Targus PAWM10 Manuel utilisateur

BRUSSELS HANNOVER BARCELONA TOKYO MILANO AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY

Targus Wireless

RF Mouse

USER’S GUIDE

Making Your Mobile Life Easier.

Visit our Web site at: www.targus.com

400-0110-001A

TARGUS WIRELESS RF

MOUSE

Introduction

Congratulations on your purchase of a Targus Wireless RF

Mouse. This ergonomically designed mouse uses a radio

frequency (RF) link that enables you to use the mouse

anywhere within four feet of its receiver. No line-of-sight

between the mouse and its receiver is required.

This user’s guide describes how to connect the mouse receiver

to your computer, install default software drivers and set up the

radio link for the following RF mouse models:

•PAWM10 – Wireless Mini Optical Mouse with Power

Management

In addition to this user’s guide, depending on the RF mouse

model that you purchased, this package contains:

PAWM10

•Mouse

•Receiver

•2 AAAbatteries

•Three inch USB extension cable

•Carrying pouch

Targus Wireless RF Mouse

System Requirements

To use the RF mouse, your computer must meet the following

hardware requirements and run one of the operating systems

listed below.

Hardware

• PC with a Pentium®processor or equivalent and a hard disk

drive

• USB interface

Operating System

• Windows®98/Me/2000/XP

NOTE: The third button and the scrolling wheel only work with

the operating systems listed above. If you use the RF mouse

with a different operating system, it will lose its enhanced

features and function as a standard, two-button mouse.

Connecting the Mouse Receiver

To connect the mouse receiver:

1 Turn off your computer.

2 Plug the USB receiver into an available USB port on your

computer.

Targus Wireless RF Mouse

Using the RF Mouse

Installing the Batteries

1 If the mouse is on, slide the on/off switch on the bottom of

the mouse to the “off” position.

2 Remove the battery cover from the top of the mouse by

pressing the battery cover hinge located on the bottom of

the mouse and sliding it off.

NOTE: The battery cover is also the top cover of the mouse.

3 Insert the supplied batteries, making sure that the positive

(+) and negative (-) ends of each battery match the polarity

indicators inside the battery housing.

WARNINGS: When replacing the batteries, you may use

alkaline or other heavy-duty NiMH batteries. Never use an

alkaline with a NiMH battery in a device.

Avoid mixing new and used batteries in a device.

4 Slide the battery cover back into position until it “clicks”

firmly into place.

5 Turn on the mouse be sliding the on/off switch on the

bottom of the mouse to the “on” position.

The optical sensor, located on the bottom of the mouse,

glows red.

Targus Wireless RF Mouse

Establishing a Communications Link

(All RF Mouse Models)

The RF mouse has 256 identification codes that allow the

mouse and its receiver to operate without interference from

other radio frequency devices.

After your computer detects the USB receiver and the driver

software is installed, you must establish a communications link

between the mouse and its receiver BEFORE you can use the

mouse. To establish this link, you need to set the identification

code so that the mouse works properly. To do this, follow the

instructions for your mouse model.

Mouse Model PAWM10

Make sure that your computer is turned on and has detected the

USB receiver before you establish a communications link.

1 Press and release the link button on the receiver.

Receiver

The USB connector rotates 90 degrees to facilitate easy

connection to your computer.

The receiver’s red status light blinks when the receiver is

activated.

2 Press and release the reset button, located on the bottom of

the mouse.

You are now ready to use the RF mouse.

90° rotation Red status light

Link button

Targus Wireless RF Mouse

Mouse Power Management

To power the mouse on and off, slide the on/off switch at the

bottom of the mouse to the desired position.

PAWM10 Mouse

When power is on, the mouse goes into "sleep mode" after 8

minutes of no use. To activate the mouse, touch the sensor

strips on the side with your hand.

To save battery power, turn off the mouse while traveling or

when you’re not using it.

CAUTION: Turning off the mouse will require you to

synchronize again the next time you turn it back on.

Operating Hints

For optimal performance and RF reception:

• Place the receiver at least 8 inches (20 cm) away from all

electrical devices, such as your monitor, speakers or external

storage devices.

If necessary, use a three-inch extension cable to keep the

receiver away from the computer. Plug the receiver into the

extension cable, and the extension cable to the computer.

• Avoid using the RF mouse on a metal surface. Metals, such

as iron, aluminum or copper, shield the radio frequency

transmission and may slow down the mouse’s response time

or cause the mouse to fail temporarily.

Sensor strips

Low battery indicator

Targus Wireless RF Mouse

• The RF mouse will enter a suspend mode at the same time

your computer does. To activate the mouse, touch the sensor

strips on the side of the mouse.

• If your computer has a metal case that contains aluminum or

magnesium, use the RF mouse to the side. The display panel

may interfere with the radio frequency signal if you use the

mouse directly in front of the computer.

• Never use the RF mouse on a glass or mirrored surface as

these surfaces will cause the mouse to fail temporarily.

• To maximize battery life, use the RF mouse on a white, or

light colored surface. Dark surfaces cause the mouse’s light

emitter diode (LED) light to glow brighter, which causes the

battery to discharge more rapidly.

Comfortable Usage

Research suggests that physical discomfort and injury to

nerves, tendons, and muscles may be related to repetitive

motion, an improperly set up work area, incorrect body

posture, and poor work habits.

To reduce the risk of injury, follow these precautions:

• Stand, stretch, and move around several times every hour.

• Switch hands while performing tasks. Use shortcut keys to

avoid repetitive or awkward mouse movements.

• Relax your shoulders and keep your elbows at your sides.

Adjust the keyboard’s position so that you don’t have to

stretch to reach it.

• Adjust your position so that you don’t have to bend your

wrists to type; avoid placing your wrists on a sharp edge.

Targus Wireless RF Mouse

If you feel discomfort or numbness in your hands, wrists, arms,

shoulders, neck, or back while typing, consult a qualified

medical professional.

Things to Remember

Batteries

General

• You must establish a communications link every time you

change the batteries.

• To extend the life of your batteries, turn off the mouse while

traveling.

Sleep Mode (All RF Mouse Models)

• The mouse’s sleep mode feature activates after 8 minutes of

non-operation.

• To wake the mouse from sleep mode, touch the sensor strips

on the side of the mouse.

Targus Wireless RF Mouse

Specifications

Model PAWM10

Button Count 3 with scrolling wheel

ID Selections 256

Electromagnetic

Characteristics

(EMC)

CE - Type acceptance: ETS 300 220 short

range devices

Distance Between

Mouse and Receiver 4 feet (1.2 m)

Mouse Carrier

Frequency

27.045 MHz

27.145 MHz

Dimensions Mouse:

4.09 x 2.2 x 1.44 inches

(104 x 56 x 36.5 mm)

Receiver:

2.75 x 0.95 x 0.55 inches

(70 x 24.2 x 14 mm)

Weight Mouse (without batteries):

3.74 ounces (106 grams)

Receiver:

0.56 ounces (16 grams)

Receiver Interface USB version 1.1

Operating Voltage Mouse: 1.6~5V

Receiver: 5V (powered by the USB port)

Batteries 2 AAA Alkaline

Operating Current Mouse: 26mA or lower

Receiver: Below 15mA
