Targus Wireless Mouse Manuel utilisateur

USER GUIDE

rechargeable

5-button

wireless mouse

Visit our Website at www.targus.com/emea

Features and specifications subject to change without notice.

AMW06EU / 410-0067-003A

Table of Contents

English

System Requirements . . . . . . . . . . . . . . . . . . . . . . .6

Connecting the Receiver and Using the Mouse . .7

Charging the Mouse . . . . . . . . . . . . . . . . . . . . . . . .8

Establishing a Communications Link . . . . . . . . . . .9

Operating Hints . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Comfortable Usage . . . . . . . . . . . . . . . . . . . . . . . .12

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . .14

Product Registration . . . . . . . . . . . . . . . . . . . . . . .15

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Regulatory Compliance . . . . . . . . . . . . . . . . . . . .16

Deutsch

Systemanforderungen . . . . . . . . . . . . . . . . . . . . . .18

Anschluss des Empfängers und Handhabung der

Maus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Aufladen der Maus . . . . . . . . . . . . . . . . . . . . . . . .20

Die Kommunikationsverbindung einrichten . . . . .22

Hinweise zum Betrieb . . . . . . . . . . . . . . . . . . . . . .23

Ergonomie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Technische Daten . . . . . . . . . . . . . . . . . . . . . . . .25

Fehlerbehebung . . . . . . . . . . . . . . . . . . . . . . . . . . .26

AMW06EU.book Page 2 Tuesday, December 20, 2005 12:55 PM

Produktregistrierung . . . . . . . . . . . . . . . . . . . . . . .28

Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Behördliche Genehmigungen/Zulassungen . . . .28

Español

Requisitos del sistema . . . . . . . . . . . . . . . . . . . . .31

Cómo conectar el receptor y usar el ratón . . . . .32

Cómo cargar el ratón . . . . . . . . . . . . . . . . . . . . . .33

Cómo establecer el enlace de Radio Frecuencia

(RF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Consejos de funcionamiento . . . . . . . . . . . . . . . .36

Uso ergonómico . . . . . . . . . . . . . . . . . . . . . . . . . .37

Especificaciones . . . . . . . . . . . . . . . . . . . . . . . . . .38

Solución de problemas . . . . . . . . . . . . . . . . . . . . .38

Soporte técnico . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Registro del producto . . . . . . . . . . . . . . . . . . . . . .41

Garantía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Conformidad con las normas . . . . . . . . . . . . . . . .42

Français

Configuration requise . . . . . . . . . . . . . . . . . . . . . .45

Raccordement du socle récepteur et Mode d'em-

ploi de la souris . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Établissement d’un lien de communication . . . . .49

Conseils d’utilisation . . . . . . . . . . . . . . . . . . . . . . .50

Position d’utilisation confortable . . . . . . . . . . . . .51

AMW06EU.book Page 3 Tuesday, December 20, 2005 12:55 PM

Caractéristiques techniques . . . . . . . . . . . . . . . .52

Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Soutien technique . . . . . . . . . . . . . . . . . . . . . . . . .54

Enregistrement du produit . . . . . . . . . . . . . . . . . .55

Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Respect de la réglementation . . . . . . . . . . . . . . .56

Italiano

Requisiti di sistema . . . . . . . . . . . . . . . . . . . . . . . .59

Collegamento del ricevitore e Utilizzo del Mouse60

Ricarica del mouse . . . . . . . . . . . . . . . . . . . . . . . .61

Impostazione codice di riconoscimento . . . . . . .63

Suggerimenti per l'uso . . . . . . . . . . . . . . . . . . . . .64

Uso agevole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Specifiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Localizzazione e soluzione dei problemi . . . . . . .66

Assistenza tecnica . . . . . . . . . . . . . . . . . . . . . . . . .68

Registrazione del prodotto . . . . . . . . . . . . . . . . . .69

Garanzia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Conformità alla normativa . . . . . . . . . . . . . . . . . . .69

Nederlands

Systeemvereisten . . . . . . . . . . . . . . . . . . . . . . . . .71

Aansluiting van de ontvanger and Using the Mouse.72

De muis opladen . . . . . . . . . . . . . . . . . . . . . . . . . .73

De identificatiecode instellen . . . . . . . . . . . . . . . .75

Tips voor gebruik . . . . . . . . . . . . . . . . . . . . . . . . . .76

AMW06EU.book Page 4 Tuesday, December 20, 2005 12:55 PM

Comfortabel gebruik . . . . . . . . . . . . . . . . . . . . . . .77

Specificaties . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Probleemoplossing . . . . . . . . . . . . . . . . . . . . . . . .78

Technische ondersteuning . . . . . . . . . . . . . . . . . .80

Productregistratie . . . . . . . . . . . . . . . . . . . . . . . . .81

Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Naleving van de bepalingen . . . . . . . . . . . . . . . . .81

Português

Requisitos do Sistema . . . . . . . . . . . . . . . . . . . . .83

Ligar o receptor e utilização do mouse . . . . . . . .84

Carregando o Rato . . . . . . . . . . . . . . . . . . . . . . . .85

Estabelecer uma ligação de comunicação . . . . .86

Sugestões de funcionamento . . . . . . . . . . . . . . .88

Utilização confortável . . . . . . . . . . . . . . . . . . . . . .89

Especificações . . . . . . . . . . . . . . . . . . . . . . . . . . .89

Resolução de Problemas . . . . . . . . . . . . . . . . . . .90

Assistência Técnica . . . . . . . . . . . . . . . . . . . . . . .91

Registo de Produto . . . . . . . . . . . . . . . . . . . . . . . .92

Garantia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

Conformidade Normativa . . . . . . . . . . . . . . . . . . .93

AMW06EU.book Page 5 Tuesday, December 20, 2005 12:55 PM

TARGUS RECHARGEABLE

5-BUTTON WIRELESS

MOUSE

Introduction

Congratulations on your purchase of the Targus

Rechargeable 5-Button Wireless Mouse. This

ergonomically designed mouse uses a radio frequency (RF)

link that enables you to use the mouse anywhere within four

feet of its receiver. No line-of-sight between the mouse and

its receiver is required.

In addition to this user’s guide, this package contains:

System Requirements

Hardware

• PC with a Pentium®processor or equivalent

• USB interface

›Mouse

› Receiver

› 2 AAA rechargeable batteries

› USB extension seat

› USB charge cable

AMW06EU.book Page 6 Tuesday, December 20, 2005 12:55 PM

Targus Rechargeable 5-Button Wireless Mouse

Operating System

•Windows

®Me/2000/XP

NOTE: The extra buttons and the scrolling wheel only

work with the operating systems listed above. If you

use the mouse with a different operating system, it

will lose its enhanced features and function as a

standard, two-button mouse.

Connecting the Receiver and

Using the Mouse

To connect the mouse receiver, plug it into an available

USB port on your computer.

Installing the Batteries

1 Remove the battery cover from the top of the mouse by

pressing the hinge located on the center of the top cover

and sliding the cover off.

NOTE: The battery cover is also the top cover of the

mouse.

AMW06EU.book Page 7 Tuesday, December 20, 2005 12:55 PM

Targus Rechargeable 5-Button Wireless Mouse

2 2 AAA NiMH rechargeable batteries are included. Insert

the supplied batteries, making sure that the positive (+)

and negative (-) ends of each battery match the polarity

indicators inside the battery housing.

WARNINGS: When replacing the batteries, you must

use heavy-duty NiMH batteries. Never use alkaline if

you intend to use the recharging feature.

Avoid mixing new and used batteries in a device.

3 Slide the battery cover back into position until it “clicks”

firmly into place.

4 Turn on the mouse by clicking any mouse button.

The optical sensor, located on the bottom of the mouse,

glows red.

Charging the Mouse

For best results, you should charge the mouse at least 4

hours before using it. You can do this via the supplied USB

charge cable. To do this:

1 Connect the supplied charging cable’s USB connector

into an available USB port on your computer.

AMW06EU.book Page 8 Tuesday, December 20, 2005 12:55 PM

Targus Rechargeable 5-Button Wireless Mouse

2 Connect the other end to the mouse; the charger

connector is located on the front tip of the mouse.

3 Alternatively, you can connect the receiver to the

supplied extension seat and plug the extension seat

cable to the USB port on your computer.

NOTE: To continuously charge the mouse via the USB

charge cable, your computer must be on and awake.

For best results, turn off your computer’s power

management feature while charging the mouse.

Establishing a Communications

Link

The mouse has 256 identification codes that allow the

mouse and its receiver to operate without interference from

other radio frequency devices.

After your computer detects the USB receiver and the

driver software is installed, you must establish a

communications link between the mouse and its receiver

BEFORE you can use the mouse. To establish this link, you

need to set the identification code so that the mouse works

properly.

AMW06EU.book Page 9 Tuesday, December 20, 2005 12:55 PM

Targus Rechargeable 5-Button Wireless Mouse

NOTE: Make sure that your computer is turned on and

has detected the USB receiver before you establish a

communications link.

1 Press and release the connection button on the receiver.

Receiver

The USB connector rotates 90 degrees to facilitate easy

connection to your computer.

2 The receiver’s red status light blinks when the receiver is

activated.

Bottom of mouse

Connection

button

Status light

Connection button

AMW06EU.book Page 10 Tuesday, December 20, 2005 12:55 PM

Autres manuels pour Wireless Mouse

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Targus Souris

Targus

Targus Wireless Laser Rechargable Notebook Mouse Manuel utilisateur

Targus

Targus Rechargeable 5-Button Wireless Mouse Manuel utilisateur

Targus

Targus Stow-N-Go Notebook Mouse Manuel utilisateur

Targus

Targus AMU22 Manuel utilisateur

Targus

Targus Wireless Multi-Channel Mouse Manuel utilisateur

Targus

Targus AMW43EU Manuel utilisateur

Targus

Targus Kaleidoscope AMU0503US Manuel utilisateur

Targus

Targus AMW060EU Manuel utilisateur

Targus

Targus WIRELESS OPTICAL LAPTOP MOUSE Manuel utilisateur

Targus

Targus AMU18US Manuel utilisateur

Targus

Targus AMU89 Manuel utilisateur

Targus

Targus Stow-N-G Manuel utilisateur

Targus

Targus 410-1689-203A/AMW51EU Manuel utilisateur

Targus

Targus AMU02US Manuel utilisateur

Targus

Targus AMW584 Manuel utilisateur

Targus

Targus Wi-Fi mouse Manuel utilisateur

Targus

Targus 5-Button Laser Retractable Manuel utilisateur

Targus

Targus AMU4501 Manuel d'installation et d'exploitation

Targus

Targus USB mouse Manuel utilisateur

Targus

Targus AMU75EU Manuel utilisateur

Targus

Targus Stow-N-Go Notebook Mouse Manuel utilisateur

Targus

Targus PAUM005 Manuel utilisateur

Targus

Targus Bluetooth Laser Mouse Manuel utilisateur

Targus

Targus Wireless Optical Rechargeable Full-size Notebook... Manuel utilisateur

Manuels Souris populaires d'autres marques

Sven

Sven RX-G720 Manuel utilisateur

3DConnexion

3DConnexion CadMouse Pro Manuel utilisateur

Canyon

Canyon Puncher GM-20 Manuel utilisateur

Sharkoon

Sharkoon Light2 180 Manuel utilisateur

Cherry

Cherry MW 8C ERGO Manuel utilisateur

NGS

NGS HIT RB Manuel utilisateur

Sharkoon

Sharkoon FireGlider Manuel utilisateur

Lenovo

Lenovo Wireless Mouse N3902 Manuel utilisateur

BASETech

BASETech BN-S11 Manuel utilisateur

Dell

Dell WM326 Manuel utilisateur

Areson

Areson B213 Manuel utilisateur

HP M17587-371 Manuel utilisateur

Chatpen

Chatpen CHA-30 Manuel utilisateur

GAMDIAS

GAMDIAS DEMETER GMS5000 Manuel utilisateur

HP KJ453AA - Wireless Laser Mouse Manuel utilisateur

Trust

Trust GRAPHIN GXT 960 Manuel utilisateur

Lenovo

Lenovo SD-9082 Manuel utilisateur

Alienware

Alienware AW320M Manuel utilisateur
