Toro 2226 Guide de démarrage rapide

FormNo.3434-704RevA

2226DirectionalDrill

ModelNo.23803—SerialNo.400000000andUp

SoftwareGuide

SoftwareVersions:A.5,A.6,andRevB

Introduction

Readthisinformationcarefullytolearnhowtooperate

andmaintainyourproductproperlyandtoavoid

injuryandproductdamage.Youareresponsiblefor

operatingtheproductproperlyandsafely.Readyour

Operator’sManualformoreinformation.

ProductOverview

DisplayScreenButtons

g277422

Figure1

1.Button15.Button5

2.Button26.Button6

3.Button37.Button7

4.Button48.Button8

g277423

Figure2

1.Statusbar5.Downarrowbutton

2.Escapebutton6.Rightarrowbutton

3.Leftarrowbutton7.OKbutton

4.Uparrowbutton

Exit-SideLockoutDisabled

StartupScreen

Note:SoftwareversionA.5andabove.

Thisexitsidelockoutdisabledwarningwillappearif

youdisabledtheexitsidelockoutsystem.

g270157

Figure3

SeeExitSideLockoutSettings(page18)toenable

theexitsidelockoutsystem

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3434-704*A

HomeScreens

MainInformationScreen

Thisistherstscreenthatappearsaftertheinitial

splashscreen.Tonavigatebetweenscreens,usethe

leftandrightarrows.

g270083

Figure4

1.Pipefunctions6.Enginetemperaturegauge

2.Fuelgauge7.Engineload

3.Exitsidelockoutstatus

indicator

8.Thrustforce,drillspeed

(rpm),orrotarytorquelimit

adjustment

4.Limitsettingoptions9.Horn

5.Selectpiperow

Thepipefunctionsicon(Figure4)willturngreenwhen

SmartTouchisturnedon;refertoSmartT ouch™

HomeScreen(page8).

Exitsidelockoutstatusindicator:

Disabled(black)Enabled(green)

g270081

Figure5

1.Carriageindicator5.Enginespeed(rpm)

2.Drillspeed(rpm)6.Drilling-uidowrate

3.Rotarytorque7.Drilling-uidpressure

4.Thrustforce

Pushbutton1toswitchbetweenthepipefunctions:

pullpipe,pushpipe,neutral,ormanualpipeloading.

g236826

Figure6

1.Pushpipe3.Pullpipe

2.Neutral4.Manualpipeloading

Pushbuttons2and3toswitchchoosearow.

g236827

Figure7

1.Row13.Row3

2.Row2

Inmanualpipeloadingmode,usebuttons2and3

tochoosearowortoloadthepipetothedrillstring;

refertoManualPipeLoading(page13).

g236825

Figure8

ManualPipeLoadingOptions

1.Row13.Row3

2.Row24.Loadthepipetothedrill

string

Pushbutton5toswitchbetweenthrustforce,drill

speed(rpm),androtarytorque.

Usebuttons6and7tosetlimitsforthedrillspeed

(rpm),rotarytorque,andthrustforce.

g236824

Figure9

1.Thrustforce3.Rotarytorque

2.Drillspeed(rpm)

SettingtheRotarySpeed

UsetheOK(O)buttononthedisplay(Figure2)to

settherotaryspeed.

Pushthebuttontochoosebetweenhighspeed/low

torqueorlowspeed/hightorque.

CruiseModeandScreen

SoftwareversionRevBandup.

Cruisemodeisidentiedbythisicon:

Cruisemodeprovideshands-freeoperationforrotaryandthrust,setbytheoperator.

Note:UseCruisemodeforpullbackonly.Usingcruisemodeinthrustcouldcausedamage.

Youcanonlyusecruisemodewithclockwisefunctions.

AccessingtheCruiseScreen

Pushthecruisebuttononthejoystick(Figure10)orpushbutton4onthehomescreentoaccessthecruise

screen.

g290820

Figure10

Pushbutton4toswitchbetweencruiseandcarvemodes.

ActivatingCruise

1.Ifnecessary,setthemachinelimits;refertotheMainInformationScreen(page2).

2.Holdthejoystick(s)intheactivepositionfortheamountofthrustandrotationspeedyouwantandpush

thecruisebuttonontherightjoystick(Figure10),thenreleasethejoysticks.

Onceset,usethecruisescreentoadjustthesettings(Figure10).

1.Pushbuttons1,3,5,or8toselectthesettingtoadjust.

Note:Theiconturnsgreenandagreencirclehighlightstheoptionyouselect(Figure11).

2.Pushbutton6or7toincreaseordecreasethevalueoftheselectedsetting.

g298902

Figure11

Thefollowingtabledescribesthefunctionvaluesaffectedwhenanotherfunctionisgivenpriority.

Thepriorityisthefunctionwiththehighestvalue,notthevalueselectedinthescreen.

Allvaluesaredependentontheavailableenginehorsepower.

ButtonPriorityIconDescription

1Piperotationspeed

(RotaryRPM)

ThesetrotaryRPMismaintainedunlessthesetrotarytorqueis

exceeded,thentherotaryrpmisreduced.

3RotaryT orqueThesetrotarytorquevalueismaintainedunlessthemaximumset

rotaryRPMisexceeded,thenthetoquevalueisreduced.

5Thrustforce(Carriage

Thrust)

Thesetcarriagethrustismaintainedunlessthecarriagerate(speed)

isexceeded,thenthethrustforceisreduced.

8Thrustrate(Carriage

Rate/Speed)

Thesetcarriagerate(speed)ismaintainedunlessthemaximumset

carriagethrustisexceeded,thenthespeedisreduced.

PushtheXbuttontoreturntotheMainInformationScreen(page2).

DeactivatingCruise

Pushthecruisebuttontodeactivatethecruisemodeorpushthejoystickasfollows:

•ModeI:therightjoystickinanydirection

•ModeII:therightorleftjoystickinforwardorreverse.

Note:Thesettingsresetwhenthekeyisturnedofforwhenyouswitchtocarvemode.

ResumingCruise

Pushthecruisebuttononthejoysticktoresumethefunctionswiththesamesettings.

Note:Thesettingsresetwhenthekeyisturnedofforwhenyouswitchtocarvemode.

CarveModeandScreen

Carvemodeisidentiedbythisicon:

Carvemodecanonlybesetinthrust,notpullback.

AccessingtheCarveScreen

Pushthecarvebuttononthejoystick(Figure12)orpushbutton4onthehomescreentoaccessthecarve

screen.

g298903

Figure12

Pushbutton4toswitchbetweencruiseandcarvemodes.

ActivatingCarve

1.Positionthedrillbitinthedirection(clockposition)thatyouneedtosteer/carve.

2.Returnthejoystickstotheneutralposition.

3.Accessthecarvescreenusingthedisplay.

4.Pushbutton2toselectthesweepangle.Usebuttons6and7toadjustthelevel.

5.Settherotationspeed,rotarytorque,andthrustforceusingthecarvescreenonthedisplay.

6.Pushthecarvebuttononthejoystick(Figure12).

Note:Thedrillstringshouldstarttorotatebackandforth.

7.Pushbutton8toaccessthethrustsetting.

Note:Theiconturnsgreenandagreencirclehighlightstheoptionyouselect(Figure13).

8.Pushbutton6toslowlyincreasethethrustratetothedesiredsetting.

9.Pushbutton6or7toincreaseordecreasethevalueoftheselectedsetting.

g291902

Figure13

Thefollowingtabledescribesthefunctionvaluesaffectedwhenanotherfunctionisgivenpriority.

Thepriorityisthefunctionwiththehighestvalue,notthevalueselectedinthescreen.

Allvaluesaredependentontheavailableenginehorsepower.

ButtonPriorityIconDescription

1Piperotationspeed

(RotaryRPM)

ThesetrotaryRPMismaintainedunlessthesetrotarytorqueis

exceeded,thentherotaryrpmisreduced.

Whennotdrilling:changethearcangledegree.Thearcangle

willincreaseordecreaseby18°.

2SweepangleWhenactivelydrilling:changethecenterofthepiperotation.

Button6isclockwise.Button7iscounterclockwise.Thepipe

adjustsby18°clockwiseorcounterclockwiseforeachbuttonpress.

3RotarytorqueThesetrotarytorquevalueismaintainedunlessthemaximumset

rotaryRPMisexceeded,thenthetoquevalueisreduced.

5Thrustforce(Carriage

thrust)

Thesetcarriagethrustismaintainedunlessthecarriagerate(speed)

isexceeded,thenthethrustforceisreduced.

8Thrustrate(Carriage

Rate/Speed)

Thesetcarriagerate(speed)ismaintainedunlessthemaximumset

carriagethrustisexceeded,thenthespeedisreduced.

PushtheXbuttontoreturntotheMainInformationScreen(page2).

DeactivatingCarve

Pushthecarvebuttontodeactivatethecarvemodeorpushthejoystickasfollows:

•ModeI:therightjoystickinanydirection

•ModeII:therightorleftjoystickinforwardorreverse.

Note:Thesettingsresetwhenthekeyisturnedofforwhenyouswitchtocruisemode.

ResumingCarve

Pushthecarvebuttononthejoysticktoresumethefunctionswiththesamesettings.

Note:Thesettingsresetwhenthekeyisturnedofforwhenyouswitchtocruisemode.

SmartTouch™Home

Screen

SmartTouchmodeallowstheoperatortoloadand

unloadpipesfromthepipeboxwithlessjoystick

operationtoreduceoperatorfatigue.

UsetheCarriageSettingsScreen(page17)toturn

SmartTouchmodeonandoff.

Note:ThePush/PullIconhasagreenbackground

whenSmartT ouchmodeisonandaribbonappears

atthebottomofthescreenshowingasequenceof

thesteps.

Important:NeverswitchbetweenPush/Pull

modesduringthechosenoperation.Useneutral

(manual)modetoswitchbetweenPush/Pull;refer

toCarriageSettingsScreen(page17)toturn

SmartTouchmodeoff.

PullingPipeinSmartTouchMode

StarttheSmartTouchmodewiththecamassembly

intheparkposition.

g236957

Figure14

1.Gotothepreviousstep2.Gotothenextstep

1.Pushbutton1toselectthepullpipeoption

(Figure15).

2.Pushbuttons2and3toselecttherowwhere

youwanttoplacethepipe(Figure15).

g238157

Figure15

1.Pullpipe2.Selectpiperow

3.Holdthelowerrightbuttonontheleftjoystick

(Figure14)untilthedisplaymovestobox2

(Figure16)andtheelevatorlowers,thecam

assemblyrotatestowardtheoperatorstation,

andthearmsfullyextend(Figure17).

g236958

Figure16

g239743

Figure17

4.Releasethebuttontoproceedtothenextstep

inthesequence(Figure18).

g236959

Figure18

5.Breakthepipeconnection;refertoRemoving

DrillPipesintheOperator’sManual.

6.Holdthelowerleftbuttonontheleftjoystick

togripthepipe(Figure19andFigure20)and

releasethebutton.

g238156

Figure19

g210519

Figure20

7.Holdthelowerrightbuttonontheleftjoystick

(Figure14)untilthearmsfullyretract(Figure

22).

g236960

Figure21

g210521

Figure22

8.Releasethebuttontoproceedtothenextstep

inthesequence(Figure23).

g236961

Figure23

9.Holdthelowerrightbuttonontheleftjoystick

(Figure14)untilthecamassemblyrotatestothe

selectedrowunderthepipebox(Figure24).

g210523

Figure24

10.Releasethebuttontoproceedtothenextstep

inthesequence(Figure25).

g236962

Figure25

11.Holdthelowerrightbuttonontheleftjoystick

(Figure14)untilthedisplaymovestobox1

andtheelevatorputsthepipebackinthepipe

boxandthecamrotatestothehomeposition

(Figure26).

g210525

Figure26

12.Releasethebuttontostartthepull-pipeprocess

again.
