog
compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 2-4 milliseconds
Low voltage transfer
to battery power
(setpoint)
75
High voltage transfer
to battery power
(setpoint)
147
SPECIAL FEATURES
Cold Start (startup in
battery mode during a
power failure)
Cold-start operation supported
High availability UPS
features
Hot swappable batteries
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B
(EMI); Meets FCC Part 68 / Industrie Canada (telecommunications); ROHS (Restriction of Hazardous Substances)
WARRANTY
Product Warranty
Period (Worldwide)
2-year limited warranty
Connected Equipment
Insurance (U.S.,
Canada & Puerto Rico)
$200,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1
Extended Warranties WEXT3-OMNI 3-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS 1
Extended Warranties WEXT5-OMNI 5-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS 1
Software WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1
Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial
lines
1
Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and
communication lines
1
Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and
communication lines
1
USB Hubs/Accessories U022-010 10-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
Wallmount Bracket UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws,
1 Velcro safety strap)
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3528.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
