Targus Wireless Laser Mouse Manuel utilisateur

BRUSSELS HANNOVER BARCELONA TOKYO MILAN AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY

Wireless Laser Mouse

USER’S GUIDE

Making Your Mobile Life Easier.®

Visit our Web site at: www.targus.com

Features and specifications are subject to change without notice.

AMW14US/400-0283-001A

TARGUS WIRELESS LASER

MOUSE

Introduction

Congratulations on your purchase of the Targus Wireless

Laser Mouse for the desktop. This ergonomically-designed

mouse offers the latest in laser tracking technology as well

as the most up-to-date wireless features. It allows for

improved tracking accuracy on most types of surfaces, even

some mirror and glass. With 6 channels and 256 IDs per

channel, the mouse's digital signal processor offers a new

level of accuracy and precision in wireless data

transmission. Productivity is enhanced by a practical 8-

button design that includes such short cuts as Internet back

and forward, applications switch and scroll up and down

functions.

Note: While the mouse is functioning, no laser light is

visible to the naked eye. Be careful not to look

directly into the emitter hole while the mouse is

active.

Package Contents

• Wireless Laser Mouse

• USB Receiver

• USB Charge Cable

•USBExtensionSeat

• 2 x AA Rechargeable Batteries

•UserGuide

AMW14US.fm Page 2 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

System Requirements

Hardware

• USB interface

Operating System

•Windows

®2000/XP

For Desktop PCs

For instances where the PC is positioned under a desk or

other places that might impede wireless connectivity, use of

the extension seat is recommended.

1 Connect the extension seat to an available USB port on

your PC.

2 Plug the USB wireless receiver into the port labeled

'receiver' located at the top of the seat.

3 Connect the USB end of the charge cable to the USB

port labeled 'charger' on the extension seat.

For Notebook PCs

1 Connect the extension seat to an available USB port on

your PC.

2 Plug the USB wireless receiver into the port labeled

'receiver' located at the top of the seat.

3 Connect the charge cable's USB end to the USB port

labeled 'charger' on the extension seat.

AMW14US.fm Page 3 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

Alternatively, if more than one USB port is available you may

opt not to use the extension seat by plugging the receiver

and charging cable directly into the notebook PC's open

USB ports.

Installing the Batteries

1 Remove the battery cover from the bottom of the mouse

by pressing the tab located on the bottom and lifting it

off.

Bottom of mouse

2 2 AA NiMH rechargeable batteries are included. Insert

the supplied batteries, making sure that the positive (+)

and negative (-) ends of each battery match the polarity

indicators inside the battery housing.

WARNINGS: Use ONLY heavy-duty NiMH

recharegeable batteries. Never use alkaline batteries.

Avoid mixing new and used batteries.

3 Slide the battery cover back into position until it “clicks”

firmly into place.

tab

Battery cover

AMW14US.fm Page 4 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

Charging the Mouse

For best results, you should charge the mouse at least eight

hours before using it.

1 Connect the supplied charge cable to the charge port

on the supplied extension seat and plug the extension

seat cable to the USB port on your computer.

2 Connect the other end of the charge cable to the

mouse.

3 Alternatively, you can connect the charge cable's USB

connector directly into an available USB port on your

computer.

NOTE: To continuously charge the mouse via the USB

charge cable, your computer must be on and awake.

For best results, turn off your computer’s power

management feature while charging the mouse.

Synchronization

Make sure that your computer is turned on and has

detected the USB receiver before you synchronize.

1 Press and release the connect button on the receiver.

Connect

button

AMW14US.fm Page 5 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

2 Press and release the connect button located on the

bottom of the mouse.

The receiver’s status light flashes while it scans the

identification codes. When synchronized the status light

stops flashing. This process must be completed within a

few seconds or the steps will need to be repeated.

After successfully synchronizing, you are ready to use the

mouse.

NOTE: Removing the batteries will require you to

synchronize the mouse with the receiver again.

Connect

button

Laser

emitter

AMW14US.fm Page 6 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

Using the Mouse

NOTES: The 4th through 8th buttons require Windows

2000 or XP to function.

Due to the improved tracking speed of the laser

engine, users may find the cursor movement is

faster than a conventional optical mouse. Cursor

settings can be changed from the Control Panel

in Windows.

1: Left Mouse Button 5: Application Switch

2: Right Mouse Button 6: Internet Page Backward

3: Middle Button/Scrolling Wheel 7: Scroll Up

4: Internet Page Forward 8: Scroll Down

AMW14US.fm Page 7 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

Safety Measures

• Although this mouse is a Class 1 Laser Product and safe

for operation, avoid pointing the laser into the eyes or

looking directly into the laser emitter.

• Keep the mouse away from young children.

• Any attempt to disassemble, adjust or repair the mouse

may result in exposure to laser light or other safety

hazards.

Sleep Mode

The mouse's sleep mode feature activates after 8 minutes

of non-operation. To wake the mouse, click the left, right or

scroll mouse button.

Troubleshooting

What do I do if the mouse does not work?

• Make sure that the polarity of the batteries is correct. The

positive (+) and negative (-) ends of each battery must

match the positive (+) and negative (-) connections in the

battery housing.

• Make sure that the batteries are fully charged. Check your

computer’s suspend mode settings, as the mouse will not

charge while the computer is in suspend mode.

• Check that the receiver's USB connector is firmly

attached to the USB port on your computer or the

AMW14US.fm Page 8 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

extension seat, or that the extensions seat's cable is

connected to your PC.

• Make sure you have established a wireless link between

the mouse and its receiver. See “Synchronization” on

page 5.

I do not see the laser light when the mouse is active.

• Unlike traditional optical mice, the light is not visible when

the laser mouse is active.

• To make sure the mouse is on and functioning properly,

move the mouse back and forth and check to see if the

cursor responds.

My mouse does not work on a mirror or glass sur-

face.

• Though rated for most of these kinds of surfaces,

occasionally there will be one such surface that will cause

the mouse to work improperly or not at all.

• If you are using the mouse on a reflective or mirrored

surface, move it to another surface.

What do I do if the response time of the mouse is

slow or the mouse intermittently stops working?

• "Increase the distance between the mouse's receiver and

the rest of your computer equipment. Use the USB

extension seat if necessary.

• "Increase the distance between the mouse's receiver and

the base units of other wireless devices.

• "Turn off any wireless devices and their base units that

are near the mouse's receiver.

AMW14US.fm Page 9 Tuesday, August 16, 2005 3:22 PM

Targus Wireless Laser Mouse

• Metals, such as iron, aluminum or copper may slow down

the mouse's response time or cause the mouse to fail

temporarily.

• If you are using the mouse on a metal surface, move it and

the receiver to a non-metal surface.

Technical Support

For technical questions, please visit:

Internet: www.targus.com/support.asp

Australia

Internet: www.targus.com.au

Email: infoaust@targus.com

Telephone: 1800-641-645

New Zealand

Telephone: 0800-633-222

Product Registration

Targus recommends that you register your Targus accessory shortly

after purchasing it. To register your Targus accessory, go to:

http://www.targus.com/registration.asp

You will need to provide your full name, email address, phone

number, and company information (if applicable).
