SHELTER

ASSEMBLY MANUAL

Model # W12xL12xH 4.5m

C4040S Container Shelter

SPECIFICATION

Width:12m Length:12m Height:4.5m

IMPORTANT ---- READ MANUAL FIRST

Improper site preparation, Assembly and Maintenance may invalidate warranty and cause

unnecessary and costly mistake. If you have any questions contact your local dealer.

For User Friendly assembly we have identified each individual component with the part code as

indicated in the parts list. Please refer to the part code numbers and drawing to ensure problem free

assembly.

It’s necessary to tighten the roof fabric enough to avoid “hammocks” on the roof and also re-tighten

once or twice again after a few months of use. This is important when assembly in cold weather

(autumn and winter) because the fabric is stiff then and when we got the sun and warm weather

afterwards it will make the fabric “slack” again and need to be re-tighten before next winter.

It’s the owners responsibility to take of snow immediately if not slide off by itself.

READ ALL INSTRUCTIONS BEFORE ASSEMBLY

1. Keep work area clean. Cluttered areas invite injuries. Do not set up near snow drifts, in

slippery places, in high winds, or wet location.

2. Keep children away. All children should be kept away from the work area.

3. Don’t over reach. Keep proper footing and balance at all times.

4. Do not assemble in under the influence of alcohol or drugs. Read warning labels on

prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If there

is any doubt, do not assemble.

5. Be aware of possible windy conditions; fasten the bases in concrete if these conditions are likely

to occur. Remove the cover during hurricane.

6. Be careful with power and heat sources. Do not keep heat sources near the tarpaulin. Do not

expose to open flame.

7. Be aware of personal safety during assembly and use. Be careful not to pinch fingers with clips

and tubes when assembling: when using makes sure there is adequate ventilation for exhaust

and other dangerous fumes.

Parts List

Part Code

Description

Qty

Top Bent Tube

Side Bent Tube

Lower Bent Tube

Purlin

Top Tension Device

Clips

Left Base Plate

Right Base Plate

Ratchet

Nylon band for ratchet

Tensioning Tube

2 组

Bolts M8x80

Bolts M10x80

Roof Cover

Knitting Rope for Cover

∮32 Plastic Plug for end of tensioning tube

Angle iron

Angle iron for base plate

Bolt 12x30

EQUIPEMNT AND TOOLS FOR INSTALIATION

1. Measuring tape

2. String for alignment

3. Step ladder

4. Welder

5. Sledge hammer

6. Wrench

7. Scissors

INSTALLATION PROCESS

A—BASE INSTALLATION

Please refer to the diagram (Figure 1) to place the base plates.

Figure 1

1. The measurement is from center to center of the tubes. Referring to the above diagram and

confirm the place of the base plates. ENSURE THAT THE FOUNDATIONS IS SQUARE.

2. All the base plates should be welded on the Containers.

Figure 2 Sketch Frame

B—FRAME INSTALLATION

Figure 3

1. As Figure 3 shown find Roof Bent Tube (No. 1), Side Bent Tube (No.2), Lower Bent

Tube(No.3). To connect them by Bolts M8x80 （No.11）.Which makes one group of arch.

Please NOTE the direction of the bolt. DO NOT install the bolts on the top of the truss where

the fabric will rest.

2. Insert one end of the assembled arch into one base plate and force the other end of the arch into

the opposite base plate.

Figure 4

3. After finishing installing the first two arches, connect the Connection purlins onto them by

using screw M10x80（No.12）.There are 7 pieces of Connection Purlins (No.4) between each

arch. Then install the third arch into base plate and connect the purlins. Finally install the Top

Tension Device (No.5) using bolt and Clip (No.6). Assemble the Frame by turns like this.

C—ROOF COVER INSTALLATION

NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A

slight breeze is the most advantageous for cover installation. To take advantage of the breeze, pull

the cover up over the arches with breeze blowing in the cover like a sail filled with air.

1. Assemble Tensioning Tube for Roof Cover (No.10) before installing thecover.

2. Put the Roof Cover (No. 13) EVENLY, CAREFULLY AND SLOWLY on the frame. Adjust

the cover so that it is square and evenly centered on the frame.

Figure 5

Figure 6

3.Weld the Angle Seats (No. 16) on each container and use Ropes (No. 14) to knit the cover on

the two side arches, finally tie the Roof cover to the Angleseats.

4.Cut pockets over each ratchet on the base plates and put the Tensioning Tube for roof cover

(No. 10) into the pocket of roof cover. Then use the Nylon band (No.9) to tie down the Lower

Tensioning Tubes as Figure 6 shown. Finally install the∮32 Plastic Plug (No. 15) into two end

of the Lower tensioning tube.

Please check the below installation detailed pictures:

(A) (B)

NOTE: DO NOT LEAVE THE ROOF COVER UNATTACHED UNDER ANY

CIRCUMSTANCES until the final assembly and tightening has been completed.

The process is quite easy. But some tightening adjustments will be necessary to produce a

flat, tensioned roof cover. Please adjust the roof cover every month.

Please Note:

Please use the tape wrapped around the gap between the steel

skeleton after installing.
