StarTech.com InfoSafe Manuel utilisateur

InfoSafe Drive Enclosure with Card

Reader and USB Hub

IDECASEU2CRH Instruction Manual

Actual product may vary from photo

InfoSafe 3.5” USB 2.0 Drive Enclosure with Card Reader and USB Hub

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing a Hard Drive in the Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting and powering the Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Driver Installation (Windows 98SE, ME, 2000) . . . . . . . . . . . . . . . . . . . . . . . .3

Hard Drive Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Card Reader and USB Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Verifying installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

PostScriptPicture

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com InfoSafe 3.5” USB 2.0 Drive Enclosure with

Card Reader and USB Hub. This product allows you to turn virtually any standard 3.5”

computer hard drive into a portable storage solution. The enclosure also offers a 26-in-1

card reader, as well as a 2-port USB hub - saving time, money and space.

FFeeaattuurreess

• Supports almost any 3.5” form factor IDE hard drive

• Front panel 26-in-1 card reader

• 2-port USB Hub

• Sturdy aluminum casing

• Compliant with USB 2.0, USB 1.1 and Parallel ATA/ATAPI Rev. 6

BBeeffoorreeYYoouuBBeeggiinn

System Requirements

• A computer with an available USB 2.0 port

• An operating system that supports removable hard drives: Windows

98SE/ME/2000/XP/2003 Server, Mac OS X or higher (other operating systems may

also support this product; consult your documentation for specific details)

• A 3.5” IDE hard drive

Contents

This package should contain:

• 1 x Drive Enclosure with USB Hub and Card Reader

• 1 x 3’ USB Type A Female to Type Mini B Female

• 1 x 6’ 5V/12V DC 1.5 Amp switching power supply

• 1 x Driver CD

• 1 x Instruction Manual

PostScriptPicture

Instruction Manual

IInnssttaallllaattiioonn

Installing a Hard Drive in the Enclosure

Use caution when installing a hard drive in the enclosure. Excessive shock or force

could damage the drive and/or the enclosure, resulting in data loss.

CAUTION: Always ensure that you are properly grounded when handling a hard drive or

the enclosure tray, since electronic components can be damaged by static electricity. If

an anti-static mat or similar product is not available, ground yourself by touching a

computer case or other metal surface for several seconds before handling any

components.

1. Using a Phillips-head screwdriver, remove the two screws

located on the top of the case.

2. Gently slide the inner tray out of the enclosure.

3. Attach the IDE connector to the hard drive. To

avoid damaging the drive and the enclosure,

please refrain from using excessive force.

4. Attach the power connector to the hard drive.

5. Attach the hard drive to the tray, using the screws

provided with the hard drive.

6. Gently re-insert the tray back into the enclosure

7. Re-fasten the Phillips-head screws that were removed

in Step 1.

Connecting and powering the Enclosure

1. Attach the provided USB cable to the Mini B port, located on the enclosure.

2. Connect the opposite end of the USB cable into an available USB port on the host

computer.

3. Connect the 5V/12V DC 1.5 Amp switching power supply to the power port located

next to the On/Off switch. Connect the opposite end to an available power source.

PostScriptPicture

Instruction Manual

4. Ensure the computer is turned on. Move the On/Off switch to the On position.

Driver Installation (Windows 98SE, ME and 2000)

Hard Drive Enclosure

1. Once the enclosure has been attached to the host computer and power has been

applied, Windows will detect it. While Windows XP will automatically

install the required drivers, Windows 98SE and ME and 2000 will require that the

drivers from the Driver CD be installed. In this case, Windows 98SE will automatically

launch the Add New Hardware Wizard. Once the wizard begins searching for new

drivers for the USB 2.0 Storage Device, please click Next.

2. On the next screen, you will be given the option to Search for the best driver for

your device (Recommended). Please ensure that this option is selected, and click

Next.

3. At the next screen, you will see a notification that Windows will search for new

drivers in its driver database... . Please insert the included driver disk and locate

the folder AT2 Driver from within the Wizard.Click next once this has been selected.

4. At the next screen, Windows will indicate that it is ready to install the best driver for the

device, specifying the location of the chosen driver. Please click Next.

5. Windows will then notify you that it has ...finished installing the software that your

new hardware device requires. Please click on Finish.

Card Reader and USB Hub

1. To complete installation of the card reader, please locate and open the folder AU6362

on the Driver CD.

2. Double click on the icon illustrated:

3. Once the InstallShield Wizard completes configuration of the installation program, you

will be asked to restart your computer. Please click Restart.

4. After the computer has restarted, you will be welcomed to the installation program.

Please click Next.

5. When you are asked to plug the reader in, please ensure that the enclosure is still

connected to the computer, clicking OK once the drivers have finished loading.

6. Installation is now complete. When given the option, please select Yes, I would like to

restart my computer now.

7. Once the computer reboots, you should notice four Removable Disks listed under My

Computer.

PostScriptPicture

Instruction Manual

Verifying Installation

1. To verify that the installation has completed successfully, please locate the Device

Manager by browsing the following path: My Computer > System Properties >

Device Manager.

2. Expand the listing for Universal Serial Bus Controllers. If installation has been

successful, USB Storage Adapter AT2 (TPP) or USB Mass Storage Device will be

listed, indicating that the hard drive is ready to use. Similarly, Generic USB Hub will

be listed, indicating that the USB Hub is ready to use.

Under Disk Drives, Generic USB CF, MS, SD and SM USB devices should be listed,

indicating that the card reader is ready to use.

PostScriptPicture

Instruction Manual

Specifications

PostScriptPicture

Instruction Manual

Hard Drive interface IDE

Certifications (Regulatory and other) FCC, CE, RoHS, WEEE

Maximum Data Transfer Rate 480Mbps

Maximum Hard Drive Size Supported

Chipset Cypress CY7C63000

Operating System Support Windows 98SE and Higher

Dimensions 237 x 40 x 130mm

Weight 884.5g (1.95lb)

Flash Media Supported

CF Type I, II

CF Ultra II

CF Extreme I

SMC

MS Pro

MS Pro Extreme

MS Duo

MS Pro Duo

MS Pro Ultra II

MS Magic Gate

MS Duo Magic Gate

MS Pro Magic Gate

MS Pro Duo Magic Gate

MS Select Function

MS Rom

SD Ultra I

SD Extreme

MMC

MMC 4.0

Mini SD

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

PostScriptPicture

Instruction Manual

Revised: 31 May 2006 (Rev. A)

About StarTech.com

StarTech.com is “The Professionals’ Source for Hard-to-Find

Computer Parts”. Since 1985, we have been providing IT

professionals with the quality products they need to complete

their solutions. We offer an unmatched selection of computer

parts, cables, server management solutions and A/V products

and serve a worldwide market through our locations in the

United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our

products and to access exclusive interactive tools such as the

Parts Finder and the KVM Reference Guide. StarTech.com

makes it easy to complete almost any IT solution. Find out for

yourself why our products lead the industry in performance,

support, and value.

Table des matières

Autres manuels StarTech.com Enceinte

StarTech.com

StarTech.com InfoSafe IDECASE25OTG Manuel utilisateur

StarTech.com

StarTech.com USB2SLSATINT Manuel utilisateur

StarTech.com

StarTech.com InfoSafe UNI3510U2EB Manuel utilisateur

StarTech.com

StarTech.com InfoSafe UNI3510U2E Manuel utilisateur

StarTech.com

StarTech.com S251BU31C3CB Manuel utilisateur

StarTech.com

StarTech.com UNI2510U2V Manuel utilisateur

StarTech.com

StarTech.com SAT2510BU32 Manuel utilisateur

StarTech.com

StarTech.com S2510BU3PWPS Manuel utilisateur

StarTech.com

StarTech.com 4POSTRACK25 Manuel utilisateur

StarTech.com

StarTech.com InfoSafe SAT2510BU2B Manuel utilisateur

StarTech.com

StarTech.com IDECASE35NAS Manuel utilisateur

StarTech.com

StarTech.com RK1219WALL Manuel utilisateur

StarTech.com

StarTech.com 4POSTRACK36 Manuel utilisateur

StarTech.com

StarTech.com SAT2510U2F Manuel utilisateur

StarTech.com

StarTech.com S3520WU33ER Manuel du système

StarTech.com

StarTech.com InfoSafe UNI3510U2E Manuel utilisateur

StarTech.com

StarTech.com S251BU31REM Manuel utilisateur

StarTech.com

StarTech.com RK1219WALHM Manuel utilisateur

StarTech.com

StarTech.com RK123WALHM Manuel utilisateur

StarTech.com

StarTech.com SLSODDU33B Manuel utilisateur

StarTech.com

StarTech.com S2510U33RUSM Manuel du système

StarTech.com

StarTech.com S2510U33RUSM Manuel utilisateur

StarTech.com

StarTech.com SAT3540ER2 Manuel utilisateur

StarTech.com

StarTech.com SAT2510U2REM Manuel utilisateur

Manuels Enceinte populaires d'autres marques

SilentiumPC

SilentiumPC Armis AR5 Manuel

Pulsar

Pulsar 17/TRP80/DSPR Manuel utilisateur

Thermaltake

Thermaltake V150 TG Manuel utilisateur

MSI

MSI MPG SEKIRA 500X Manuel utilisateur

Antec

Antec Dark fleet DF-10 Manuel utilisateur

Nexans

Nexans WTC05 Manuel utilisateur

Peavey

Peavey DS 1502 Manuel utilisateur

D-Link

D-Link ShareCenter Pro DNS-1550-04 Manuel utilisateur

Rosewill

Rosewill RX82-U(JBOD) Manuel utilisateur

QNAP

QNAP SAS JBOD CLI 1.0 Manuel utilisateur

GAMDIAS

GAMDIAS Talos P1 Manuel utilisateur

Auvs

Auvs KR615 Manuel utilisateur

Digitus

Digitus DA-71114 Manuel utilisateur

CommScope

CommScope FDH 3000 Manuel utilisateur

FS FHD-FWME4 Manuel utilisateur

JBL

JBL CS1215T Manuel utilisateur

Pulsar

Pulsar ARAD-S4 Manuel utilisateur

Pulsar

Pulsar AWO454 Manuel utilisateur
