JetStream Smart Switch

T1500-28TC/T1500-28PCT

About this Installation Guide

This Installation Guide describes the hardware characteristics, installation methods and the

points that should be attended to during the installation. This Installation Guide is structured as

follows:

Chapter 1 Introduction

This chapter describes the external components of the switch.

Chapter 2 Installation

This chapter illustrates how to install the switch.

Chapter 3 Lightning Protection

This chapter illustrates how to prevent lightning damage.

Chapter 4 Connection

This chapter illustrates how to do the physical connection of the switch.

Appendix A Troubleshooting

Appendix B Specifications

Audience

This Installation Guide is for:

Network Engineer Network Administrator

Conventions

• Some models featured in this guide may be unavailable in your country or region. For local

sales information, visit http://www.tp-link.com.

• The figures in Chapter 2 to Chapter 4 are for demonstration purposes only. Your switch may

differ in appearance from that depicted.

• This guide uses the specific formats to highlight special messages. The following table lists

the notice icons that are used throughout this guide.

Remind to be careful. A caution indicates a potential which may result in device damage.

Remind to take notice. The note contains the helpful information for a better use of the

product.

Related Document

This Installation Guide is also available in PDF on our website. To obtain the latest

documentation and product information, please visit the official website:

http://www.tp-link.com

Contents

Chapter 1 Introduction ——————————— 01

1.1 Product Overview ...........................................................01

1.2 Appearance.......................................................................01

Chapter 2 Installation ——————————— 06

2.1 Package Contents ..........................................................06

2.2 Safety Precautions .........................................................06

2.3 Installation Tools..............................................................08

2.4 Product Installation ........................................................09

Chapter 3 Lightning Protection ——————— 11

3.1 Cabling Reasonably........................................................11

3.2 Connect to Ground.........................................................13

Chapter 4 Connection ——————————— 17

4.1 Ethernet Port ....................................................................17

4.2 Verify Installation.............................................................17

4.3 Power On............................................................................17

4.4 Initialization........................................................................18

Chapter 5 Login to the Switch———————— 19

5.1 ConguretheSwitchviaGUI......................................19

5.2 ConguretheSwitchviaCLI.......................................20

Appendix A Troubleshooting ———————— 21

AppendixBSpecications ————————— 22

JetStream Smart Switch

Introduction

Chapter 1 Introduction

1.1 Product Overview

T1500-28TC/T1500-28PCT is compliant with the IEEE802.3 Ethernet protocols.

T1500-28TC/T1500-28PCT is equipped with powerful management interface, via

which system, port, network, VLAN and priority can be configured. They provide a

variety of service features and multiple powerful functions with high security. The

EIA-standardized framework and smart configuration capacity can provide flexible

solutions for a variable scale of networks. QoS and IGMP snooping/filtering optimize

voice and video application. SNMP, RMON, WEB Log-in bring abundant management

policies.

T1500-28TC/T1500-28PCT integrates multiple functions with excellent performance,

and are friendly to manage, which can fully meet the need of the users demanding

higher networking performance.

T1500-28PCT Switch is also a Power Sourcing Equipment (PSE*). All the fast Ethernet

RJ45 ports on the switch support Power over Ethernet (PoE*) function, which can

automatically detect and supply power with those powered devices (PDs*) complying

with IEEE 802.3af and IEEE 802.3at.

*PSE: a device (switch or hub for instance) that provides power through an Ethernet

cable.

*PoE: This technology describes a system to transmit electrical power, along with data,

to remote devices over standard twisted-pair cable in an Ethernet.

*PD: a device powered by a PSE and thus consumes energy. Examples include powering

network cameras, wireless LAN access points, IP telephones, network hubs, embedded

computers etc.

1.2 Appearance

■Front Panel

The front panel of T1500-28TC is shown as the following figure.

Figure 1-1 Front Panel of T1500-28TC

ResetLEDs 10/100Mbps RJ45 Port 10/100/1000Mbps RJ45 Port

SFP Port

JetStream Smart Switch

Introduction

LEDs

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

10/100M

On A device is connected to the corresponding port but no

activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

1000M

Green On A 1000Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Yellow On A 10/100Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Reset

With the switch powered on, press Reset button for 5 seconds to reset the software

setting to its factory default settings.

10/100Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps. Each

has a corresponding 10/100M or PoE LED.

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or

1000Mbps. Each has a corresponding 1000M LED.

SFP Port

Designed to install the SFP module. T1500-28TC features some SFP transceiver

slots that are shared with the associated RJ45 ports. The associated two ports

are referred as a "Combo" port, which means they cannot be used simultaneously,

otherwise only SFP port works. Meanwhile, the associated two ports share the same

LED. For T1500-28TC, Port 27 shares the same LED with Port 27F and Port 28 shares

the same LED with Port 28F.

JetStream Smart Switch

Introduction

The front panel of T1500-28PCT is shown as the following figure.

Figure 1-2 Front Panel of T1500-28PCT

LEDs 10/100Mbps RJ45

Port and PoE Port

10/100/1000Mbps

RJ45 Port

LED Mode

Switch Button

SFP Port

Reset

LEDs

T1500-28PCT has an LED mode switch button which is for switching the LED

status indication. When the Speed LED is on, the port LED is indicating the data

transmission status. When the PoE LED is on, the port LED is indicating the power

supply status. By default, the Speed LED is on. Pressing the mode switch button, the

Speed LED will turn off and the PoE LED will light up. Then the PoE LED will turn off

after being on for 60 seconds and the Speed LED will light up again.

When the Speed LED is on, the port LED is indicating the data transmission status.

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

FAN Green All the fans work properly

Yellow Not all the fans work properly

PoE Max

On The remaining PoE power≤7W

Flashing The remaining PoE power keeps ≤7W after this LED is

on for 2 minutes

Off The remaining PoE power＞

10/100M

or PoE

Green On A 100Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Yellow On A 10Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

JetStream Smart Switch

Introduction

1000M

Green On A 1000Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Yellow On A 10/100Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

When the PoE LED is on, the port LED is indicating the power supply status.

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

FAN Green All the fans work properly

Yellow Not all the fans work properly

PoE Max

On The remaining PoE power≤7W

Flashing The remaining PoE power keeps ≤7W after this LED is

on for 2 minutes

Off The remaining PoE power＞

10/100M

or PoE

Green

On The port is supplying power normally

Flashing The supply power exceeds the correponding port's

maximum power

Yellow On Overload or short circuit is detected

Flashing Power-on self-test has failed

Off No PoE power supply is provided on the port

1000M

Green On A 1000Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Yellow On A 10/100Mbps device is connected to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Reset

With the switch powered on, press Reset button for 5 seconds to reset the software

setting to its factory default settings.

10/100Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps. Each

has a corresponding 10/100M or PoE LED.

JetStream Smart Switch

Introduction

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or

1000Mbps. Each has a corresponding 1000M LED.

SFP Port

Designed to install the SFP module. T1500-28PCT features some SFP transceiver

slots that are shared with the associated RJ45 ports. The associated two ports

are referred as a "Combo" port, which means they cannot be used simultaneously,

otherwise only SFP port works. Meanwhile, the associated two ports share the same

LED. For T1500-28PCT, Port 27 shares the same LED with Port 27F and Port 28

shares the same LED with Port 28F.

■Rear Panel

The rear panel of T1500-28TC is shown as the following figure.

Figure 1-3 Rear Panel of T1500-28TC

100-240V~ 50/60Hz 0.3A

ensington Security Slot Grounding Terminal Power Socket

The rear panel of T1500-28PCT is shown as the following figure.

Figure 1-4 Rear Panel of T1500-28PCT

100-240V~ 50/60Hz 3.0A

ensington Security Slot Grounding TerminalPower Socket

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from being

stolen.

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC (Alternating Current) power outlet. Please make sure the voltage of the power

supply meets the requirement of the input voltage.

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also ground

the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable.

For detailed information, please refer to Chapter 3 Lightning Protection.

Caution: Please use the provided power cord.

JetStream Smart Switch

Installation

Chapter 2 Installation

2.1 Package Contents

Make sure that the package contains the following items. If any of the listed items is

damaged or missing, please contact your distributor.

One Power Cord

One Switch This Installation Guide

Installation Guide

BusinessNetworking Solution

Two mounting brackets and

thettings

2.2 Safety Precautions

To avoid any device damage and bodily injury caused by improper use, please observe

the following rules.

■Safety Precautions

■Keep the power off during the installation.

■Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good skin

contact and is well grounded.

■Useonlythepowercordprovidedwiththeswitch.

■Make sure that the supply voltage matches the specifications indicated on the rear

panel of the switch.

■Ensure the vent hole is well ventilated and unblocked.

■Do not open or remove the cover of the switch.

■Before cleaning the device, cut off the power supply. Do not clean it by the waterish

cloth, and never use any other liquid cleaning method.

■Site Requirements

To ensure normal operation and long service life of the device, please install it in an

environment that meets the requirements described in the following subsection.

One Resource CD

JetStream Smart Switch

Installation

Temperature/Humidity

40℃

0℃

Please keep a proper temperature and humidity in the equipment room. Too high/ low

humidity may lead to bad insulation, electricity leakage, mechanical property changes

and corrosions. Too high temperature may accelerate aging of the insulation materials

and can thus significantly shorten the service life of the device. For normal temperature

and humidity of the device, please check the following table.

Environment Temperature Humidity

Operating 0℃to 40℃10% to 90%RH Non-condensing

Storage -40℃to 70℃5% to 90%RH Non-condensing

Clearness

The dust accumulated on the switch can be absorbed by static electricity and result

in poor contact of metal contact points. Some measures have been taken for the

device to prevent static electricity, but too strong static electricity can cause deadly

damage to the electronic elements on the internal circuit board. To avoid the effect of

static electricity on the operation of the Switch, please attach much importance to the

following items:

■Dust the device regularly, and keep the indoor air clean.

■Keep the device well grounded and ensure static electricity has been transferred.

Electromagnetic Interference

Electronic elements including capacitance and inductance on the device can be

affected by external interferences, such as conducted emission by capacitance

coupling, inductance coupling, and impedance coupling. To decrease the interferences,

please make sure to take the following measures:

■Usethepowersupplythatcaneffectivelyfilterinterferencefromthepowergrid.

■Keep the device far from high-frequency, strong-current devices, such as radio

transmitting station.

■Useelectromagneticshieldingwhennecessary.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TP-Link Changer

TP-Link

TP-Link LS105LP Manuel utilisateur

TP-Link

TP-Link JetStream TL-SL3428 Mode d’emploi

TP-Link

TP-Link TL-SF1008P Manuel d'instructions d'installation

TP-Link

TP-Link TL-SG2424P Manuel utilisateur

TP-Link

TP-Link tapo S505D Manuel utilisateur

TP-Link

TP-Link DS108GE Manuel utilisateur

TP-Link

TP-Link T1700G-28TQ Manuel utilisateur

TP-Link

TP-Link JetStream L2 Lite TL-SG3210 Mode d’emploi

TP-Link

TP-Link JetStream TL-SG2210P Manuel utilisateur

TP-Link

TP-Link TL-SF1008P Manuel utilisateur

TP-Link

TP-Link JetStream TL-SG3424 Manuel utilisateur

TP-Link

TP-Link JetStream TL-SG3424 Manuel utilisateur

TP-Link

TP-Link Omada DS1008X Manuel utilisateur

TP-Link

TP-Link TL-SG108 Manuel utilisateur

TP-Link

TP-Link TL-SG105 Manuel utilisateur

TP-Link

TP-Link JetStream TL-SL3452 Manuel utilisateur

TP-Link

TP-Link TL-SL2428 Manuel utilisateur

TP-Link

TP-Link TL-SG5426 - Manuel utilisateur

TP-Link

TP-Link UH720 Manuel utilisateur

TP-Link

TP-Link JetStream TL-SL5428E Manuel utilisateur

TP-Link

TP-Link tapo 7106509958 Manuel utilisateur

TP-Link

TP-Link TL-SG1008D Manuel utilisateur

TP-Link

TP-Link TL-SG1008P Manuel utilisateur

TP-Link

TP-Link JetStream T1500G-10PS Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
