Notational Conventions

Preface



About This Manual

This manual describes the operation of the TAS5066-5111D6EVM evaluation

module from Texas Instruments.

How to Use This Manual

This document contains the following chapters:

-Chapter 1 — Overview

-Chapter 2 — System Interfaces

-Chapter 3 — Protection

Information about Cautions and Warnings

This document may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Trademarks

Related Documentation from Texas Instruments

The following table contains a list of data manuals that have detailed descrip-

tions of the integrated circuits used in the design of the

TAS5066−5111D6EVM. The data manuals can be obtained at the URL

http://www.ti.com.

Part Number Literature Number

TAS5066PAG SLES089

TAS5111DAD SLES049

SN74LVC1G08 SCES217O

SN74LVC1G126 SCES224J

LMV331I SLCS136K

LM317M SLVS297I

TPS76433 SLVS180B

TPS3801K33 SLVS219B

Additional Documentation

-TAS5066−5111D6EVM Application Report − SLEA033

-PC Configuration Tool for TAS50XX (DAS TCT 50xx – version 3.1 or later)

-General Application Notes

FCC Warning

This equipment is intended for use in a laboratory test environment only. It gen-

erates, uses, and can radiate radio frequency energy and has not been tested

for compliance with the limits of computing devices pursuant to subpart J of

part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other en-

vironments may cause interference with radio communications, in which case

the user at his own expense will be required to take whatever measures may

be required to correct this interference.

Trademarks

TI, EquibitTM and PurePath DigitalTM are trademarks of Texas Instruments.

Contents

vii



1 Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 TAS5066-5111D6EVM Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 PCB Key Map 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 System Interfaces 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 PSU Interface (J901) 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 PSU Control Interface (J902) 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Loudspeaker Connectors (J100 − J600) 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Control Interface (J50) 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 Digital Audio Interface (J51) 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.6 PWM Timing, Interchannel Delay Registers 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Protection 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Short Circuit Protection and Fault Reporting Circuitry 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Device Fault Reporting 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

viii



1−1 Complete PurePath Digital System 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1−2 Physical Structure for the TAS5066-5111D6EVM 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−1 Recommended Power-Up Sequence 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 J901 and J903 Pin Numbers (PCB Connector Top View) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . .

2−3 J902 Pin Numbers (PCB Connector Top View) 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−4 J100 − J600 Pin Numbers (PCB Connector Top View) 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .



2−1 Recommended Power Supplies 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 J901 Pin Description 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−3 J903 Pin Description 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−4 J902 Pin Description 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−5 J100− J600 Pin Description 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−6 J50 Pin Description 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−7 J51 Pin Description 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−8 Clock Rates 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−9 Recommended Interchannel Delay Register Values (based on EVM designs) 2-8. . . . . . . . .

3−1 TAS5111 Error Signal Decoding 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Overview



The TAS5066−5111D6EVM PurePath Digitaltcustomer evaluation module

demonstrates two integrated circuits TAS5066 and TAS5111DAD from Texas

Instruments (TI).

The TAS5066 is a high-performance 24-bit six-channel digital pulse width

modulator (PWM) based on EquibitTM technology. The TAS5066 has a wide

variety of serial input (I@S) options including right justified, left justified, and

DSP data formats. It accepts I@S data with sample rates up to 192 kHz.

TAS5111 is a high-performance digital amplifier power stage designed to drive

a 4-Ohm loudspeaker up to 85 W. It contains integrated gate-drivers, four

matched and electrically isolated enhancement-mode N-channel power

DMOS transistors and protection / fault-reporting circuitry.

The TAS5066−5111D6EVM, together with a TI input board, is a complete digi-

tal audio amplifier system that includes digital input (S/PDIF), analog input, in-

terface to PC, digital volume control, and failure protection. The system was

design for home theater applications such as DVD minicomponent systems,

home theater in a box (HTIB), DVD receiver, A/V receiver, or TV sets.

Topic Page

1.1 TAS5066-5111D6EVM Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 PCB Key Map 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

TAS5066-5111D6EVM Features

1-2

1.1 TAS5066-5111D6EVM Features

-6-channel PurePath Digitaltevaluation module

-Self-contained protection system (short circuit and thermal)

-Standard I2S and I2C/control connector for TI input board

-Double-sided plated-through PCB layout

Figure 1−1.Complete PurePath DigitalESystem

Control interface

6 channel

analog input

I2C busPC interface

I2S bus

Optical and

coaxial

S/PDIF input

TAS5066–5111D6EVM

module

Subwoofer

line out

Power

supply

Example

TI input–PC board

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Texas Instruments Matériel informatique

Texas Instruments

Texas Instruments CC1000PP Manuel utilisateur

Texas Instruments

Texas Instruments TSC2007EVM Manuel utilisateur

Texas Instruments

Texas Instruments MSP-FET430 Manuel utilisateur

Texas Instruments

Texas Instruments Serial Programming Adapter MSP430 Manuel utilisateur

Texas Instruments

Texas Instruments BoosterPack BOOSTXL-ADS7142-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments AM1808 Manuel utilisateur

Texas Instruments

Texas Instruments TPS3813 Q1EVM Series Manuel utilisateur

Texas Instruments

Texas Instruments TMS320TCI6482 Mode d’emploi

Texas Instruments

Texas Instruments OMAP5910 Manuel utilisateur

Texas Instruments

Texas Instruments CC3100 SimpleLink Manuel utilisateur

Texas Instruments

Texas Instruments BT-MSPAUDSOURCE-RD Manuel utilisateur

Texas Instruments

Texas Instruments DRV8811EVM Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC2640 Manuel utilisateur

Texas Instruments

Texas Instruments PGA411-Q1 EVM Manuel utilisateur

Texas Instruments

Texas Instruments MSPM0 Manuel utilisateur

Texas Instruments

Texas Instruments 2000 series Manuel utilisateur

Texas Instruments

Texas Instruments bq24650EVM Manuel utilisateur

Texas Instruments

Texas Instruments MSP430x1xx Manuel utilisateur

Texas Instruments

Texas Instruments TMS320*2801 Series Manuel utilisateur

Texas Instruments

Texas Instruments Sub-1 GHz Sensor-to-Cloud Linux E14 Kit Manuel utilisateur

Texas Instruments

Texas Instruments LDC3114-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments TPA2013D1 Manuel utilisateur

Texas Instruments

Texas Instruments CC2545 Manuel utilisateur

Texas Instruments

Texas Instruments C2000 Piccolo LaunchPad Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
