StarTech.com RK819SIDEM Manuel utilisateur

Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 11/14/2011

For the most up-to-date information, please visit: www.startech.com

RK819SIDEM / RK1019SIDEM / RK1219SIDEM

8U/ 10U/ 12U 19in Wide Wall Mount Side Mount Deep Open Frame Rack Cabinet

*actual product may vary from photos

Installation

To mount the cabinet to a wall, there are 4 anchor points on the side

panel of the cabinet. Please use the appropriate screws or bolts for

mounting heavy equipment to the specic type of wall (i.e. concrete,

drywall, etc.).

NOTE: Mounting points are 16”from center to center for mounting

to standard wooden studs.

Ensure the wall and mounting hardware will be able to support the

weight of the cabinet and any equipment that will be mounted into

it. Please be sure to observe proper safety procedures and use the

appropriate tools.

To install rack mountable equipment into the cabinet, use the

provided square cage nuts on the rack posts (install from rear

of posts), then use the provided cabinet screws to secure the

equipment to the cage nuts (from front of posts).

Packaging Contents

• 1 x Wall Mount Cabinet

• 1 x Bag of M5 Cabinet Screw

• 1 x Bag of M5 Cage Nut

System Requirements

• If mounting to a wall or other surface: Appropriate mounting

hardware for surface type

*RK1219SIDEM shown

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Specications

RK819SIDEM RK1019SIDEM RK1219SIDEM

Description 8U 19in Wide Wallmount/

Sidemount Open Frame Rack

10U 19in Wide Wallmount/

Sidemount Open Frame Rack

12U 19in Wide Wallmount/

Sidemount Open Frame Rack

Internal Height 8U 10U 12U

Mounting Depth 559.0mm (22”)

Maximum Weight

Capacity 159 kg (350 lbs)

Material SPCC

Color Black

Equipment Mounting

Hole Type Square

External Dimensions

(WxHxD) 537.0mm x 480.0mm x 565.0mm 537.0mm x 570.0mm x 565.0mm 537.0mm x 655.0mm x 558.0mm

Net Weight 17.72 kg 19.36 kg 21.82kg

Standards EIA RS310-D

Certications CE, RoHS
