Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

DVI over Cat5 Extenders

and Extender/Splitters

Extender Kit Models:

B140-101, B140-1P1-WP-1, B140-101X, B140-1A1-WP

Local Unit Models: B140-002 and B140-004

Remote Unit Models: B140-1P0, B140-1P0-WP-1,

B140-1A0, B140-1A0-WP-1 and B140-110

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Package Contents 2

Product Features 2

Mounting (Optional) 8

Standard Extender Kit Installation 9

Extender Kit with Remote/Repeater Installation 11

(B140-101X and B140-1A1-WP extender kits only)

Standard Extender/Splitter Installation 14

Extender/Splitter with Remote/Repeater Installation 17

(B140-1A0 and B140-1A0-WP-1 remote receiver units only)

Extender/Splitter Daisy-Chain Installation 20

Extender/Splitter Daisy-Chain with Remote/Repeater Installation 22

(B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP

remote receivers only)

Warranty & Warranty Registration 27

201110026-93-3094-EN.indd 1 11/3/2011 11:37:06 AM

Package Contents

Product Features

B140-101

B140-1P1-WP-1

B140-101X

B140-1A1-WP

B140-002

B140-004

B140-1A0

B140-1A0-WP-1

B140-1P0

B140-1P0-WP-1

B140-110

Local Unit (L), Remote Unit

(R), or Both (B) B B B B L L R R R R R

External Power Supplies

(0, 1, or 2) 00121111001

Mounting Hardware X X X X X

Wallplate Screws X X X X

Screwdriver for Equalization

Adjustment X X X X X

DVI Daisy-chain Cable X

All

• SupportDVI-DSingle-Linkvideoresolutionsupto1920x1080(60Hz)

• Plug-and-play;nosoftwareordriversrequired

• Compatiblewithallmajoroperatingsystems

•HDCPcompatible

B140-101

• DVIoverCat5PassiveExtenderKit(Box-style)

• Extenda1024x768(60Hz)signalupto100ft.fromthesource,or

a1920x1080(60Hz)signalupto50ft.fromthesource

• Noexternalpowerrequired

201110026-93-3094-EN.indd 2 11/3/2011 11:37:06 AM

Product Features

B140-1P1-WP-1

• DVIoverCat5PassiveExtenderWallplateKit

• Extenda1024x768(60Hz)signalupto75ft.fromthesource,ora

1920x1080(60Hz)signalupto50ft.fromthesource

• RJ45-stylewallplatesallowfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

• Noexternalpowerrequired

B140-101X

• DVIoverCat5ActiveExtenderKit(Box-style)

• Extenda1024x768(60Hz)signalupto200ft.fromthesource,or

a1920x1080(60Hz)signalupto150ft.fromthesource

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• Includesmountinghardwarethatallowsremoteunittobe

wallmounted, rackmounted or pole mounted

B140-1A1-WP

• DVIoverCat5ActiveExtenderWallplateKit

• Extenda1024x768(60Hz)signalupto200ft.fromthesource,or

a1920x1080(60Hz)signalupto150ft.fromthesource

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• RJ45-stylewallplatesallowfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

201110026-93-3094-EN.indd 3 11/3/2011 11:37:06 AM

Product Features

B140-002

• 2-PortDVIoverCat5Extender/SplitterLocalTransmitterUnit

(Box-style)

• SplitsaDVI-DSingle-Linksignalinto2separatesignals

• Workswithremote/repeaterandreceiverunitstoextendaDVI-D

Single-Linksignalpassedthe16-ft.(5m.)distancelimitation

• Includesmountinghardwarethatallowstheunittobewallmounted,

rackmounted or pole mounted

B140-004

• 4-PortDVIoverCat5Extender/SplitterLocalTransmitterUnit

(Box-style)

• SplitsaDVI-DSingle-Linksignalinto4

• AdditionalDVIportcanbeusedtoconnectalocalmonitororto

daisy-chain additional B140-004 units. Up to 3 B140-004 units

can be daisy-chained together to increase the number of connected

monitors

• Workswithremote/repeaterandreceiverunitstoextendaDVI-D

Single-Linksignalpassedthe16ft.(5m.)distancelimitation

• Includesmountinghardwarethatallowstheunittobewallmounted,

rackmounted or pole mounted

• Upto3B126-004unitscanbemountedinaB132-004-RB

1U rackmount bracket

201110026-93-3094-EN.indd 4 11/3/2011 11:37:06 AM

Product Features

B140-1A0

• DVIoverCat5ActiveExtenderRemoteReceiverUnit(Box-style)

• WorkswithB140-002andB140-004extender/splitterstoextenda

1024x768(60Hz)signalupto200ft.fromthesource,ora

1920x1080(60Hz)signalupto150ft.fromthesource

• Built-inEqualizationcontrolforvideoimageadjustment

• Includesmountinghardwarethatallowstheunittobewallmounted,

rackmounted or pole mounted

B140-1A0-WP-1

• DVIoverCat5ActiveExtenderWallplate

• WorkswithB140-002andB140-004extender/splitterstoextenda

1024x768(60Hz)signalupto200ft.fromthesource,ora

1920x1080(60Hz)signalupto150ft.fromthesource

• Built-inEqualizationcontrolforvideoimageadjustment

• RJ45-stylewallplateallowsfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

B140-1P0

• DVIoverCat5PassiveExtenderRemoteReceiverUnit(Box-style)

• WorkswithB140-002andB140-004extender/splitterstoextenda

1024x768(60Hz)signalupto100ft.fromthesource,ora

1920x1080(60Hz)signalupto50ft.fromthesource

• Built-inDVIcable;separateDVIcablenotrequired

• Noexternalpowerrequired

201110026-93-3094-EN.indd 5 11/3/2011 11:37:06 AM

Product Features

B140-1P0-WP-1

• DVIoverCat5PassiveExtenderWallplate

• WorkswithB140-002andB140-004extender/splitterstoextenda

1024x768(60Hz)signalupto75ft.fromthesource,ora1920x

1080(60Hz)signalupto50ft.fromthesource

• RJ45-stylewallplateallowsfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired.

• Noexternalpowerrequired

B140-110

• DVIoverCat5ExtenderRemote/RepeaterUnit(Box-style)

• ExtendsandexpandsyourTrippLiteDVIoverCat5installation,

allowing you to locate multiple monitors at different points in a chain

of up to 700 ft.

• Extendsa1024x768(60Hz)signalupto175ft.,ora1920x1080

(60Hz)signalupto125ft.fromthelocaltransmitterunittotherst

remote/repeater unit in the installation

• Extendsa1024x768(60Hz)signaluptoanadditional175ft.,or

a1920x1080(60Hz)signaluptoanadditional125ft.fromeach

remote/repeater unit to the next unit in the chain. In a full 4-level

daisychaininstallation,a1024x768(60Hz)signalcanbeextended

upto700ft.,ora1920x1080(60Hz)signalupto500ft.fromthe

source to the last remote unit in the chain.

• Connectupto4remoteunits(3remote/repeatersand1receiver),

with a monitor located at each point in the chain

• Built-inEqualizationcontrolforvideoimageadjustment

• Includesmountinghardwarethatallowstheunittobewallmounted,

rackmounted or pole mounted

201110026-93-3094-EN.indd 6 11/3/2011 11:37:06 AM

Product Features

Optional Accessories:

• B132-004-RB1URackmountBracket

• N202-SeriesCat624AWG,solidwirepatchcables

• P561-SeriesDVI-DSingle-Linkcables

201110026-93-3094-EN.indd 7 11/3/2011 11:37:06 AM

Mounting (Optional)

The B140-101X, B140-002, B140-004, B140-1A0 and B140-110

come with mounting hardware that allows them to be mounted in

a variety of ways. The following images show the different ways the

included mounting brackets can be attached for different mounting

methods. Note: The B140-004 can also be mounted to a Tripp Lite

B132-004-RB 1U Rackmount Bracket. Up to 3 B140-004 local units

can be connected to a B132-004-RB.

Wallmount

19” Rackmount Pole Mount

201110026-93-3094-EN.indd 8 11/3/2011 11:37:08 AM

TO DVI SOURCE

RJ45 JACK

Cat5/5e/6

PATCH CABLE

LOCAL UNIT

POWER

JACK

REMOTE UNIT

TO DVI MONITOR

B140-101 — Up to 100 ft. at 1024 x 768 (60 Hz), or up to 50 ft. at 1920 x 1080 (60 Hz)

B140-1P1-WP-1 — Up to 75 ft. at 1024 x 768 (60 Hz), or up to 50 ft. at 1920 x 1080 (60 Hz)

B140-101X and B140-1A1-WP — Up to 200 ft. at 1024 x 768 (60 Hz), or up to 150 ft. at 1920 x 1080 (60 Hz)

Standard Extender Kit Installation

(B140-101, B140-1P1-WP-1, B140-101X, B140-1A1-WP)

Notes:

1. The diagram below shows a B140-101X installation. Installation will

be the same for the B140-1A1-WP. Installation will be similar for the

B140-101 and B140-1P1-WP-1, except that they will not require

external power.

2. Test to make sure that the entire installation works properly before

pulling cables through ceilings/walls.

3. To achieve maximum distance and performance, use 24 AWG Solid

Wire Cat5e/6 cable. Using stranded wire cable, or cable with a gauge

(AWG) size higher than 24 AWG, will result in lesser performance

and shorter extension distance. Tripp Lite N202-Series (Cat6) patch

cables are made with 24 AWG Solid Wire cabling.

1Make sure power to the DVI source is turned off.

2Connect the built-in DVI connector on the B140-101 or B140-101X

local unit to the DVI source, or connect the B140-1A1-WP or

B140-1P1-WP-1 local unit to the source using a Tripp Lite

P561-SeriesDVIcable.

201110026-93-3094-EN.indd 9 11/3/2011 11:37:08 AM

Standard Extender Kit Installation

3B140-1A1-WP only: Connect the external power supply to the local

unit and plug it into a Trip Lite Surge Suppressor, Power Distribution

Unit(PDU),orUninterruptablePowerSupply(UPS).TheGreen

Power LED will illuminate.

4ConnecttheRJ45portsonthelocalandremoteunitsusing

Cat5e/6cable.

5Connect the built-in DVI connector on the B140-101 remote unit to

the DVI monitor, or connect the B140-1A1-WP, B140-1P1-WP-1 or

B140-101X remote unit to the monitor using a Tripp Lite

P561-SeriesDVIcable.

6B140-1A1-WP and B140-101X only: Connect the external

power supply to the remote unit and plug it into a Tripp Lite Surge

Suppressor, Power Distribution Unit (PDU) or Uninterruptible Power

Supply(UPS).TheGreenRJ45LEDontheB140-101Xremoteunit

willilluminatetoindicateitisreceivingpower.TheGreenPowerLED

will illuminate on the B140-1A1-WP remote unit.

7TurnonthepowertotheDVIsource.TheGreenRJ45LEDswill

illuminate on the B140-101 and B140-101X units, and the Power

LEDs will illuminate on the B140-1P1-WP-1 units to indicate that

theyarereceivingpower.TheOrangeRJ45LEDwillilluminateonthe

B140-101X remote unit to indicate it is receiving a signal from the

source. The Orange Activity LEDs will illuminate on the

B140-1A1-WP units.

8B140-1A1-WP and B140-101X only: If necessary, adjust the

Equalization control on the remote unit to improve the video image.

Note: An improper Equalization setting can cause the monitor not

to display a picture at all. Try each Equalization setting until an

acceptable image is displayed.

201110026-93-3094-EN.indd 10 11/3/2011 11:37:09 AM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tripp Lite Extenseur

Tripp Lite

Tripp Lite B130-101-2: B130-101A-2 Manuel utilisateur

Tripp Lite

Tripp Lite B136-100 Manuel utilisateur

Tripp Lite

Tripp Lite BHDBT-K-SI Manuel utilisateur

Tripp Lite

Tripp Lite B202-150 Manuel utilisateur

Tripp Lite

Tripp Lite B127-008-D Manuel utilisateur

Tripp Lite

Tripp Lite B136-004 Manuel utilisateur

Tripp Lite

Tripp Lite 0DT23008 Manuel utilisateur

Tripp Lite

Tripp Lite P166-001-A Manuel utilisateur

Tripp Lite

Tripp Lite B150-1A1-DVI Manuel utilisateur

Tripp Lite

Tripp Lite B125-101-60-WP Manuel utilisateur

Tripp Lite

Tripp Lite B127F-1A1-MM-HH Manuel utilisateur

Tripp Lite

Tripp Lite B127M-101-H Manuel utilisateur

Tripp Lite

Tripp Lite B136-101-WP-1 Manuel utilisateur

Tripp Lite

Tripp Lite B127A-1A1-FHFH Manuel utilisateur

Tripp Lite

Tripp Lite HDMI B122-000-60 Manuel utilisateur

Tripp Lite

Tripp Lite U007-40M Manuel utilisateur

Tripp Lite

Tripp Lite P167-000 Manuel utilisateur

Tripp Lite

Tripp Lite BHDBT-K-E3SI-ER Manuel utilisateur

Tripp Lite

Tripp Lite B118-2X4-4K-A Manuel utilisateur

Tripp Lite

Tripp Lite B126-2A1 Manuel utilisateur

Tripp Lite

Tripp Lite NPOE-EXT-1G30WP Manuel utilisateur

Tripp Lite

Tripp Lite B127E-1A1-HH Manuel utilisateur

Tripp Lite

Tripp Lite B136-100-WP-1 Manuel utilisateur

Tripp Lite

Tripp Lite B164-101-WIR Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
