Tecnoware ERA PLUS 1600 SCHUKO Manuel utilisateur

Uninterruptible Power Supply

ERA PLUS 1.600

ERA PLUS 2.000

ERA PLUS 2.600

User’s manual



UPS ERA PLUS 1.600 –2.000 –2.600 1User’s manual

Index

Safety Warnings ................................................................................ 2

1Introduction................................................................................. 3

2General Characteristics ................................................................... 4

3Receipt and site selection ................................................................ 4

4EXTERNAL DESCRIPTION .................................................................. 5

4.1 Front Panel .............................................................................5

4.1.1 Leds and ON/OFF Button .................................................................6

4.2 Rear Side................................................................................7

5Electrical Installation and First Start Up............................................... 8

6Functioning ................................................................................. 9

6.1 Normal Mode ...........................................................................9

6.2 Battery Mode ...........................................................................9

6.3 Low Battery and Automatic Restart.................................................9

6.4 Load Control.......................................................................... 10

6.5 Fault Condition ...................................................................... 10

7Communication Interfaces .............................................................. 10

8Technical Characteristics................................................................ 11

9Maintenance ............................................................................... 12

9.1 UPS Cleaning ......................................................................... 12

9.2 Battery ................................................................................ 12

9.3 Battery Replacement ............................................................... 12

9.4 Operator Safety...................................................................... 13

10 Troubleshooting ........................................................................... 14

Conformity to the European Directives ................................................... 15

Product Disposal............................................................................... 15

Lead Batteries ................................................................................. 15

All trademarks are property of their respective owners.

TECNOWARE s.r.l.

Via Montetrini, 2E –Loc. Molino del Piano –50065- Pontassieve (FI) –Italy

www.tecnoware.com

Edition: January 2018 –version: 1.1

No part of this manual may be reproduced, even partially, without the

authorisation of TECNOWARE s.r.l.

TECNOWARE s.r.l. reserves the right to change specifications at any time

and without notice.

User’s manual 2UPS ERA PLUS 1.600 –2.000 –2.600

Safety Warnings

Read this manual carefully and completely before installing and using the TECNOWARE ERA

PLUS Uninterruptible Power Supply, which, from here after, will also be referred to as UPS.

This manual should be kept close to the UPS and read before the UPS is installed and used.

The UPS must be used only by properly trained personnel. To ensure correct and safe

operations, it is necessary that operators and maintenance personnel observe the general

safety Standards as well as the specific instructions included in this manual.

Risk of electric shock: do not remove the cover. The UPS contains internal parts, which are at a

high Voltage and are potentially dangerous, capable of causing injury or death by electric

shock.

There are no internal parts in the UPS, which are user serviceable. Any repair or maintenance

work must be performed exclusively by qualified technical personnel authorized by

TECNOWARE. TECNOWARE declines any responsibility if this warning is disregarded.

Warning to the technical personnel authorized for Service: since internal components are

connected to the batteries, they will remain powered, and therefore dangerous, even after the

UPS has been disconnected from AC power mains. Before any repair or maintenance work,

disconnect the batteries, by removing the positive cable (red colour) from the positive pole of

the battery.

It is compulsory to ground the UPS according to Safety Standards. The AC mains power supply

socket used to power the UPS must have an earth connection.

In the event of AC main power supply failure (when the UPS works in Battery mode), do not

unplug the power supply cable to the UPS to ensure earth continuity to the connected loads.

Since the AC mains power supply cable acts as a separation device, the AC mains power socket

used to supply the UPS and/or the rear side of the UPS must be accessible to easily disconnect

the cable in case of dangerous conditions.

Risk of electric shock at the Output lines when the UPS is ON.

Risk of electric shock at the Output lines while the unit is connected to the AC utility line.

Do not obstruct ventilation slots or holes and do not rest any object on top of the UPS.

Do not insert objects or pour liquids in the ventilation holes.

Install the UPS indoors, in a protected, clean and moisture-free environment.

Do not expose to the direct sun light.

Do not keep liquids, flammable gases or corrosive substances near the UPS.

UPS ERA PLUS 1.600 –2.000 –2.600 3User’s manual

1Introduction

ERA PLUS is a Line Interactive UPS (Uninterruptible Power Supply) specifically designed to protect your computer

from any type of irregularities in the AC line (such as black-outs, under or over voltages, micro-interruptions),

which often cause damage to your Hardware and Software.

Under normal AC line condition, ERA PLUS performs output voltage regulation and filters frequently occurring

electrical disturbances (such as transients, spikes, interferences, etc.), thus protecting all devices connected to

the outlets, and recharging the batteries in an ideal way. In case of anomaly to the AC line, the UPS continues

feeding the protected equipment.

ERA PLUS is equipped with USB interface which can be used to notify a power failure or a low battery condition

directly to a computer: this makes it possible to automatically save your data during an extended black-out with

the most widespread operating systems (Windows, Mac OS X, Linux, etc.).

Read this manual carefully before using the ERA PLUS; it includes important safety

warnings and useful advices for correct use and installation.

This manual is a guide that enables you to correctly install and use your ERA PLUS. This

manual includes important SAFETY instructions for the operator, for the UPS correct

installation, and gives useful advice on the product and battery maintenance. For any

type of problem, please refer to this manual before calling the customer service.

ERA PLUS is constantly being developed and improved: consequently, your unit may differ somewhat from the

description contained in this manual.

This manual includes the following models:

ERA PLUS 1.600 (1.6 KVA)

ERA PLUS 2.000 (2.0 KVA)

ERA PLUS 2.600 (2.6 KVA)

In this manual ERA PLUS will simply be referred to as UPS.

User’s manual 4UPS ERA PLUS 1.600 –2.000 –2.600

2General Characteristics

ERA PLUS has all the advanced features, which guarantee maximum reliability and safety:

All functions are controlled by a microprocessor, giving full guarantee of high reliability.

Output Voltage regulation through AVR (Automatic Voltage Regulation).

Overload protection both in normal mode and in battery mode.

High performance battery charger, which extends the battery medium life ensuring an optimal recharge.

Start up even if the electrical network is not available.

Automatic restart after an automatic shut down due to a low battery condition once the AC utility power

returns.

Adapts automatically to 50 or 60 Hz input frequency.

3 Leds to show the functioning modes, alarm and fault conditions.

Acoustic signals of various kinds indicating functioning modes and alarm/fault condition.

Communication with the computer through USB interface.

Protects and filters the telephone line.

Fast swappable battery.

High efficiency

Maximum reliability

Smart design and easy to use

3Receipt and site selection

Carefully remove the UPS from its packaging, and carry out a meticulous inspection. We recommend keeping the

original packaging in a secure place, in case you need to send the UPS for maintenance purposes. In case of

transport damage, notify the carrier and dealer immediately.

We recommend paying attention to the below points in order to choose a correct placement for your UPS:

The UPS is designed to operate in a protected environment (e.g. offices). We therefore recommend

installing it in a place with very little or no humidity, dust or smoke.

In all circumstances, see the “Technical Characteristics”chapter for environmental specifications and

check that the selected area meets these specifications.

During normal operation the UPS discharges a minimal amount of heat. So it is necessary to leave at least

20 cm of unobstructed space all around the UPS in order to keep it properly ventilated.

Do not obstruct ventilation holes.

Do not insert objects or pour liquids in the ventilation holes.

Do not rest any object on top of the UPS.

Do not keep liquids, flammable gases or corrosive substances near the unit.

Install the UPS on a properly tiled floor. Avoid the installation on a floor that is not tiled flat.

UPS ERA PLUS 1.600 –2.000 –2.600 5User’s manual

4EXTERNAL DESCRIPTION

4.1 Front Panel

The front panel informs the user about operating status, alarm conditions and measurements. Front panel shown

below consists of two parts:

1. 3 Leds that show the functioning modes, alarm and fault conditions.

2. ON/OFF button: enables the user to turn ON/OFF the UPS.

Figure 1 –Front panel

User’s manual 6UPS ERA PLUS 1.600 –2.000 –2.600

4.1.1 Leds and ON/OFF Button

Please refer to figure 2.

Figure 2 –LCD Display

1. Line LED: this (blue) led is always on in “LINE” mode.

2. Battery LED: this (yellow) led is on in “BATTERY” mode.

3. Fault LED: this FAULT led (red) switches on to indicate the excessive or the OVERLOAD condition or generic

“FAULT”.

4. ON/OFF Button: to turn ON and OFF the UPS.

UPS ERA PLUS 1.600 –2.000 –2.600 7User’s manual

4.2 Rear Side

Figure 2 –Rear Side

1. Grounded AC Input power socket: IEC C14 type; to connect the UPS to the AC utility line.

2. Input fuse: electrical specification: max current 10 A, voltage 250 V.

3. Grounded UPS Output receptacles: IEC C13 type, black colour, to supply critical loads.

4. Grounded (ONLY FILTERED) Output receptacles: IEC C13 type, red colour, to supply NON-critical loads.

5. Telephone protection (RJ11/RJ45 IN/OUT connectors): to protect and filter a phone line, an ADSL or a LAN

(TNV-3 type connections).

6. Computer Interface (USB connector):it is the communication USB port.

The 2 ONLY FILTERED Output receptacles (red colour, #4), protect only the devices

connected from overvoltages and disturbances of the AC line. Please connect ONLY the

NON-critical devices to the ONLY FILTERED Output receptacles

In case of anomaly to the AC line (black-out), ONLY the UPS Output receptacles (black

colour, #3) continue supplying the correct power to all connected equipment. Please

connect all the non-critical devices to the UPS Output receptacles.

UPS ERA PLUS 2.000

UPS ERA PLUS 2.600

User’s manual 8UPS ERA PLUS 1.600 –2.000 –2.600

5Electrical Installation and First Start Up

We advise you to follow the steps below explained for greater safety:

1. Switch off all the devices (Personal Computer or other electronic devices) that need to be supplied by the

UPS.

2. Connect the UPS Input socket to the AC line outlet Through the Personal Computer supplying cable. It is

mandatory to ground the AC line outlet according to the Safety Standards. Carefully check the grounding,

make sure that the utility power is available, and that its range falls within the UPS specifications (refer to

the “Specifications” chapter).

3. Press the ON/OFF button on the front panel: the UPS emits a brief acoustic signal, turns on the Leds, and

performs a functioning SELF-TEST. After some seconds the UPS starts to work in Normal mode: the Line Led

in blue color is on. Leave the UPS in Normal mode for at least 4 hours in order to completely recharge the

batteries.

4. Switch the UPS off (by pressing again the ON/OFF button).

5. Connect the devices to be supplied to the UPS outputs, by using only the included cables. Be sure all the

devices have the main switch in ON position.

6. Turn on the UPS again. Check that it starts working correctly and it doesn’t signal any sort of anomaly.

Moreover be sure that all the devices connected to the UPS outputs are working correctly. Check that the

UPS do not go in overload status; otherwise it is necessary to remove part of the Output load.

7. Simulate a black-out by removing the AC Input line. The UPS starts working in Battery mode: the Line Led

(blue color) is off and the Battery Led (yellow color) icon is on. Moreover the UPS emits a brief acoustic

signal every 10 seconds.

8. Be sure that all the devices connected to the UPS outputs are working correctly and the UPS doesn’t signal

any sort of anomaly.

9. Restore the AC Input line: after few seconds the UPS turns back in Normal mode.

Before using ERA PLUS normally, leave it in Normal mode in order to charge the batteries completely as specified

at point 3. The batteries reach the 90% of their capacity after about 4 hours of recharge.

It is compulsory to ground/earth the UPS according to the Safety Standards.

Risk of electric shock at the Output lines if the UPS is ON, even when the UPS is not

connected to AC utility line.

Risk of electric shock at the Output lines while the unit is connected to the AC utility

line.

Risk of electric shock: do not remove the cover. The UPS contains internal parts, which

are at a high Voltage and are potentially dangerous, capable of causing injury or death

by electric shock.

There are no internal parts in the UPS that are user serviceable. Any repair or

maintenance work must be performed exclusively by qualified technical personnel

authorized by TECNOWARE. TECNOWARE declines any responsibility if this warning is

disregarded.

Disregard for these warnings may lead to a risk of electric shock to operators.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tecnoware UPS

Tecnoware

Tecnoware EVO DSP MM 6.0 Manuel utilisateur

Tecnoware

Tecnoware V33/65-80-100 Manuel utilisateur

Tecnoware

Tecnoware ERA PLUS 800 SCHUKO Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS 1.200 Rack Tower PF 0.9 Manuel utilisateur

Tecnoware

Tecnoware ECO STRIP 0.50 Manuel utilisateur

Tecnoware

Tecnoware ERA PLUS 750 Manuel utilisateur

Tecnoware

Tecnoware UPS EVO DSP PLUS 6.5 PF 0,9 Manuel utilisateur

Tecnoware

Tecnoware EXA 2.6 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Tecnoware

Tecnoware EXA PLUS 1000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP MM 4.0 Rack Tower Manuel utilisateur

Tecnoware

Tecnoware ERA PLUS 1.100 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS 800 PF 0.9 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS TT 10.0 Manuel utilisateur

Tecnoware

Tecnoware EVO STAR Manuel utilisateur

Tecnoware

Tecnoware EVO DSP TM Manuel utilisateur

Tecnoware

Tecnoware EVO DSP TT Manuel utilisateur

Tecnoware

Tecnoware Ups Pro Manuel utilisateur

Tecnoware

Tecnoware EVO 3.0 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 8.0 Manuel utilisateur

Tecnoware

Tecnoware EVO TM 15.0 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MODULAR Manuel utilisateur

Tecnoware

Tecnoware EVO DSP MM 3.6 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 1.0 - pf 0,9 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur

ZincFive

ZincFive BC Series Manuel utilisateur
