Titan TTB883ROU Manuel utilisateur
Original Instructions_MNL_TTB883ROU_(EN)_V01_211229
WARNING! Read the instructions before using the product!
TTB883ROU
EAN: 5059340253664
EN
2
TTB883ROU
Let's
get started...
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.
Getting started... 02
Safety 03
Symbols 14
Your product 15
Technical and legal information 16
Before you start 19
In more detail... 26
Product functions 27
Operation 34
Care and maintenance 36
Trouble shooting 39
Guarantee 40
Declaration of conformity 41
33
Getting started...
TTB883ROU EN
Safety warnings
General power tool safety warnings
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to
follow all instructions listed below may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for
future reference. The term “power tool” in
the warnings refers to your mains-operated
(corded) power tool or battery operated
(cordless) power tool.”
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
Safety
44
Getting started...
TTB883ROU
EN
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
Safety warnings
Safety
55
Getting started...
TTB883ROU EN
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non- skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
3. Prevent unintentional starting. Ensure the
switch is in the off- position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing away from
moving parts. Loose clothes, jewellery or longhair
can be caught in moving parts.
Safety
66
Getting started...
TTB883ROU
EN
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the rate
for which it was designed.
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
4. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
Safety warnings
Safety
77
Getting started...
TTB883ROU EN
with the power tool or these instructions to
operate the power tool. Power tools are dangerous
in the hands of untrained users.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
Service
1. Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
Safety
88
Getting started...
TTB883ROU
EN
Additional safety warnings for router
1. Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact its own cord. Cutting a “live”
wire may make exposed metal parts of the power tool
“live” and could give the operator an electric shock.
2. Use clamps or another practical way to secure
and support the workpiece to a stable platform.
Holding the workpiece by hand or against your body
leaves it unstable and may lead to less of control.
• Always wear a dust mask and ear protection when
using this power tool.
• Use only bits which are designed for this router.
• Use only sharp bits that are not chipped or cracked.
Blunt bits will cause stalling.
• Secure small pieces of wood firmly before working.
Never hold them in your hand.
• Before starting up, check that the bit is firmly
positioned and secured in the collet.
• The maximum indicated rotation speed of the milling
bit must not be exceeded.
• Routing must always be carried out against the
direction of rotation (bit-rotation) of the bit.
Safety warnings
Safety
99
Getting started...
TTB883ROU EN
• The bit must be running at full speed before lowering
into the work-piece.
• When operating the machine, take great care and
always hold the router handles firmly with both
hands. Always keep secure footing when working.
• Beware of the torque reaction of the machine,
particularly if the bit becomes jammed in the
workpiece.This could cause the tool to turn in the
opposite direction to the direction of bit rotation.
• On completion of work, allow the machine to slide
back to its raised position by releasing the handle.
Keep the machine under control until the bit has
stopped rotating.
• Make yourself familiar with your working area and
be alert for possible hazards which you might not
hear due to machine noise.
• Caution: Allow for run down time of bit after turning
router off. Wait for the machine to come to a
complete stop before removing from the work piece.
• Never slow the router down with your hands.
• Do not touch the bit immediately after operation; it
may be extremely hot and could burn you.
•
Never stop the router by applying lateral pressure to the bit.
• Do not force the router. Your router will do a better
job if you take it slowly.
Safety
1010
Getting started...
TTB883ROU
EN
• Avoid cutting nails and screws. Inspect timber and
remove all nails and screws before cutting.
• In the event of an electrical or mechanical
malfunction, immediately switch off the router and
disconnect the power lead from the mains supply.
• Never use fingers to clear waste material or blockages.
• Turn the router off immediately if the bit gets jammed.
• Ensure the air vents are always unobstructed and
clear. Clean them if necessary with a soft brush.
Blocked air vents may lead to overheating and
damage the product.
• Always keep the power cord behind the tool.
Additional safety warning for construction dust
The updated Control of Substances Hazardous to
Health Regulations 1st October 2012 now also targets
to reduce the risks associated with silica, wood and
gypsum dusts.
Construction workers are one of the at-risk groups
within this because of the dust that they breathe: silica
dust is not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts
in things like sand, sandstone and granite. It is also
commonly found in many construction materials such
Safety warnings
Safety
