Instruction Manual

Table of Contents

Introduction ................................................................................... 1

Features ......................................................................................1

Package contents ........................................................................1

Operating Controls and Functions .............................................. 2

Front Panel ..................................................................................2

Remote Control ...........................................................................3

Connection and Installation ......................................................... 3

Speciﬁcations ................................................................................ 4

Technical Support ......................................................................... 5

Warranty Information .................................................................... 5

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com HDMI 1.3 Switch. Now, you

can connect up to four devices with HDMI output (e.g. High Deﬁnition

DVD players, Blu-Ray players, Satellite Receivers, and Video Game

Consoles) to a single HDMI input, and eliminate the need to manually

exchange cables.

Features

HDMI 1.3, HDCP 1.1, and DVI 1.0 compliant•

Easy-to-use remote control for switching between devices•

Auto Signal Enhancement•

Package contents

This package should contain:

1 x Video Switch•

1 x IR Remote•

1 X Power Adapter•

1 X Instruction Manual•

Instruction Manual

Operating Controls and Functions

Front Panel

Remote control sensor1.

Input select/Indicators:2. Press the “INPUT” button repeatedly to switch

to your desired input source and the LED will illuminate to indicate

which input source is selected.

Signal Enhancement/Indicator:3. Press the “Signal Enhance” button

to turn on this feature to improve signal quality after long distance

transmission. Press again to turn off. The LED will illuminate when the

signal is enhanced

POWER Switch/Indicator:4. When the power supply is connected to the

system, the system will automatically to turn on and the power LED will

illuminate. Press the “POWER” button to turn on/off the system

Rear Panel

HDMI output:1. Connect the HDMI out of the unit to the HDMI input of

your display using an HDMI cable

HDMI Inputs:2. Connect each of the input ports to the HDMI or DVI

output of your source equipment such as DVD player or set-top-box

Power:3. Plug the 5V DC power supply into this unit and connect the

adapter to an A/C wall outlet.

1 2 3 4

1 2 3

Instruction Manual

Remote Control

Power:1. Press the button to turn on/off the

unit.

Direct input selector:2. Press 1, 2, 3 or 4 to

select the desired

input source.

Connection and Installation

Display Input 1 Input 2 Input 3 Input 4

Instruction Manual

Specications

Frequency

Bandwidth 2.25Gbps (single link)

Input ports 4 x HDMI female ports (Type A connector)

Output port 1 x HDMI female port

Power Supply 5VDC/1A (US/EU standards, CE/FCC/UL certiﬁed)

Dimensions (mm) 206(W) x 111(D) x 32(H)

Weight 250g

Operating

Temperature Operating from 0°C ~ 70°C

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-

ment to provide industry-leading solutions. If you ever need help with your

product, visit www.startech.com/support and access our comprehensive

selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a one-year warranty. In addition, StarTech.com

warrants its products against defects in materials and workmanship for the

periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent

products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or

exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about

all our products and to access exclusive interactive tools such as

the Cable Finder, Parts Finder and the KVM Reference Guide.

StarTech.com makes it easy to complete almost any IT or A/V

solution. Find out for yourself why our products lead the industry

in performance, support, and value.
