StarTech.com ST4300U3C3 Manuel utilisateur

Manual Revision: 01/23/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST4300U3C3

4 Port USB 3.0 Hub with 3 Dedicated Charging

Ports (2 x 1A & 1 x 2A)

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Installation ..............................................................................................3

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Product Diagram

Power LED

USB 3.0 Hub Ports

USB Charge Ports

DC Jack USB 3.0

Host Port

Instruction Manual

Introduction

Packaging Contents

• 1 x USB Charging Hub

• 1 x USB 3.0 Cable

• 1 x Wall Mount Bracket (w/ Screws)

• 4 x Rubber Feet

• 1 x Universal Power Adapter (NA/UK/EU)

• 1 x Instruction Manual

System Requirements

• Available wall outlet

• USB-enabled computer system with an available USB port

Instruction Manual

Smart Charging Note: The charge ports of the ST4300U3C3 Hub are designed with

an Intelligent Control Chipset, which can detect the required charging mode of the

dierent devices connected, and switch to the proper mode for“Full Speed charging”

of that device(E.g. When an Apple device is connected, it will automatically charge to

Apple Charging Mode specications)

Installation

Warning! Do Not Connect Devices which do not require charging into the charging

ports of this device (e.g. USB Flash Drives, Card Readers, etc.)

1. If you plan to wall or surface-mount the device, attach the included wall-mount

bracket to the back of the unit using the screws provided, then attach to the desired

surface using the appropriate hardware (not included).

2. Connect the included power adaptor to an AC outlet, then to the device – the

power LED should be lit.

3. Connect the included USB A-B cable to the hub, then to an available USB port on

your PC.

4. The operating system should detect the hub immediately and automatically

install it.

5. Connect your device(s) to the corresponding data ports / charging ports (1A or 2A)

according to the charging requirement your device(s).

USB Devices

Compatable with devices requiring 5V, 1A(iPhone, Samsung, HTC, etc.)

Compatable with devices requiring 5V, 2A(iPad, iPad Mini, etc.)

12V

Input

220V/110V

Outlet

Instruction Manual

Apple Mode denition:

Apple Mode is a proprietary charging mode developed by Apple, which redenes

the other two pins of the USB connector, enabling them to send current and increase

charging speed (same theory as DCP mode in BC 1.2 version, but with dierent voltage

levels on the pins).

Detailed as follows:

1A Mode: VCC:5V/GND:5V/D+:2.0V/D-:2.7V (compatible with Apple products that need

1A current input, such as iPhones, IPods and iPads)

2A Mode: VCC:5V/GND:5V/D+:2.7V/D-:2.0V (compatible with Apple products that need

2A current input, such as iPads or iPad minis)

Notes:

a. The choice of charging mode is dependent upon what mode the connected device

supports. The quantity of charging electricity provided is also dependent upon how

much the connected device needs to get a full speed charge.

b. Some devices with a 2A charging requirement can be charged in a 1A USB port,

however, the provided power will be 1A and the charging time will be longer.

Likewise, devices with a 1A charging requirement can be connected to a 2A USB

port and the connected device will only draw the power that is required. It is

recommended that you connect your devices to the proper USB ports based on the

charging requirement of the connected device(s).

c. The charging station may become warm to the touch during charging – this is

normal and will not harm your connected device(s).

d. With an exhausted battery, a Samsung Galaxy Note tablet will not display a charging

icon when connected to the charging hub. After approximately one hour of low

speed charging, the charging icon will show up and begin high speed charging.

BC 1.2 Mode ( Battery Charging Specication 1.2) denitions:

SDP: Standard Downstream Port, dened under USB 2.0 & 3.0 specication. Charging

limits: 500mA / USB 2.0; 900mA/USB3.0

DCP: Dedicated charging Port, for charging only. To increase charging eciency in

DCP mode, D+ and D- will short out and cannot transmit data. **ST7CU35122 uses this

mode only.

CDP: Charging Downstream Ports. USB ports under this mode can transmit data.

Instruction Manual

Specications

Host Interface USB 3.0

Number of Ports 7 (4 x USB 3.0 Hub Ports / 2 x 1A, 1 x 2A

Charging Ports)

Connectors

1 x USB 3.0 B (9 pin; SuperSpeed)

4 x USB 3.0 A (9 pin; SuperSpeed)

3 x USB A (4 pin)

Maximum Data Transfer Rate 5 Gbps

Supported Standards USB Battery Charging Specication Rev. 1.2

Power Adapter 12V, 3A

Enclosure Material Aluminum

Operating Temperature 5°C to 35°C (41°F to 95°F)

Storage Temperature -20°C to 50°C (-4°F to 122°F)

Dimensions 110 x 45 x 24 mm

Weight 130g

Compatible Operating Systems

Windows® 8.1 (32/64-bit), 8 (32/64), 7

(32/64), Vista (32/64), XP (32/64)

Windows® Server 2012, 2008 R2, 2003

(32/64)

Mac OS 10.5 and up (Tested up to 10.9)

Linux kernel 2.4 and above

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
