Owner’s Manual

VGA Over Cat5 Extenders

and Extender/Splitters

Extender Kit Models: B130-101-2, B130-101A-2,

B130-101-WP-1, B130-101A-WP-2, B130-101S-2,

B130-111, B130-111A and B130-101-U

Transmitter Unit Models: B132-002-2,

B132-002A-2, B132-004-2, B132-004A-2 and

B132-008A-2

Receiver Unit and Remote Repeater Models:

B132-100-1, B132-100A, B132-100-WP-1,

B132-100A-WP-1, B132-110 and B132-110A

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

All trademarks are the sole property of their respective owners.

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

15-08-104-933289-EN.indd 1 8/21/2015 3:45:46 PM

Table of Contents

Package Contents 3

Product Features 4

All 4

B130-101-2 4

B130-101A-2 4

B130-101-WP-1 4

B130-101A-WP-2 5

B130-101S-2 5

B130-111 5

B130-111A 6

B130-101-U 6

B132-002-2 7

B132-002A-2 7

B132-004-2 7

B132-004A-2 8

B132-008A-2 8

B132-100-1 9

B132-100A 9

B132-100-WP-1 9

B132-100A-WP-1 9

B132-110 9

B132-110A 10

Optional Accessories 10

Mounting Hardware 11

Instructions

Installation 12

EDID Copy 12

Extender Kit Installation 14

Non-Kit Standard Installation 17

Non-Kit Daisy Chain Installation 19

Extender/Repeater Kit 21

Installation

Non-Kit Remote Repeater 24

Installation

Non-Kit Daisy Chain Remote 27

Repeater Installation

Troubleshooting 31

Warranty and Product 34

Registration

Additional Warnings and 35

Notices

15-08-104-933289-EN.indd 2 8/21/2015 3:45:46 PM

Package Contents

B130-101-2

B130-101A-2

B130-101-WP-1

B130-101A-WP-2

B130-101S-2

B130-111

B130-111A

B130-101-U

B132-002-2

B132-002A-2

B132-004-2

B132-004A-2

B132-008A-2

B132-100-1

B132-100A

B132-100-WP-1

B132-100A-WP-1

B132-110

B132-110A

Local Unit (L), Remote

Unit (R) or Both (B) B B B B B B B B L L L L L R R R R R R

1 or 2 External

Power Supplies

(Input: 100-240 V,

50/60 Hz, 0.5 A

Output: 5 V, 2 A)

22222220 11111111111

Mounting Hardware X X X X X X X X X X X X X X

Wallplate Screws X X X X

Screwdriver X X X X X X X X X X X X X X

3.5 mm Male to DB9

Male Adapter Cable X

3.5 mm Male to DB9

Female Adapter Cable X

1 ft. VGA Splitter Cable X

1 ft. VGA + Audio

Splitter Cable X

1 ft. VGA Daisy Chain

Cable X

1 ft. VGA + Audio

Daisy Chain Cable X X

15-08-104-933289-EN.indd 3 8/21/2015 3:45:46 PM

Product Features

All

• Support a maximum resolution of 1920 x 1440 @ 60 Hz.

• All operating systems supported.

• Plug and play; no software or drivers required.

• HDCP compliant.

B130-101-2

• Extends a VGA video signal (1024 x 768 @ 60 Hz) up to 1,000 ft. from

the source.

• Features an additional VGA port, allowing for the connection of a local

monitor.

• Includes mounting hardware that allows units to be wall-mounted, rack

mounted or pole mounted.

• Features built-in equalization and gain controls to adjust the video image.

• EDID copy feature ensures optimal display compatibility.

B130-101A-2

• Extends both a VGA video (1024 x 768 @ 60 Hz) and an audio signal

up to 1,000 ft. from the source.

• Features additional VGA and 3.5mm ports, allowing for the connection

of a local monitor and speakers.

• Includes mounting hardware that allows units to be wall-mounted, rack

mounted or pole mounted.

• Features built-in equalization and gain controls to adjust the video image.

• EDID copy feature ensures optimal display compatibility.

B130-101-WP-1

• Extends a VGA video signal (1024 x 768 @ 60 Hz) up to 1,000 ft. from

the source.

• Includes a VGA splitter cable, which allows for the connection of a local

monitor.

• Includes RJ45 jacks, allowing for easy connection via standard patch

cables; no 110 punchdown connections required.

• Features built-in equalization and gain controls to adjust the video image.

15-08-104-933289-EN.indd 4 8/21/2015 3:45:46 PM

B130-101A-WP-2

• Extends both a VGA video (1024 x 768 @ 60 Hz) and an audio signal

up to 1,000 ft. from the source.

• Includes a VGA + audio splitter cable, which allows for the connection

of a local monitor and speakers.

• Includes RJ45 jacks, allowing for easy connection via standard patch

cables; no 110 punchdown connections required.

• Features built-in equalization and gain controls to adjust the video image.

• EDID copy feature ensures optimal display compatibility.

B130-101S-2

• Extends both a VGA video (1024 x 768 @ 60 Hz) and RS-232 Serial

signal up to 1,000 ft. from the source.

• Includes mounting hardware that allows units to be wall-mounted, rack

mounted or pole mounted.

• Features built-in equalization and gain controls to adjust the video image.

• EDID copy feature ensures optimal display compatibility.

B130-111

• Kit comes with both local transmitter and remote repeater units.

• Locate multiple monitors at different points in a chain of up to 2,000 ft.

by connecting an additional remote receiver unit (B132-100-1 or

B132-100-WP-1), or a remote repeater unit (B132-110).

• Up to 4 remote units (3 remote repeaters and 1 receiver) can be

connected together, providing video to up to 4 remote displays in a full chain.

• Extends a 1024 x 768 (60 Hz) signal up to 1,000 ft. between the local

transmitter and the ﬁrst remote repeater unit in the installation.

• Extends a 1024 x 768 (60 Hz) signal up to an additional 1,000 ft. from

the ﬁrst remote repeater unit to the last display in the installation, for a

maximum extension distance of 2,000 ft.

• Local unit includes an additional VGA port, allowing for the connection

of a local monitor.

• Features built-in equalization and gain controls to adjust the video image.

• Includes mounting hardware that allows units to be wall-mounted,

rack mounted or pole mounted.

Product Features continued

15-08-104-933289-EN.indd 5 8/21/2015 3:45:46 PM

Product Features continued

B130-111A

• Kit comes with both local transmitter and remote repeater units.

• Locate multiple monitors/speakers at different points in a chain of up to

2,000 ft. by connecting an additional remote receiver unit (B132-100A

or B132-100A-WP-1), or a remote repeater unit (B132-110A).

• Up to 4 remote units (3 remote repeaters and 1 receiver) can be

connected together, providing audio/video to up to 4 remote displays/

speakers in a full chain.

• Extends a 1024 x 768 (60 Hz) video and audio signal up to 1,000 ft.

between the local transmitter and the ﬁrst remote repeater unit in the

installation.

• Extends a 1024 x 768 (60 Hz) video and audio signal up to an

additional 1,000 ft. from the ﬁrst remote repeater unit to the last set

of display and speakers in the installation, for a maximum extension

distance of 2,000 ft.

• Local unit includes additional VGA video and 3.5 mm audio ports,

allowing for the connection of a local monitor and speakers.

• Features built-in equalization and gain controls to adjust the video image.

• Includes mounting hardware that allows units to be wall-mounted,

rack mounted or pole mounted.

B130-101-U

• Extends a VGA video signal (1024 x 768 @ 60 Hz) up to 500 ft. from

the source.

• Power is supplied by the USB connection on the local transmitter unit;

no external power supplies are required.

• Dongle-style local and remote units come with built-in VGA connectors;

no external VGA cables are required.

• Features built-in equalization and gain controls to adjust the video image.

15-08-104-933289-EN.indd 6 8/21/2015 3:45:46 PM

Product Features continued

B132-002-2

• Works with the B132-100-1 and B132-100-WP-1 remote units to extend a

VGA video signal (1024 x 768 @ 60Hz) up to 1,000 ft. from the source.

• Able to transmit a single VGA video signal to 2 monitors.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• EDID copy feature ensures optimal display compatibility.

B132-002A-2

• Works with the B132-100A and B132-100A-WP-1 remote units to

extend both a VGA video (1024 x 768 @ 60 Hz) and an audio signal up

to 1,000 ft. from the source.

• Transmits a single VGA video and audio signal to 2 sets of monitors and

speakers.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• EDID copy feature ensures optimal display compatibility.

B132-004-2

• Features an additional VGA port, allowing for the connection of a local

monitor.

• Works with the B132-100-1 and B132-100-WP-1 remote units to extend a

VGA video signal (1024 x 768 @ 60Hz) up to 1,000 ft. from the source.

• Able to transmit up to 5 (4 remote, 1 local) VGA video signals.

• Expand the number of connected monitors to up to 25 (24 remote,

1 local) by daisy chaining up to 6 local units together.

Note: B132-002-2 local units cannot be daisy chained.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• EDID copy feature ensures optimal display compatibility.

• Up to three local units can be connected to a Tripp Lite B132-004-RB

rackmount bracket and mounted in just 1U of rack space.

15-08-104-933289-EN.indd 7 8/21/2015 3:45:46 PM

Product Features continued

B132-004A-2

• Works with the B132-100A and B132-100A-WP-1 remote units to

extend both a VGA video (1024 x 768 @ 60 Hz) and an audio signal up

to 1,000 ft. from the source.

• Features additional VGA and 3.5mm ports, allowing for the connection

of a local monitor and speakers.

• Transmits a single VGA video and audio signal to up to 5 sets

(4 remote, 1 local) of monitors and speakers.

• Expand the number of connected monitors/speakers to up to 25

(24 remote, 1 local) by daisy chaining up to 6 local units together.

Note: B132-002A-2 local units cannot be daisy chained.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• Up to three local units can be connected to a Tripp Lite B132-004-RB

rackmount bracket and mounted in just 1U of rack space.

• EDID copy feature ensures optimal display compatibility.

B132-008A-2

• Works with the B132-100A and B132-100A-WP-1 remote units to extend

both a VGA video (1024 x 768 @ 60 Hz) and an audio signal up to 1,000

ft. from the source.

• Features additional VGA and 3.5 mm ports, allowing for the connection of a

local monitor and speakers.

• Transmits a single VGA video and audio signal to up to 9 sets (8 remote, 1

local) of monitors and speakers.

• Expand the number of connected monitors/speakers to up to 49 (48

remote, 1 local) by daisy chaining up to 6 local units together.

Note: B132-002A-2 local units cannot be daisy chained.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• EDID copy feature ensures optimal display compatibility.

15-08-104-933289-EN.indd 8 8/21/2015 3:45:46 PM

Product Features continued

B132-100-1

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• Features built-in equalization and gain controls to adjust the video image.

B132-100A

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• Features built-in equalization and gain controls to adjust the video image.

B132-100-WP-1

• Includes RJ45 jacks, allowing for easy connection via standard patch

cables; no 110 punchdown connections required.

• Features built-in equalization and gain controls to adjust the video image.

B132-100A-WP-1

• Includes RJ45 jacks, allowing for easy connection via standard patch

cables; no 110 punchdown connections required.

• Features built-in equalization and gain controls to adjust the video image.

B132-110

• Extends and expands your Tripp Lite VGA over Cat5 installation, allowing

you to locate multiple monitors at different points in a chain of up to

2,000 ft.

• Up to 4 remote units (3 remote repeaters and 1 receiver) can be connected

together, providing video to up to 4 remote displays in a full chain.

• Extends a 1024 x 768 (60 Hz) signal up to 1,000 ft. between the local

transmitter and the ﬁrst remote repeater unit in the installation.

• Extends a 1024 x 768 (60 Hz) signal up to an additional 1,000 ft. from

the ﬁrst remote repeater unit to the last display in the installation, for a

maximum extension distance of 2,000 ft.

• Features built-in equalization and gain controls to adjust the video image.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

15-08-104-933289-EN.indd 9 8/21/2015 3:45:46 PM

Optional Accessories

• B132-004-RB 1U Rackmount Bracket

• N001-Series Cat5e Snagless Patch Cables

• N002-Series Cat5e Patch Cables

• N020-01K-GY Gray Cat5e Bulk Stranded Cable – 1,000 ft.

• N022-01K-GY Gray Cat5e Bulk 24 AWG Solid Cable – 1,000 ft.

• N030-010 10-pack of RJ45 Plugs for Solid-wire Cat5e Cable

• N031-050 50-pack of RJ45 Plugs for Stranded-wire Cat5e Cable

• N201-Series Cat6 Snagless Patch Cables

• N202-Series Cat6 Snagless 24 AWG Solid Patch Cables

• N222-01K-GY Gray Cat6 Bulk 24 AWG Solid Cable – 1,000 ft.

• P312-Series Audio Cables

Product Features continued

B132-110A

• Both extends and expands your Tripp Lite VGA + audio over Cat5

installation, allowing you to locate multiple monitors/speakers at

different points in a chain of up to 2,000 ft.

• Up to 4 remote units (3 remote repeaters and 1 receiver) can be

connected together, providing audio/video to up to 4 remote displays/

speakers in a full chain.

• Extends a 1024 x 768 (60 Hz) video and audio signal up to 1,000 ft.

between the local transmitter and the ﬁrst remote repeater unit in the

installation.

• Extends a 1024 x 768 (60 Hz) video and audio signal up to an

additional 1,000 ft. from the ﬁrst remote repeater unit to the last set

of display and speakers in the installation, for a maximum extension

distance of 2,000 ft.

• Features built-in equalization and gain controls to adjust the video image.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

15-08-104-933289-EN.indd 10 8/21/2015 3:45:46 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tripp Lite Extenseur

Tripp Lite

Tripp Lite B203-101-PNP Manuel utilisateur

Tripp Lite

Tripp Lite B127F-1A1-MM-DD Manuel utilisateur

Tripp Lite

Tripp Lite B127-008-D Manuel utilisateur

Tripp Lite

Tripp Lite B150-1A1-HDMI Manuel utilisateur

Tripp Lite

Tripp Lite NPOE-EXT-1G30 Manuel utilisateur

Tripp Lite

Tripp Lite Wireless Console Extender B014-000 Manuel utilisateur

Tripp Lite

Tripp Lite B121-000 Manuel utilisateur

Tripp Lite

Tripp Lite B150-1A1-DVI Manuel utilisateur

Tripp Lite

Tripp Lite B130-101S-WP Manuel utilisateur

Tripp Lite

Tripp Lite B127U-002-PDPH2 Manuel utilisateur

Tripp Lite

Tripp Lite B130-101-2: B130-101A-2 Manuel utilisateur

Tripp Lite

Tripp Lite B127-1A1-CH Manuel utilisateur

Tripp Lite

Tripp Lite B203-101-POC Manuel utilisateur

Tripp Lite

Tripp Lite B137-101 Manuel utilisateur

Tripp Lite

Tripp Lite : B140-002 Manuel utilisateur

Tripp Lite

Tripp Lite 8TLP167000 Manuel utilisateur

Tripp Lite

Tripp Lite B202-150 Manuel utilisateur

Tripp Lite

Tripp Lite B126-1A1-WHD3 Manuel utilisateur

Tripp Lite

Tripp Lite BHDBT-K-E3SI-ER Manuel utilisateur

Tripp Lite

Tripp Lite B140-002-DD Manuel utilisateur

Tripp Lite

Tripp Lite B127U-111-PHPH Manuel utilisateur

Tripp Lite

Tripp Lite B126-004 Manuel utilisateur

Tripp Lite

Tripp Lite B127A-4X1-BH Manuel utilisateur

Tripp Lite

Tripp Lite B164-101-WIR Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
