Targus MTM0060425 Manuel utilisateur
2
TABLE OF CONTENTS
System requirements...........................................3
Installing the Batteries.........................................3
Using the Enhanced Resolution feature...............5
Bluetooth Software: WIDCOMM...........................5
Bluetooth Software: TOSHIBA............................10
Bluetooth Software: MICROSOFT......................15
Bluetooth Software: Mac OS X...........................19
Technical Support..............................................25
3
TARGUS BLUETOOTH®
LASER
RECHARGEABLE
NOTEBOOK MOUSE
Introduction
Congratulations on your purchase of the Targus Bluetooth®
Laser Rechargeable Notebook Mouse. This mouse has a
special EDR (Enhanced Data Rate) technology that provides
faster data transmission rate and allows multiple Bluetooth
devices running without conflict.
System Requirements
Hardware - Bluetooth-enabled notebook or desktop PC
Operating System - Windows® 98SE / 2000 / ME / XP
Mac OS X (10.x or greater)
Installing the Batteries (Supplied)
Use the two AAA-size rechargeable NIMH batteries
(supplied)
Remove the battery cover from the back of the mouse by
sliding off the cover while pressing the release button at the
bottom of the mouse.
Insert the batteries, making sure that the positive (+) and
negative (-) ends of each battery match the polarity
indicators inside the battery housing
•
•
•
4
OPEN
ID
on
off
connect
button
Battery cover
release button
slide the battery
cover in this direction
On/Off switch
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
WARNINGS: WHEN REPLACING THE BATTERIES, ALWAYS REPLACE WITH
NiMH BATTERIES OR OTHER RECHARGEABLE BATTERIES. NEVER USE ALKALINE
BATTERIES IN THIS DEVICE. AVOID MIXING NEW AND USED BATTERIES IN A
DEVICE
Snap the battery cover back into position
Turn on the mouse by sliding on/off switch on the bottom
to the “on” position.
•
•
Charge the mouse for 8 hours before using. Plug in the
USB charge cable to the mouse and connect the other
end to the computer.
•
NOTE: TO CONTINUOUSLY CHARGE THE BATTERIES VIA THE USB
CHARGE CABLE, YOUR COMPUTER MUST BE ON AND AWAKE . FOR
BEST RESULTS , TURN OFF YOUR COMPUTER ’S POWER MANAGE-
MENT / SLEEP MODE FEATURE WHILE CHARGING THE MOUSE.
Charging the Batteries
5
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
Initial Configuration
Before you can begin using Bluetooth connectivity on your
computer and other Bluetooth devices, you must perform
some initial setup tasks.
The Targus Bluetooth Laser Rechargeable notebook mouse is
designed to work with the three major software stack
(protocol) standards: WIDCOMM, Toshiba, Microsoft and Mac
OS X. Please check your computer’s documentation to see
which software stack your computer has. Please contact your
system vendor if your system does not support one of the
following Bluetooth software standards.
Using the enhanced Resolution feature
This bluetooth laser mouse has a special enhanced
resolution feature. By activating this feature, the laser
mouse will increase its tracking sensitivity from 800 CPI to
1600 CPI. This will improve the precision of the mouse
pointer for fine details with increased speed. Press both the
scroll and right key when the mouse is on , the red LED in
the scroll wheel will light up around 3 secs to proceed
resolution switching. When the LED is off, it indicates the
resolution switching is successful.
Bluetooth Software: WIDCOMM
1. Go to the Bluetooth Places icon located on your desktop
or in the system tray and double click, then click Bluetooth
setup wizard.
6
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
2. The Bluetooth configuration screen will prompt. Please
follow the onscreen instructions. Click Next to continue.
3. Continue to setup your bluetooth device profile.
7
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
4. Click Next to continue setup.
5. Please select the service which the bluetooth device
offers. (Default setting allows the most coverage. It is
recommend to keep as default). Click Next.
6. Installation will perform setup and click Next when setup is
completed.
8
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
7. Please turn on the mouse and press the connection ID
button located at the bottom of the mouse until the light in
the middle scrollwheel blinks red light (discoverable mode).
Click Next to continue pairing.
8. The confirmation window will appear as the system installs
the drivers. Click OK. When this is done, the mouse should
be functioning. The bluetooth mouse has been successfully
installed.
Targus BT
Laser
Notebook
Mouse
9
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
(There may be one or more different bluetooth device
detected.) If the mouse is not detected, please make sure
the power is on and in discoverable mode. Press Search
Again to re-pair the device.
9. Once the pairing search is complete, the bluetooth mouse
icon should appear on the screen as shown. Setup is
complete.You may choose to close the window, or continue
pairing other bluetooth devices.
connection with Targus BT laser notebook mouse has been
established successfully.
To confirm that the correct mouse is being connected
please use it to click the button below.
Targus BT
Laser
Notebook
Mouse
10
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
Bluetooth Software: TOSHIBA
How to check your version of the Toshiba Bluetooth Stack
1. Launch the Bluetooth Manager.
2. Select the Help menu.
3. Select About.
NOTE: TO ENSURE OPTIMAL PERFORMANCE OF YOUR BLUETOOTH PRODUCT YOU
NEED TOSHIBA BLUETOOTH STACK V3.20.00 OR HIGHER. IF YOU HAVE A DIFFERENT
VERSION PLEASE UPDATE IT FROM WWW.SUPPORT.TOSHIBA.COM
1. Double click on the Bluetooth Manager icon in the system
tray, and then click “New Connection.”
2. When follow window appears, click “New Connection” to
begin setup.
