TP-Link Tapo S505D Manuel utilisateur

User Guide

Smart Wi-Fi Light Switch, Dimmer

Contents

About This Guide ·············································································································································1

Introduction ························································································································································2

Appearance ························································································································································3

Wire Your Switch···············································································································································5

Set Up Your Switch ·········································································································································9

Set Up Your Smart Switch via Matter·································································································10

Authentication················································································································································13

About This Guide

This guide provides a brief introduction to the Smart Wi-Fi Light Switch, Dimmer and regulatory information.

Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and

descriptions in this guide are only examples and may not reect your actual Tapo experience.

Conventions

In this guide, the following convention is used:

Convention Description

Blue Key information appears in blue, including management page text such as menus, items, buttons and so on.

Underline Hyperlinks are in blue and underlined. You can click to redirect to a website.

Note: Ignoring this type of note might result in a malfunction or damage to the device.

More Info

• Specications can be found on the product page at https://www.tapo.com.

• Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/.

Introduction

With the Tapo Smart Wi-Fi Dimmer Light Switch, Matter, customize lighting ambience from anywhere.

• Matter Certied – Integrate Matter-certied Tapo devices with other Matter end products into your preferred ecosystem.

• Brightness Control – Control the brightness of your lights to set the ideal ambiance for dierent activities.

• Fade On/O – Slowly increase brightness or dim to o when turning lights on/o

• Voice Control – Manage your smart switch with voice commands via Amazon Alexa, Apple Siri®, or Google Assistant.

• Remote Control – Instantly turn connected devices on/o from wherever you are through the Tapo app.

• Schedule – Preset a schedule to automatically manage devices.

• Away Mode – Randomly turns devices on and o at dierent times to give the appearance that someone is home.

• Smarter with Sensors – Create Smart Actions triggered by Tapo smart sensors for greater automation (Tapo Smart Sensor are sold separately.

When working with a Tapo Smart Sensor, the Tapo Hub is required).

Appearance

On/O

Button

Decrease/Increase

Brightness

Restart

LED

Reset

Brightness

Indicators

Button Explanations

Restart

Reset

Press and hold for about 5s to reset

Wi-Fi while keeping other settings.

Press to restart your switch.

Decrease or increase the brightness.

Press and hold for about 10s to restore

your switch to factory default settings.

LED Status

Starting up; disconnected

from cloud.

Solid amber

Blinking amber

Blinking green

White

Solid red

Stay green for 30s

Blinking amber & green

Connecting to Wi-Fi.

Ready for setup.

Device resetting.

Light fixture is off.

Disconnected from Wi-Fi.

Connected to Wi-Fi.

Blinking green slowly Firmware upgrading.

Matter Numeric Code

• For Matter initial setup.

Detach the Wallplate

Carefully insert a at-bladed screw driver the opening at the bottom of the wallplate and pull forward to remove the wallplate.

Note: Your can nd another Matter setup code label in the package and stick it anywhere you like as needed for initial matter setup.

*Images may dier from your actual product.

Wire Your Switch

Follow the steps below to wire your Smart Wi-Fi Dimmer Light Switch. If you are not familiar with basic electronical wiring, please consult an electrician.

Before You Start

1. Prepare Baisc knowledge of Wiring

• Ground: Usually green or copper.

• Neutral: Usually white, not connected to the dumb switch.

• Line: Usually black and coming from the circuit breaker.

• Load: Usually black. One end is connected to the light.

Note: If you are unsure, consult a qualied electrician.

2. Prepare Your Tools

Prepare a philips and slotted screwdriver, pliers, wire strippers and a voltage detector.

3. Check Wi-Fi Strength

Make sure your switch is in a area with strong Wi-Fi signal.

Step 1. Turn O Power and Remove the Wallplate

Turn o the circuit breaker. Then remove the old wallplate of the wall

switch and label the wires.

Step 3. Identify Line and Load wires

1) Turn on the circuit breaker. Use a voltage detector to identify the

energized wire (Line wire).

Wire Your Switch

Step 2. Expose Your Switch Wiring

Remove the screws securing your old switch to the wall box. Gently

pull the switch out and disconnect wires from the old switch.

2) Turn o the circuit breaker. Label the Line and Load wires.

Load wire

Line wire

MISE EN GARDE

Risque d'électrocution - Haute tension. Débrancher l'alimentation électrique avant d'utiliser.

CAUTION

Risk of Electric Shocks - High Voltage - Disconnect power supply before servicing.

Step 4. Connect the Wires

Connect the wires to the smart dimmer switch as shown below.

Step 5. Install Your Smart Dimmer

Gently fold all of the wires back into the wall box. Line up the switch

with the mounting holes. Secure it with screws.

Power

Source

To Light

Step 6. Attach the Wallplate and Turn on Power

Attach the wallplate and turn on the circuit breaker. Then the wiring is

nished.
