Tripp Lite B126-1A1-WP Manuel utilisateur

Owner’s Manual

HDMI over Cat5 Extenders

and Extender/Splitters

Extender Kit Models: B126-1A1 and B126-1A1-WP

Local Unit Models: B126-002 and B126-004

Remote Unit Models: B126-1P0, B126-1P0-MINI,

B126-1P0-WP-1, B126-1A0, B126-1A0-WP-1 and B126-110

Package Contents 2

Product Features 2

Mounting Instructions 7

Standard Extender Kit Installation 8

Extender Kit with 10

Remote/Repeater Installation

Standard Extender/Splitter 13

Installation

Extender/Splitter with 16

Remote/Repeater Installation

Extender/Splitter Daisy-Chain 20

Installation (B126-004 only)

Extender/Splitter Daisy-Chain with 23

Remote/Repeater Installation

(B126-004 only)

Warranty and Product Registration

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

16-08-518-933023-EN.indd 1 9/8/2016 2:11:15 PM

Package Contents

Product Features

B126-1A1

B126-1A1-WP

B126-002

B126-004

B126-1A0

B126-1A0-WP-1

B126-1P0

B126-1P0-MINI

B126-1P0-WP-1

B126-110

Local Unit (L), Remote Unit (R),

or Both (B) B B L L R R R R R R

External Power Supplies

(0, 1, or 2) 2211110001

Mounting Hardware X X X X X

Wallplate Screws X X X

Screwdriver for

Equalization Adjustment X X X X X

HDMI Daisy-chain Cable X

All

• Support a maximum video resolution of 1080p (60Hz)

• Plug-and-play; no software or drivers required

• Support up to 7.1 channel surround sound audio

• HDCP and 3D compatible

16-08-518-933023-EN.indd 2 9/8/2016 2:11:15 PM

Product Features

B126-1A1

• HDMI over Cat5 Active Extender Kit (Box-style)

• Extends a 1080i (60Hz) signal up to 200 ft. from the source, or a 1080p

(60Hz) signal up to 150 ft. from the source

• Features an additional HDMI port on the local transmitter unit for the

connection of local monitor

• Remote receiver unit features a built-in Equalization control for video

image adjustment

• Includes mounting hardware that allows both the local transmitter

and remote receiver units to be wall-mounted, rack mounted or

pole mounted

B126-1A1-WP

• HDMI over Cat5 Active Extender Wallplate Kit

• Extends a 1080i (60Hz) signal up to 200 ft. from the source, or a 1080p

(60Hz) signal up to 150 ft. from the source

• Remote receiver unit features a built-in Equalization control for video

image adjustment

• RJ45-style wallplates allow for the use of standard Cat5e/6 patch cables;

110 punchdown connection not required

B126-002

• 2-Port HDMI over Cat5 Extender/Splitter Local Transmitter Unit (Box-style)

• Splits an HDMI signal into two

• Works with remote/repeater and receiver units to extend an HDMI signal

past the 16 ft. (5 m) distance limitation

• Includes mounting hardware that allows unit to be wall-mounted,

rack mounted or pole mounted

16-08-518-933023-EN.indd 3 9/8/2016 2:11:16 PM

Product Features

B126-004

• 4-Port HDMI over Cat5 Extender/Splitter Local Transmitter Unit (Box-style)

• Splits an HDMI signal into four

• Features an additional HDMI port, which can be used to connect a local

monitor or to daisy-chain additional B126-004 units (up to three units

can be daisy-chained together).

• Works with remote/repeater and receiver units to extend an HDMI signal

past the 16 ft. (5 m) distance limitation

• Includes mounting hardware that allows unit to be wall-mounted,

rack mounted or pole mounted.

• Up to three B126-004 units can be mounted in a B132-004-RB 1U

rackmount bracket

B126-1A0

• HDMI over Cat5 Active Extender Remote Receiver Unit (Box-style)

• Works with B126-002 and B126-004 extender/splitters to extend a

1080i (60Hz) signal up to 200 ft. from the source, or a 1080p (60Hz)

signal up to 150 ft. from the source

• Features built-in Equalization control for video image adjustment

• Includes mounting hardware that allows the unit to be wall-mounted,

rack mounted or pole mounted

B126-1A0-WP-1

• HDMI over Cat5 Active Extender Wallplate

• Works with B126-002 and B126-004 extender/splitters to extend a

1080i (60Hz) signal up to 200 ft. from the source, or a 1080p (60Hz)

signal up to 150 ft. from the source

• Features built-in Equalization control for video image adjustment

• RJ45-style wallplate allows for the use of standard Cat5e/6 patch cables;

110 punchdown connection not required

16-08-518-933023-EN.indd 4 9/8/2016 2:11:16 PM

Product Features

B126-1P0

• HDMI over Cat5 Passive Extender Remote Receiver Unit (Box-style)

• Works with B126-002 and B126-004 extender/splitters to extend a

1080i (60Hz) signal up to 100 ft. from the source, or a 1080p (60Hz)

signal up to 50 ft. from the source

• Features a built-in HDMI cable; separate cable not required

• No external power required

B126-1P0-MINI

• HDMI over Cat5 Passive Extender Remote Receiver Unit (Compact)

• Works with B126-002 and B126-004 extender/splitters to extend a

1080i (60Hz) signal up to 100 ft. from the source, or a 1080p (60Hz)

signal up to 50 ft. from the source

• Low proﬁle and compact design allows for discreet placement

• No external power required

B126-1P0-WP-1

• HDMI over Cat5 Passive Extender Wallplate

• Works with B126-002 and B126-004 extender/splitters to extend a

1080i (60Hz) signal up to 100 ft. from the source, or a 1080p (60Hz)

signal up to 50 ft. from the source

• RJ45-style wallplate allows for the use of standard Cat5e/6 patch cables;

110 punchdown connection not required

• No external power required

16-08-518-933023-EN.indd 5 9/8/2016 2:11:16 PM

Product Features

B126-110

• HDMI over Cat5 Active Extender Remote/Repeater Unit (Box-style)

• Extends and expands an HDMI over Cat5 installation, allowing multiple

monitors to be located at different points in a chain of up to 700 ft.

• Extends a 1080i (60Hz) signal up to 175 ft., or a 1080p (60Hz) signal up

to 125 ft. from the local transmitter unit to the ﬁrst remote/repeater unit

in the installation

• Extends a 1080i (60Hz) signal up to an additional 175 ft., or a 1080p

(60Hz) signal up to an additional 125 ft. from each remote/repeater unit

to the next unit in the chain (in a full four-level daisychain installation, a

1080i (60Hz) signal can be extended up to 700 ft., or a 1080p (60Hz)

signal up to 500 ft. from the source to the last remote unit in the chain)

• Connect up to four remote units (three remote/repeaters and one

receiver), with a monitor located at each point in the chain

• Features built-in Equalization control for video image adjustment

• Includes mounting hardware that allows the unit to be wall-mounted,

rack mounted or pole mounted

Optional Accessories:

• B132-004-RB 1U Rackmount Bracket

• N202-Series Cat6 24 AWG Solid Wire Patch Cables

• P568-Series High-Speed HDMI cables

16-08-518-933023-EN.indd 6 9/8/2016 2:11:16 PM

Mounting Instructions (select models only)

The B126-002, B126-004, B126-1A1, B126-1A0 and B126-110 include

mounting hardware that allows for a variety of mounting methods. The

following images illustrate how the included mounting brackets can be

attached for different installations.

Note: The B126-004 can also be mounted to a Tripp Lite B132-004-RB 1U

Rack-Mount Bracket. Up to three B126-004 local units can be connected to a

B132-004-RB.

Wall Mount

19” Rack Mount Pole Mount

16-08-518-933023-EN.indd 7 9/8/2016 2:11:19 PM

OPTIONAL LOCAL

MONITOR

LOCAL

TRANSMITTER

REMOTE

RECEIVER

Up to 200 ft. at 1080i (60Hz)

Up to 150 ft. at 1080p (60Hz)

BLU-RAY

Standard Extender Kit Installation

Notes:

1) Test to ensure the entire installation works properly before pulling cables through

ceilings/walls.

2) To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6

cable. Using stranded wire Cat5e/6 cable, or cable with a gauge (AWG) size higher

than 24 AWG, will result in shorter extension distance. Higher gauge cabling, such

as 26 AWG, has a more limited transmission capability than lower gauge cabling.

All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling.

3) The B126-1A1 and B126-1A1-WP are set to transmit a stereo audio signal by

default. Press the Audio button on the local unit to switch to 7.1-channel surround-

sound audio.

4) The installation diagram shows a B126-1A1 unit. The B126-1A1-WP installation is

the same, except there is no local monitor port.

16-08-518-933023-EN.indd 8 9/8/2016 2:11:21 PM

Standard Extender Kit Installation

1Make sure the HDMI source is powered OFF.

2Connect the HDMI source to the INPUT port on the B126-1A1 or B126-

1A1-WP local unit using a Tripp Lite P568-Series HDMI Cable.

3Optional for B126-1A1: Connect a local monitor to the LOCAL port on

the B126-1A1 local unit using a Tripp Lite P568-Series HDMI Cable.

4Connect the external power supply to the local unit and plug it

into a Tripp Lite Surge Protector, Power Distribution Unit (PDU) or

Uninterruptible Power Supply (UPS). The green LED illuminates to

indicate the unit is receiving power from the external power supply.

5Using Cat5e/6 cable, connect the RJ45 port on the local unit to the

RJ45 port on the remote unit.

6Connect the external power supply to the remote unit and plug it into

a Tripp Lite Surge Protector, PDU or UPS. The green LED illuminates to

indicate the unit is receiving power from the external power supply. The

orange LED illuminates to indicate the unit is connected to a powered

ON local unit.

7Connect the remote unit’s HDMI port to a monitor using a Tripp Lite

P568-Series HDMI Cable.

8Turn on the power to the HDMI source. The orange LED on the local unit

illuminates to indicate a signal is being received from the source.

9If necessary, use the Equalization control on the remote unit to adjust

the video image.

Note: An improper Equalization setting can cause the monitor not to display a

picture at all. Try each Equalization setting until an acceptable picture is displayed.

16-08-518-933023-EN.indd 9 9/8/2016 2:11:21 PM

OPTIONAL LOCAL

MONITOR

B126-1A1 LOCAL

TRANSMITTER

B126-1A1 REMOTE

RECEIVER

B126-110 REMOTE

REPEATER

B126-110 REMOTE

REPEATER

B126-110 REMOTE

REPEATER

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

BLU-RAY

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

Extender Kit with Remote/Repeater Installation

Notes:

1) Test to ensure the entire installation works properly before pulling cables through

ceilings/walls.

2) To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6

cable. Using stranded wire Cat5e/6 cable, or cable with a gauge (AWG) size higher

than 24 AWG, will result in shorter extension distance. Higher gauge cabling, such

as 26 AWG, has a more limited transmission capability than lower gauge cabling.

All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling.

3) The B126-1A1 and B126-1A1-WP are set to transmit a stereo audio signal by

default. Press the Audio button on the local unit to switch to 7.1-channel surround-

sound audio.

4) The installation diagram shows a B126-1A1 unit. The B126-1A1-WP installation is

the same, except there is no local monitor port.

1Make sure the HDMI source is powered OFF.

2Connect the HDMI source to the INPUT port on the B126-1A1 or

B126-1A1-WP using a Tripp Lite P568-Series HDMI Cable.

3Optional for B126-1A1: Connect a local monitor to the LOCAL HDMI

port using a Tripp Lite P568-Series HDMI Cable.

16-08-518-933023-EN.indd 10 9/8/2016 2:11:22 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tripp Lite Extenseur

Tripp Lite

Tripp Lite B130-202 Manuel utilisateur

Tripp Lite

Tripp Lite : B140-002 Manuel utilisateur

Tripp Lite

Tripp Lite B120-000-SL Manuel utilisateur

Tripp Lite

Tripp Lite B127U-111-PDPD Manuel utilisateur

Tripp Lite

Tripp Lite B165-101 Manuel utilisateur

Tripp Lite

Tripp Lite 166-001-A Manuel utilisateur

Tripp Lite

Tripp Lite B127F-1A1-MM-HH Manuel utilisateur

Tripp Lite

Tripp Lite B125-150 Manuel utilisateur

Tripp Lite

Tripp Lite B136-100-WP-1 Manuel utilisateur

Tripp Lite

Tripp Lite B140-101X-U Manuel utilisateur

Tripp Lite

Tripp Lite B126-1P0-MINI Manuel utilisateur

Tripp Lite

Tripp Lite B127-1A1-DH Manuel utilisateur

Tripp Lite

Tripp Lite 0DT23001 Manuel utilisateur

Tripp Lite

Tripp Lite B136-101 Manuel utilisateur

Tripp Lite

Tripp Lite B132-100A Manuel utilisateur

Tripp Lite

Tripp Lite B127U-111-PHPH Manuel utilisateur

Tripp Lite

Tripp Lite B127A-1A1-BCBH Manuel utilisateur

Tripp Lite

Tripp Lite B125-150 Manuel utilisateur

Tripp Lite

Tripp Lite P167-000 Manuel utilisateur

Tripp Lite

Tripp Lite B150-1A1-HDMI Manuel utilisateur

Tripp Lite

Tripp Lite B132-004A Manuel utilisateur

Tripp Lite

Tripp Lite B013-330 Manuel utilisateur

Tripp Lite

Tripp Lite B136-100 Manuel utilisateur

Tripp Lite

Tripp Lite B126-1A1-WHD4HH Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
