Raven AccuBoom Manuel utilisateur

SpraCoupe 7460/7660 AccuBoom™

Installation Manual

P/N 016-1001-077 Rev C 04/16 E17443

While every effort has been made to ensure the accuracy of this document,

Raven Industries assumes no responsibility for omissions and errors. Nor is any

liability assumed for damages resulting from the use of information contained

herein.

Raven Industries shall not be responsible or liable for incidental or consequential

damages or a loss of anticipated benefits or profits, work stoppage or loss, or

impairment of data arising out of the use, or inability to use, this system or any of

its components. Raven Industries shall not be held responsible for any

modifications or repairs made outside our facilities, nor damages resulting from

inadequate maintenance of this system.

As with all wireless and satellite signals, several factors may affect the availability

and accuracy of wireless and satellite navigation and correction services (e.g.

GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the

accuracy, integrity, continuity, or availability of these services and cannot

guarantee the ability to use Raven systems, or products used as components of

systems, which rely upon the reception of these signals or availability of these

services. Raven Industries accepts no responsibility for the use of any of these

signals or services for other than the stated purpose.

Disclaimer

Table of Contents

Manual No.016-1001-077 i

Chapter 1 Important Safety Information................................................. 1

Important Safety Information ..................................................................................................... 1

Chapter 2 Introduction............................................................................. 3

Introduction ............................................................................................................................... 3

Recommendations .............................................................................................................. 3

Tools Needed ...................................................................................................................... 4

Preparing for Installation ..................................................................................................... 4

Point of Reference ............................................................................................................... 4

AccuBoom Kit Contents ............................................................................................................ 4

Chapter 3 AccuBoom Installation........................................................... 7

Install the AccuBoom Node .......................................................................................................7

Install the AccuBoom Harness Cable ........................................................................................ 8

Install the Power Connection ............................................................................................... 8

Connect the Harness to the Machine .................................................................................. 9

Chapter 4 Section Mapping Setup ........................................................ 11

Envizio Pro ............................................................................................................................. 11

Viper Pro ................................................................................................................................ 12

Chapter 5 Troubleshooting ................................................................... 13

Table of Contents

ii SpraCoupe 7460/7660 AccuBoom Installation Manual

CHAPTER

Manual No. 016-1001-077 1

C hapt er 1

Important Safety

Information

Important Safety Information

Read this manual and the operation and safety instructions included with your implement and/or controller

carefully before installing the AccuBoom™ system.

•Follow all safety information presented within this manual.

•If you require assistance with any portion of the installation or service of your Raven equipment, contact

your local Raven dealer for support.

•Follow all safety labels affixed to the AccuBoom system components. Be sure to keep safety labels in good

condition and replace any missing or damaged labels. To obtain replacements for missing or damaged

safety labels, contact your local Raven dealer.

When operating the machine after installing AccuBoom, observe the following safety measures:

•Be alert and aware of surroundings.

•Do not operate AccuBoom or any agricultural equipment while under the influence of alcohol or an illegal

substance.

•Remain in the operator’s position in the machine at all times when AccuBoom is enabled.

•Disable AccuBoom when exiting from the operator's seat and machine.

•Do not drive the machine with AccuBoom enabled on any public road.

•Determine and remain a safe working distance from other individuals. The operator is responsible for

disabling AccuBoom when the safe working distance has been diminished.

•Ensure AccuBoom is disabled prior to starting maintenance work on AccuBoom or the machine.

•Always verify that the power leads are connected to the correct polarity as marked. Reversing the power

leads could cause severe damage to the equipment.

•Ensure that the power cable is the last cable to be connected.

NOTICE

CAUTION

Chapter 1

2 SpraCoupe 7460/7660 AccuBoom Installation Manual

CHAPTER

Manual No. 016-1001-077 3

C hapt er 2

Introduction

Congratulations on your purchase of the Raven AccuBoom system! This system is designed to provide

accurate and cost-efficient application control by avoiding no-spray zones and eliminating wasteful overlaps.

This manual applies to the following machines. For future reference, write your serial number in the space

below.

MAKE: SpraCoupe

MODEL: 7460/7660

YEAR: 2010 - 2011

SERIAL NUMBER:

FIGURE 1. SpraCoupe 7660

Recommendations

Raven Industries recommends the following best practices when installing the AccuBoom system:

•Use part numbers to identify parts.

•Do not remove the plastic wrap from a part until it is necessary for installation.

Chapter 2

4 SpraCoupe 7460/7660 AccuBoom Installation Manual

Tools Needed

The following tools are recommended for installation of the AccuBoom system:

•SAE standard-sized wrenches

•Cable ties

•Set of tools

Preparing for Installation

Before installing AccuBoom, park the machine where the ground is level, clean, and dry. Leave the machine

turned off for the duration of the installation process.

During the installation process, follow good safety practices. Be sure to carefully read the instructions in this

manual as you complete the installation process.

Point of Reference

The instructions in this manual assume that you are standing behind the machine, looking toward the cab.

AccuBoom Kit Contents

This section contains a list of the components that are included in the AccuBoom kit. Before beginning the

AccuBoom installation, compare the items in the AccuBoom kit with the components on this list. If you have

questions about the kit, contact your local Raven dealer.

Important: In addition to the following kit components, an AccuBoom CAN combo node

(P/N 063-0172-714) and mounting kit (P/N 117-0171-342) is required for the

operation of the AccuBoom system.

TABLE 1. AccuBoom Installation Kit (P/N 117-1004-077)

Picture Item Description Part Number Qty.

Not Pictured Manual - SpraCoupe 7460/7660 AccuBoom

Installation 016-1001-077 1

Cable - 7000 Series SpraCoupe CAN

AccuBoom Combo Node 115-1001-040 1

Bolt - 5/16”-18 x 1” Hex 311-0054-105 2

Manual No. 016-1001-077 5

Introduction

Nut - 5/16”-18 Nylon Lock 312-4000-059 2

Washer - 5/16” Flat 313-2300-011 2

TABLE 1. AccuBoom Installation Kit (P/N 117-1004-077)

Picture Item Description Part Number Qty.

Chapter 2

6 SpraCoupe 7460/7660 AccuBoom Installation Manual
