Texas Instruments LM5168FEVM Manuel utilisateur

User’s Guide

LM5168FEVM EVM User's Guide

ABSTRACT

The LM5168FEVM is a 115-V DC/DC fly-buck regulator that employs synchronous rectification to achieve high

conversion efficiency in a small footprint. The EVM operates over a wide input voltage range of 20 V to 115

V (120-V absolute maximum) to provide a regulated 10-V output at up to 0.25 A with a 750-kHz switching

frequency. An additional 10-V floating output is provided through the fly-buck topology. The output voltage has

better than 1.5% set-point accuracy and is adjustable using an external resistor divider. The module design

uses the LM5168F-Q1 synchronous buck converter with wide input voltage range, wide duty-cycle range,

integrated high-side and low-side power MOSFETs, advanced overcurrent protection, and precision enable. With

AEC-Q100 grade 1 automotive qualification, the LM5168F-Q1 is rated to operate over a junction temperature

range of –40°C to +150°C.

Table 1-1. EVM Configuration

EVM CONVERTER IC PACKAGE

LM5168FEVM LM5168F-Q1 8-pin SO package with PowerPAD (4.89 mm × 3.90 mm)

Table of Contents

1 General TI High Voltage Evaluation User Safety Guidelines.............................................................................................. 3

2 EVM Characteristics............................................................................................................................................................... 5

3 LM5168FEVM Evaluation Module..........................................................................................................................................6

3.1 Quick Start Procedure........................................................................................................................................................6

3.2 Detailed Descriptions......................................................................................................................................................... 7

4 Schematic................................................................................................................................................................................8

5 PCB Layout..............................................................................................................................................................................9

6 Bill of Materials......................................................................................................................................................................11

7 Performance Curves.............................................................................................................................................................13

List of Figures

Figure 3-1. LM5168FEVM Top View............................................................................................................................................6

www.ti.com Table of Contents

SNVU819 – NOVEMBER 2021

Submit Document Feedback

LM5168FEVM EVM User's Guide 1

Figure 4-1. LM5168FEVM Schematic..........................................................................................................................................8

Figure 5-1. Top Layer...................................................................................................................................................................9

Figure 5-2. Mid-Layer 1 Ground Plane........................................................................................................................................ 9

Figure 5-3. Mid-Layer 2 Routing................................................................................................................................................ 10

Figure 5-4. Bottom Layer........................................................................................................................................................... 10

Figure 7-1. Efficiency................................................................................................................................................................. 13

Figure 7-2. Load Regulation...................................................................................................................................................... 13

Figure 7-3. Load Regulation...................................................................................................................................................... 13

Figure 7-4. Typical Switching Waveform....................................................................................................................................13

Figure 7-5. Typical Start-Up Waveform......................................................................................................................................13

Figure 7-6. Typical Shutdown Waveform...................................................................................................................................13

List of Tables

Table 1-1. EVM Configuration......................................................................................................................................................1

Table 2-1. LM5168FQEVM Electrical Performance Characteristics............................................................................................ 5

Table 6-1. LM5168FEVM Bill of Materials ................................................................................................................................. 11

Trademarks

PowerPAD™ is a trademark of Texas Instruments.

All trademarks are the property of their respective owners.

Trademarks www.ti.com

2LM5168FEVM EVM User's Guide SNVU819 – NOVEMBER 2021

Submit Document Feedback

1 General TI High Voltage Evaluation User Safety Guidelines

WARNING

Always follow TI’s set-up and application instructions, including use of all interface components within their

recommended electrical rated voltage and power limits. Always use electrical safety precautions to help ensure

your personal safety and the safety of those working around you. Contact TI’s Product Information Center http://

support.ti.com for further information.

Save all warnings and instructions for future reference.

Failure to follow warnings and instructions may result in personal injury, property damage, or death due

to electrical shock and/or burn hazards.

The term TI HV EVM refers to an electronic device typically provided as an open-framed, unenclosed printed-

circuit board assembly. It is intended strictly for use in development laboratory environments, solely for qualified

professional users having training, expertise, and knowledge of electrical safety risks in development and

application of high-voltage electrical circuits. Any other use and/or application are strictly prohibited by Texas

Instruments. If you are not suitably qualified, you should immediately stop from further use of the HV EVM.

•Work Area Safety:

– Maintain a clean and orderly work area.

– A qualified observer or observers must be present any time circuits are energized.

– Effective barriers and signage must be present in the area where the TI HV EVM and its interface

electronics are energized, indicating operation of accessible high voltages can be present, for the purpose

of protecting inadvertent access.

– All interface circuits, power supplies, evaluation modules, instruments, meters, scopes, and other related

apparatus used in a development environment exceeding 50 VRMS/75 VDC must be electrically located

within a protected Emergency Power Off (EPO) protected power strip.

– Use a stable and non-conductive work surface.

– Use adequately insulated clamps and wires to attach measurement probes and instruments. No freehand

testing whenever possible.

•Electrical Safety:

As a precautionary measure, it is always a good engineering practice to assume that the entire EVM can

have fully accessible and active high voltages.

– De-energize the TI HV EVM and all its inputs, outputs, and electrical loads before performing any

electrical or other diagnostic measurements. Confirm that TI HV EVM power has been safely de-

energized.

– With the EVM confirmed de-energized, proceed with required electrical circuit configurations, wiring,

measurement equipment hook-ups, and other application needs, while still assuming the EVM circuit and

measuring instruments are electrically live.

– When EVM readiness is complete, energize the EVM as intended.

WARNING

WARNING: While the EVM is energized, never touch the EVM or its electrical circuits as

they could be at high voltages capable of causing electrical shock hazard.

www.ti.com General TI High Voltage Evaluation User Safety Guidelines

SNVU819 – NOVEMBER 2021

Submit Document Feedback

LM5168FEVM EVM User's Guide 3

•Personal Safety:

– Wear personal protective equipment, for example, latex gloves, safety glasses with side shields, or both,

or protect EVM in an adequate lucent plastic box with interlocks from accidental touch.

•Limitation for Safe Use:

– EVMs are not to be used as all or part of a production unit.

Safety and Precautions

The EVM is designed for professionals who have received the appropriate technical training, and is designed

to operate from an AC power supply or a high-voltage DC supply. Please read this user's guide and the

safety-related documents that come with the EVM package before operating this EVM.

CAUTION

Do not leave the EVM powered when unattended.

WARNING

Hot surface! Contact may cause burns. Do not touch!

WARNING

High Voltage! Electric shock is possible when connecting board to live wire. Board should be handled with care by a

professional.

For safety, use of isolated test equipment with overvoltage and overcurrent protection is highly recommended.

General TI High Voltage Evaluation User Safety Guidelines www.ti.com

4LM5168FEVM EVM User's Guide SNVU819 – NOVEMBER 2021

Submit Document Feedback

2 EVM Characteristics

Unless otherwise specified, the following conditions apply: TA = 25ºC, IOUT1 = primary output current, IOUT2 =

secondary output current

Table 2-1. LM5168FQEVM Electrical Performance Characteristics

Parameter Test Conditions MIN TYP MAX UNITS

INPUT CHARACTERISTICS

Input voltage range, VVIN EVM input voltage operating range 20 48 115 V

Input voltage turn-on, VIN(ON)

Adjusted by EN/UVLO resistors

6.0 V

Input voltage turn-off, VIN(OFF) 5.6 V

Input voltage hysteresis, VIN(HYS) 0.4 V

Input current, no load, IIN(NL) IOUT = 0 A VIN = 48 V 13 mA

Input current, disabled, IIN(OFF) VEN/UVLO = 0 V, no EN divider VIN = 36 V 10 µA

OUTPUT CHARACTERISTICS

Output voltage, VOUT1 VIN = 48 V, IOUT1 = IOUT2 = 0A 10.0 V

Output voltage, VOUT2 VIN = 48 V, IOUT1=0 A, IOUT2 = 0A 10.0

Output current, IOUT1 VIN = 48 V, IOUT2 = 0 A 0.25 A

Output current, IOUT2 VIN = 48 V, IOUT1 = 0 A 0.25 A

Output voltage regulation, ΔVOUT1

Load regulation, VIN = 48 V IOUT1 = 0 A to 0.25

A, IOUT2 = 0 A

1 mV

Output voltage regulation, ΔVOUT2

Load regulation, VIN = 48 V IOUT1 = 0 A to 0.25

A, IOUT2 = 0 A

200

Output voltage regulation, ΔVOUT1

Load regulation, VIN = 48 V IOUT2 = 0 A to 0.25

A, IOUT1 = 0 A

Output voltage regulation, ΔVOUT2

Load regulation, VIN = 48 V IOUT2 = 0 A to 0.25

A, IOUT1 = 0 A

1000

Output voltage regulation, ΔVOUT1

Line regulation, IOUT1 = IOUT2

= 0 A

VIN = 24 V to 115 V 50

Output voltage regulation, ΔVOUT2

Line regulation, IOUT1 = IOUT2

= 0 A

VIN = 24 V to 115 V 750

Maximum output current from primary

output VIN = 48 V, IOUT2 = 0 A 0.27 A

Soft-start time, tSS 3.5 ms

SYSTEM CHARACTERISTICS

Switching frequency VIN = 36 V, IOUT1 = 0 A , IOUT2 = 0 A 730 kHz

Half-load efficiency IOUT1 = IOUT2 = 0.08 A VIN = 48 V 70%

Full load efficiency IOUT1 = IOUT2 = 0.125 A VIN = 48 V 76%

VIN = 60 V 72%

www.ti.com EVM Characteristics

SNVU819 – NOVEMBER 2021

Submit Document Feedback

LM5168FEVM EVM User's Guide 5

3 LM5168FEVM Evaluation Module

The LM5168FEVM is configured to deliver a regulated 10-V output, 0.25 A at 750-kHz switching frequency, and

an additional 10-V floating output. The LM5168 uses a COT control architecture, with input voltage feedforward

to provide a constant frequency regulator with tightly regulated output voltage. This type of control requires

adequate voltage ripple at the FB input to achieve stable regulation. The LM5168FEVM is set up with type III

ripple injection to minimize the output voltage ripple while ensuring a stable regulator. The LM5168FEVM also

provides the option to use type I or type II ripple injection. See the LM516x-Q1 0.65/0.3-A, 120-V Step-Down

Converter w/ Fly-Buck Converter Capability Data Sheet for more information. An overall view of the LM516FEVM

and the schematic are shown in Figure 3-1 and Figure 4-1, respectively.

3.1 Quick Start Procedure

1. Connect the input voltage supply to the VIN connector (+ and –).

2. Connect the load or loads to the VOUT and the VOUT2 connectors (+ and –).

3. Set the input supply voltage to an appropriate level between 20 V to 115 V.

4. Turn on the power supply. The EVM powers up and provides VOUT = 10 V, and VOUT2 = 10 V.

See Figure 3-1 for the location of the connectors.

CAUTION

Caution Hot surface.

Contact may cause burns.

Do not touch.

Figure 3-1. LM5168FEVM Top View

LM5168FEVM Evaluation Module www.ti.com

6LM5168FEVM EVM User's Guide SNVU819 – NOVEMBER 2021

Submit Document Feedback

3.2 Detailed Descriptions

This section describes the connectors and the test points on the EVM and how to properly connect, set up, and

use the LM5168FEVM EVM. See Figure 3-1 for location of connectors and jumpers.

VOUT Output voltage of the converter

VOUT screw terminal connector. Apply load to this connector (+ and –). The VOUT test point is

used to monitor output voltage.

VOUT2 Secondary output voltage of the converter

VOUT2 screw terminal connector. One side of this output is connected to the primary ground

(GND) through a tie resistor, Rtie (R12). This resistor can be removed for a true floating voltage

source. Apply load to this connector (+ and –).

GND Ground of the converter

GND and GNDS test points. Used as ground test points for the EVM.

VIN Input voltage to the converter

VIN screw terminal connector. Apply input voltage to this connector (+ and –). The VIN test point is

used to monitor input voltage.

VINEMI Input voltage to input filter of the converter

If it is desired to use the built-in EMI filter on the EVM, then connect the input supply to the VINEMI

screw terminal connector (+ and –).

Input

Filter

EMI mitigation

An input EMI filter is provided on the EVM. Note L2 and C18 are not populated and must be

installed for the EMI filter to operate. Also, note that the maximum input voltage to the filter is 100

VDC.

EN/UVLO

Jumper

Set EN/UVLO pin options

Use this jumper to enable/disable the EVM. The resistors connected to this pin set the input UVLO

thresholds. Input UVLO thresholds are set to approximately 6 V and 5.6 V. These levels can be

changed by changing the values of R5 and R7. For external control of the device, these resistors

should be removed and the control signal applied to the center pin of the header. Note that for

accurate shutdown current measurement, these resistors must also be removed and the EN input

(center pin) grounded.

1. Jumper open (default setup): Device starts up and shuts down with UVLO.

2. Center pin connected to ON: Device starts up and shuts down without UVLO.

3. Center pin connected to OFF: Device is off.

PGOOD The PGOOD header used as a test point to monitor the power-good indicator. This flag indicates

whether the output voltage has reached its regulation level. PGOOD is an open-drain output that is

tied to VOUT through a 100-kΩ, resistor R10.

www.ti.com LM5168FEVM Evaluation Module

SNVU819 – NOVEMBER 2021

Submit Document Feedback

LM5168FEVM EVM User's Guide 7

4 Schematic

Figure 4-1. LM5168FEVM Schematic

Schematic www.ti.com

8LM5168FEVM EVM User's Guide SNVU819 – NOVEMBER 2021

Submit Document Feedback

5 PCB Layout

Figure 5-1 through Figure 5-4 show the board layout for the LM5168FEVM.

The 8-pin SO PowerPAD™ package offers an exposed thermal pad, which must be soldered to the copper

landing on the PCB for optimal thermal performance. The PCB consists of a 4-layer design. There are 2-oz

copper planes on the top and bottom and 1-oz copper mid-layer planes to dissipate heat with an array of thermal

vias under the thermal pad to connect to all four layers.

Figure 5-1. Top Layer

Figure 5-2. Mid-Layer 1 Ground Plane

www.ti.com PCB Layout

SNVU819 – NOVEMBER 2021

Submit Document Feedback

LM5168FEVM EVM User's Guide 9

Figure 5-3. Mid-Layer 2 Routing

Figure 5-4. Bottom Layer

PCB Layout www.ti.com

10 LM5168FEVM EVM User's Guide SNVU819 – NOVEMBER 2021

Submit Document Feedback

Table des matières

Autres manuels Texas Instruments Matériel informatique

Texas Instruments

Texas Instruments AM57 Series Manuel utilisateur

Texas Instruments

Texas Instruments TLV320AIC12KEVMB-K Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC2651R3SIPA Manuel utilisateur

Texas Instruments

Texas Instruments LM38020EVM Manuel utilisateur

Texas Instruments

Texas Instruments LM95172EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS65941213-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments PGA2500EVMV2 Manuel utilisateur

Texas Instruments

Texas Instruments PGA309EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS7H4003EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS40193EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments TMDSCNCD2800157 Manuel technique

Texas Instruments

Texas Instruments LAUNCHXL-CC2650 Manuel utilisateur

Texas Instruments

Texas Instruments DS90Ux929-Q1EVM Manuel utilisateur

Texas Instruments

Texas Instruments INA234EVM Manuel utilisateur

Texas Instruments

Texas Instruments DP83867E Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6201 Manuel utilisateur

Texas Instruments

Texas Instruments THS3115 EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320 Series Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink Wi-Fi CC3 20 Series Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC3200 Wi-Fi Manuel utilisateur

Texas Instruments

Texas Instruments CC3100 SimpleLink Manuel utilisateur

Texas Instruments

Texas Instruments DRV8811EVM Manuel utilisateur

Texas Instruments

Texas Instruments TLV320AIC3101EVM Manuel utilisateur

Texas Instruments

Texas Instruments EDMA3 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
