TRENDnet TE100-SK4 Manuel utilisateur

TRENDnet's TE100-SK4, a 10/100Mbps Fast Ethernet

Switched Network Kit, is a complete solution for connecting

two personal computers to share files, printers, and hard

drives. The kit comes with two 32-bit PCI Bus 10/100Mbps

NWay Fast Ethernet PCI cards (TE100-PCIWN), one 5-port

10/100Mbps Ethernet Mini Switch (TE100-S5P), two 15 feet

CAT5 cables, and an easy-to-use installation guide. As your

network grows, you can uplink switches or network hubs to the

5-port mini switch to gain more ports. Designed espe-cially for

home and small office use, this reliable network kit lets you

cruise in 200Mbps (full-duplex) and expand your network in

the future.

TE100-SK4

10/100Mbps Switched Fast Ethernet Network Kit

Complies with IEEE 802.3 and IEEE 802.3u standards

Single RJ-45 connector (CAT 3, 4, 5 UTP/STP cables for

10Mbps operation and CAT 5 UTP/STP cable for 100Mbps

operation)

32-bit PCI Bus master mode

Plug and Play (PnP) for auto-configuration

Supports half- and full-duplex operation

Built-in FIFO buffers reduces overhead of memory transfers

Compatible with all popular operating systems

5 Year Warranty

Complies with IEEE 802.3 and IEEE 802.3u standards

Five 10/100Mbps NWay auto-negotiation UTP/STP RJ-45 ports

Operates at maximum packet filtering and forwarding rate

MDI-II uplink port (shared) for easy expansion

128Kb buffer memory

Half- or full-duplex mode

Filtering Address Table up to 1K MAC entries (per device)

Compact design with external power adapter

5 Year Warranty

BENEFITSFEATURES

Upgrabable:

Expandable:

Flexible:

Cost Effective:

Add workstations as needed.

Add a server, Internet station, network

printer, or network hub without

changing the switch.

Switch is small enough to be put

anywhere it is needed.

With a 5 year warranty, purchase only

the parts you need.

10/100Mbps 32-Bit N-way Fast Ethernet PCI Card (TE100-PCIWN)

5-Port 10/100Mbps Ethernet Mini Switch (TE100-S55Eplus)

TE100-SK4 (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE-SK1: 5-Port 10Base-T Hub Ethernet Starter Kit

(2 x TE-PCIWT, 1 x TE-500, 2 x 15' CAT 5 cables)

TE100-SK1: 5-Port 100Base-T Hub Fast Ethernet Starter Kit

(2 x TE100-PCIW, 1 x TE100-H5E, 2 x 15' CAT 5 cables)

TE100-SK2: 4-Port 10/100Mbps Dual Speed Starter Kit

(1 x TE100-PCIWplus, 1x TE100-DX4PCI, 1 x 15' CAT 5 cables)

TE100-SK3: 5-Port 10/100Mbps Switch Fast Ethernet

Network Kit

(2 x TE100-PCIWN, 1x TE100-S55E, 2 x 20' CAT 5 cables)

TE100-SK3plus: 5-Port 10/100Mbps Switch Fast Ethernet

Network Kit

(2 x TE100-PCIWN, 1x TE100-S55Eplus, 2 x 20' CAT 5 cables)

TE100-SK4: 10/100Mbps Switched Fast Ethernet Network Kit

(2 x TE100-PCIWN, 1 x TE100-S5P, 2 x 15" CAT 5 cable)

NETWORKING SOLUTIONS

SOFTWARE SUPPORT

Windows NT

Windows 95/98/2000

Windows for Workgroups

Novell NetWare

LAN Manager

IBM LAN Server

IBM LAN Support

IBM TCP/IP

•

NDIS Driver

DEC PATHWORKS

Banyan

SCO UNIX

Packet Driver

FTP PC/TCP

NCSA TCP/IP

LINUX

•

TE100-SK4

10/100Mbps Switched Fast Ethernet Network Kit

TE100-SK4

10/100Mbps Switched Fast Ethernet Network Kit

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
