TPI A771 Manuel utilisateur

A771

CO Accessory

Instruction Manual

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

CONTENTS

1. Caution

2. Product Features

3. General Description

4. Operation

5. Battery Replacement

6. Specifications

7. Alarm Adjustment

8. Calibration

CAUTION

The A771 is factory calibrated and designed to measure

quantitative readings and alarm in the presence of

Carbon Monoxide only. The A771 can be used with any

digital multimeter with a 2-4 volt DC range capable of

measuring 0.001 volts DC.

The A771 is factory set to alarm at 30ppm, both when

new or when returned from an authorized repair center.

PRODUCT FEATURES

1. ON/OFF switch

2. Power LED

3. Alarm LED

4. Zero adjustment

5. Cord

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

CONTENTS

1. Caution

2. Product Features

3. General Description

4. Operation

5. Battery Replacement

6. Specifications

7. Alarm Adjustment

8. Calibration

CAUTION

The A771 is factory calibrated and designed to measure

quantitative readings and alarm in the presence of

Carbon Monoxide only. The A771 can be used with any

digital multimeter with a 2-4 volt DC range capable of

measuring 0.001 volts DC.

The A771 is factory set to alarm at 30ppm, both when

new or when returned from an authorized repair center.

PRODUCT FEATURES

1. ON/OFF switch

2. Power LED

3. Alarm LED

4. Zero adjustment

5. Cord

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GENERAL

DESCRIPTION

The A771 is an advanced state-of-the-art Carbon

Monoxide monitor that may be used to measure

levels of carbon monoxide (CO) in th part per

million (ppm) range when used with a digital

multimeter (DMM).

The instrument has both audible and visual alarms

when CO has reached the preset level. This unit

may be operated as an alarm only personal

monitor.

NOTE: The product may be used with any DMM

capable of measuring 2-4 volts DC. The signal

output is 1 mV DC = 1 ppm CO.

The A771 uses and advanced electrochemical

sensor that measures Carbon Monoxide only. A

built-in filter reduces most cross-sensitivity to

other gases. This product should be used with

DMM’s with greater than or equal to 10 megohm

impedance.

OPERATION

(Investigation Use)

1. Attach the banana jack to the COM and V input jacks

of the DMM.

2. Turn on the DMM and select the 2 or 4 volt range

DC.

3. If the voltage reading is below 4 VDC with the A771

in the off position, replace the 9 volt battery in the

A771.

4. Turn on the A771. The alarm LED with flash and the

green LED should stay on.

5. In a clean environment, adjust the zero knob until

the DMM reads zero.

6. Place the A771 in the area to be tested and read the

CO in ppm on the DMM.

7. To deactivate the alarm sound, set the slide switch

to MUTE.

OPERATION

(Monitor Use)

1. Follow steps 1-5 above.

2. Unplug the A771 from the DMM.

3. Place the A771 in the belt pouch with the sensor

facing outward.

4. If an alarm occurs, use a DMM to measure the

concentration.

5. The red LED will illuminate continuously during

alarms

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

GENERAL

DESCRIPTION

The A771 is an advanced state-of-the-art Carbon

Monoxide monitor that may be used to measure

levels of carbon monoxide (CO) in th part per

million (ppm) range when used with a digital

multimeter (DMM).

The instrument has both audible and visual alarms

when CO has reached the preset level. This unit

may be operated as an alarm only personal

monitor.

NOTE: The product may be used with any DMM

capable of measuring 2-4 volts DC. The signal

output is 1 mV DC = 1 ppm CO.

The A771 uses and advanced electrochemical

sensor that measures Carbon Monoxide only. A

built-in filter reduces most cross-sensitivity to

other gases. This product should be used with

DMM’s with greater than or equal to 10 megohm

impedance.

OPERATION

(Investigation Use)

1. Attach the banana jack to the COM and V input jacks

of the DMM.

2. Turn on the DMM and select the 2 or 4 volt range

DC.

3. If the voltage reading is below 4 VDC with the A771

in the off position, replace the 9 volt battery in the

A771.

4. Turn on the A771. The alarm LED with flash and the

green LED should stay on.

5. In a clean environment, adjust the zero knob until

the DMM reads zero.

6. Place the A771 in the area to be tested and read the

CO in ppm on the DMM.

7. To deactivate the alarm sound, set the slide switch

to MUTE.

OPERATION

(Monitor Use)

1. Follow steps 1-5 above.

2. Unplug the A771 from the DMM.

3. Place the A771 in the belt pouch with the sensor

facing outward.

4. If an alarm occurs, use a DMM to measure the

concentration.

5. The red LED will illuminate continuously during

alarms

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

BATTERY REPLACEMENT

1. Remove the single screw in the case back.

2. Slide open the battery compartment cover in the

direction of the arrow.

3. Replace the 9 volt battery and reassemble the unit.

SPECIFICATIONS

Size: 6.5” x 2.0” x 1.25”

(65 x 50 x 29mm)

Weight: 5.0 oz (142g)

Battery: 9 volt alkaline

Duty Cycle: 2,000 hours

Sensor: Long life Electrochemical

Range: 0 - 1999 ppm

Alarms: Visual, Audible

Alarm Set Range: 0-200 ppm

Calibration: 100ppm

Response Time: 90% of reading in 60 seconds

Temperature: 0 - 120 F

Relative Humidity: 5 - 95%

Accuracy: +/- 5ppm or 5% of reading,

whichever is greater

ALARM ADJUSTMENT

The alarm on the A771 is factory set at 30ppm. Use

the following procedure to select a different level

between 0 and 200ppm:

1. Remove the battery compartment cover on the

A771.

2. Using a DMM set to the DCmV range, touch the tips

of the test leads to the GND and Alarm test points on

the PCB (located on the left and right next to the

VR1 and VR2 adjustment pots).

3. Reading the DMM, set the alarm to the desired level

(1ppm = 1mV DC) by adjusting VR2.

4. Remove the leads and reassemble the A771.

CALIBRATION

1. Attach the banana jack to the COM and V input jacks

of the DMM.

2. Turn on the DMM and select the 2 or 4 volt range

DC.

3. If the voltage reading is below 4 VDC with the A771

in the off position, replace the 9 volt battery in the

A771.

4. Turn on the A771. The alarm LED with flash and the

green LED should stay on.

5. In a clean environment, adjust the zero knob until

the DMM reads zero.

6. Attach proper gas, regulator and adapter assembly

to the A771.

7. Allow to stabilize for 1 minute.

8. Adjust VR1 in the battery compartment to the

proper gas value.

9. Disconnect gas and allow A771 to zero.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

BATTERY REPLACEMENT

1. Remove the single screw in the case back.

2. Slide open the battery compartment cover in the

direction of the arrow.

3. Replace the 9 volt battery and reassemble the unit.

SPECIFICATIONS

Size: 6.5” x 2.0” x 1.25”

(65 x 50 x 29mm)

Weight: 5.0 oz (142g)

Battery: 9 volt alkaline

Duty Cycle: 2,000 hours

Sensor: Long life Electrochemical

Range: 0 - 1999 ppm

Alarms: Visual, Audible

Alarm Set Range: 0-200 ppm

Calibration: 100ppm

Response Time: 90% of reading in 60 seconds

Temperature: 0 - 120 F

Relative Humidity: 5 - 95%

Accuracy: +/- 5ppm or 5% of reading,

whichever is greater

ALARM ADJUSTMENT

The alarm on the A771 is factory set at 30ppm. Use

the following procedure to select a different level

between 0 and 200ppm:

1. Remove the battery compartment cover on the

A771.

2. Using a DMM set to the DCmV range, touch the tips

of the test leads to the GND and Alarm test points on

the PCB (located on the left and right next to the

VR1 and VR2 adjustment pots).

3. Reading the DMM, set the alarm to the desired level

(1ppm = 1mV DC) by adjusting VR2.

4. Remove the leads and reassemble the A771.

CALIBRATION

1. Attach the banana jack to the COM and V input jacks

of the DMM.

2. Turn on the DMM and select the 2 or 4 volt range

DC.

3. If the voltage reading is below 4 VDC with the A771

in the off position, replace the 9 volt battery in the

A771.

4. Turn on the A771. The alarm LED with flash and the

green LED should stay on.

5. In a clean environment, adjust the zero knob until

the DMM reads zero.

6. Attach proper gas, regulator and adapter assembly

to the A771.

7. Allow to stabilize for 1 minute.

8. Adjust VR1 in the battery compartment to the

proper gas value.

9. Disconnect gas and allow A771 to zero.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

WARRANTY

The A771 is warranted to be free from defects in

materials and workmanship for the period of one year

from the date of purchase. If within the warranty period

your instrument should become inoperative from such

defects, the unit will be repaired or replaced at our

option. This warranty covers normal use and does not

cover damage which occurs in shipment or failure

which results from alteration, tampering, accident,

misuse, abuse, neglect or improper maintenance.

Instruments out of warranty will be repaired for a

service charge.

Return unit freight prepaid to:

TPI Service Center

9615 SW Allen Blvd. Ste 104

Beaverton, OR 97005

(503) 520-9197

This warranty gives you specific legal rights. You may

have other rights which vary from state to state.
