Wireless Multi-Channel

Mouse

USER’S GUIDE

Visit our Web site at: www.targus.com

400-0116-001C

TARGUS WIRELESS

MULTI-CHANNEL MOUSE

Introduction

Congratulations on your purchase of a Targus Wireless Multi-

Channel Mouse. This ergonomically designed mouse uses

leading-edge radio frequency (RF) technology that enables you

to use the mouse anywhere up to three feet of its receiver, in a

360 degree range of operation. No line-of-sight between the

mouse and its receiver is required.

This mouse also features ten communication channels with

automatic channel-hopping capability. This feature reduces the

likelihood of interference from other RF devices. Using multi-

channels make it ideal for use in areas where more than one RF

device is used, such as a conference room or office area.

NOTE: This mouse is a high resolution device. For maximum

accuracy and efficiency, it is recommended that you set your

display resolution to 1024 x 768 pixels or higher while you are

using the mouse.

Packaging Contents

In addition to this user’s guide, this package contains:

• Mouse

• Receiver

• USB charge cable

• Three inch USB extension cable

Targus Wireless Multi-Channel Mouse

System Requirements

To use the mouse, your computer must meet the following

hardware requirements and run one of the operating systems

listed below.

Hardware

• PC with an Intel®Pentium®processor or equivalent

• USB interface

Operating System

• Windows®98/98SE/Me/2000/XP

NOTE: The third button and the scrolling wheel only work with

the operating systems listed above. If you use the mouse with

a different operating system, it will lose its enhanced features

and function as a standard, two-button mouse.

Charging the Mouse

This mouse comes with a non-replaceable Lithium polymer

battery. If properly maintained, the battery will last for as long

as you own the mouse.

For best results, you should charge the mouse at least 14 hours

before using it. You can do this via the supplied USB charge

cable. To do this:

1 Connect the cable’s USB connector into an available USB

port on your computer

2 Connect the other end to the mouse.

NOTE: To continuously charge the mouse via the USB charge

cable, your computer must be on and awake. For best results,

turn off your computer’s power management feature while

charging the mouse.

Targus Wireless Multi-Channel Mouse

Low Battery Indicator Light

When the battery charge is running low, the LED on the

scroller wheel glows.

NOTE: If the indicator light is glowing, it is highly

recommended that you charge the mouse as soon as

possible to properly maintain the battery.

Once the indicator light starts glowing, the mouse’s internal

controller begins monitoring the battery’s voltage level. When

this level reaches its lowest point, depending on how often you

use the mouse, the mouse enters power off mode. To power on

the mouse, fully charge the battery then press the mouse’s

connect button to resume normal operation.

Connecting the Mouse Receiver

To connect the mouse receiver:

1 Turn off your computer.

2 Plug the USB receiver into an available USB port on your

computer.

3 Turn on your computer and follow any on-screen

instructions to complete the default driver installation.

Establishing a Communications

Link

NOTE: For best results, place the mouse close to the receiver

when establishing a communications link, to avoid possible

interference from other RF devices.

Targus Wireless Multi-Channel Mouse

After your computer detects the USB receiver and the driver

software is installed, you must establish a communications link

between the mouse and its receiver BEFORE you can use the

mouse. To establish this link, you need to set the identification

code so that the mouse works properly. To do this:

1 Press and release the link button on the receiver.

Sample receiver

The receiver’s status light blinks when the receiver is

activated.

2 Press and release the connect button, located on the bottom

of the mouse.

Sample mouse bottom

The mouse’s light emitter diode (LED) stops glowing when

you press the connect button and resumes glowing when the

button is released.

When the communication link is established, the receiver’s

status light turns off.

You are now ready to use the mouse.

Link button

Connect button

Targus Wireless Multi-Channel Mouse

Mouse Power Management

Powering the Mouse Off and On

To power the mouse off, move the on/off switch to the off

position. To turn it back on, move the switch back to the on

position.

Power Save Modes

To conserve the battery, the mouse reduces its power

consumption gradually when not in use, via power saving

modes, as follows:

Standby mode When the mouse stops moving, it

immediately enters standby mode. It

stays in this mode for 30 seconds if

movement isn’t detected.

Flash mode After 30 seconds of non-operation, the

mouse enters flash mode. It stays in this

mode for 20 minutes if movement isn’t

detected.

While in flash mode, the mouse’s

optical sensor turns off and on

intermittently to not only conserve

battery power, but allow the user prompt

access to the cursor if movement is

resumed.

Sleep mode After 20 minutes of non-operation, the

mouse enters sleep mode and turns off

the optical sensor. You must wake the

mouse to resume normal operation from

this mode.

Targus Wireless Multi-Channel Mouse

Waking the Mouse To wake the mouse from sleep mode,

press any button on the mouse to resume

normal operation.

Operating Hints

For optimal performance and RF reception:

• Turn off your computer’s power management feature before

charging the mouse so that your computer doesn’t enter

sleep mode, which temporarily haults the charging process.

• Place the receiver at least 8 inches (20 cm) away from all

electrical devices, such as your monitor, speakers or external

storage devices.

If necessary, use the three-inch extension cable to keep the

receiver away from the computer. Plug the receiver into the

extension cable, and the extension cable to the computer.

• Avoid using the mouse on a metal surface. Metals, such as

iron, aluminum or copper, shield the radio frequency

transmission and may slow down the mouse’s response time

or cause the mouse to fail temporarily.

• The mouse will enter a suspend mode at the same time your

computer does. To activate the mouse, press any button.

• If your computer has a metal case that contains aluminum or

magnesium, use the mouse to the side. The display panel

may interfere with the radio frequency signal if you use the

mouse directly in front of the computer.

• Never use the mouse on a glass or mirrored surface as these

surfaces will cause the mouse to fail temporarily.

• To maximize battery life, use the mouse on a white, or light

colored surface. Dark surfaces cause the mouse’s light

Targus Wireless Multi-Channel Mouse

emitter diode (LED) light to glow brighter, which causes the

battery to discharge more rapidly.

Comfortable Usage

Research suggests that physical discomfort and injury to

nerves, tendons, and muscles may be related to repetitive

motion, an improperly set up work area, incorrect body

posture, and poor work habits.

To reduce the risk of injury, follow these precautions:

• Stand, stretch, and move around several times every hour.

• Switch hands while performing tasks. Use shortcut keys to

avoid repetitive or awkward mouse movements.

• Relax your shoulders and keep your elbows at your sides.

Adjust the keyboard’s position so that you don’t have to

stretch to reach it.

• Adjust your position so that you don’t have to bend your

wrists to type; avoid placing your wrists on a sharp edge.

If you feel discomfort or numbness in your hands, wrists, arms,

shoulders, neck, or back while typing, consult a qualified

medical professional.

Things to Remember

Batteries

• To extend the life of your batteries, turn off the mouse while

traveling.

Sleep Mode

• The mouse’s sleep mode feature activates after 20 minutes of

non-operation. To wake the mouse from sleep mode, press

any button.

Targus Wireless Multi-Channel Mouse

Specifications

Button Count 3 with scrolling wheel

ID Selections 256

Number of Channels 10 with automatic detect and switching

channels

Hardware Resolution 800 dpi

Electromagnetic

Characteristics (EMC)

CE - Type acceptance: ETS 300 220 short

range devices

Distance Between

Mouse and Receiver 3 feet (0.91 m)

Mouse Carrier

Frequency 27 MHz ISM band

Dimensions Mouse:

3.5 x 2.05 x 1.38 inches

(89.5 x 52.1 x 35 mm)

Receiver:

2.5 x 0.86 x 0.67 inches

(63 x 22 x 17 mm)

Weight Mouse (without batteries):

3.38 ounces (96 grams)

Receiver:

0.56 ounces (16 grams)

Receiver Interface USB version 1.1

Operating Voltage Mouse:

3.7V DC (powered by battery)

Receiver:

4.5 to 5.5V DC (powered by the USB

port)

Targus Wireless Multi-Channel Mouse

Troubleshooting

What do I do if the mouse does not work?

• Make sure that the mouse is fully charged.

• Verify that your computer’s power management feature is

turned off.

• Check that the receiver’s USB connector is firmly attached

to the USB port on your computer.

• Make sure you have established a radio link between the

mouse and its receiver. See “Establishing a Communications

Link” on page 4.

Batteries 1 internal lithium polymer

Operating Current Mouse:

35mA or lower

Receiver:

30mA (typical) (100mA maximum)

Mouse Standby

Current 4.5 mA (for 30 seconds of non-operation)

Mouse Flash Mode

Current

Below 2.8mA (for 20 minutes of non-

operation)

Mouse Sleep Mode

Current Below 8µA

Modulation Type FSK

Transmission Rate 5K bps

Transmission Type Digital radio frequency

Error Detection 8-bit CRC

Table des matières

Autres manuels Targus Souris

Targus

Targus AMU76AP Manuel utilisateur

Targus

Targus Stow-N-Go Notebook Mouse Manuel utilisateur

Targus

Targus Rechargeable Wireless Notebook Mouse Manuel utilisateur

Targus

Targus AMW841 Manuel utilisateur

Targus

Targus MOBILE Manuel utilisateur

Targus

Targus Wireless Laser Mouse Manuel utilisateur

Targus

Targus AMU0503 Manuel utilisateur

Targus

Targus PAWM10 Manuel utilisateur

Targus

Targus Stow-N-Go Notebook Mouse Manuel utilisateur

Targus

Targus Stow-N-Go Notebook Mouse Manuel utilisateur

Targus

Targus AMW05US Manuel utilisateur

Targus

Targus wireless bluetooth notebook mouse Manuel utilisateur

Targus

Targus Stow-N-Go Notebook Mouse Manuel utilisateur

Targus

Targus 402-0145-001B Manuel utilisateur

Targus

Targus Rechargeable 5-Button Wireless Mouse Manuel utilisateur

Targus

Targus AMB09EU Manuel utilisateur

Targus

Targus AMW43EU Manuel utilisateur

Targus

Targus AMU06EU Manuel utilisateur

Targus

Targus Wireless Mouse Manuel utilisateur

Targus

Targus WIRELESS COMFORT LASER MOUSE Manuel utilisateur

Targus

Targus AMW060EU Manuel utilisateur

Targus

Targus WIRELESS OPTICAL LAPTOP MOUSE Manuel utilisateur

Targus

Targus U102 Manuel utilisateur

Targus

Targus AMW839 Manuel utilisateur

Manuels Souris populaires d'autres marques

Sven

Sven RX-G720 Manuel utilisateur

3DConnexion

3DConnexion CadMouse Pro Manuel utilisateur

Canyon

Canyon Puncher GM-20 Manuel utilisateur

Sharkoon

Sharkoon Light2 180 Manuel utilisateur

Cherry

Cherry MW 8C ERGO Manuel utilisateur

NGS

NGS HIT RB Manuel utilisateur

Sharkoon

Sharkoon FireGlider Manuel utilisateur

Lenovo

Lenovo Wireless Mouse N3902 Manuel utilisateur

BASETech

BASETech BN-S11 Manuel utilisateur

Dell

Dell WM326 Manuel utilisateur

Areson

Areson B213 Manuel utilisateur

HP M17587-371 Manuel utilisateur

Chatpen

Chatpen CHA-30 Manuel utilisateur

GAMDIAS

GAMDIAS DEMETER GMS5000 Manuel utilisateur

HP KJ453AA - Wireless Laser Mouse Manuel utilisateur

Trust

Trust GRAPHIN GXT 960 Manuel utilisateur

Lenovo

Lenovo SD-9082 Manuel utilisateur

Alienware

Alienware AW320M Manuel utilisateur
