StarTech.com SAT5210U2E Manuel utilisateur

SATA Optical Drive Enclosure

SAT5210U2E Instruction Manual

Actual product may vary from photo

InfoSafe 5.25” eSATA/USB 2.0 SATA Optical Drive Enclosure

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aannddootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a product

or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and related

documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing a Drive in the Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting the Enclosure to the Host Computer . . . . . . . . . . . . . . . . .4

Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Disconnecting an External Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Instruction Manual

Thank you for purchasing a StarTech.com InfoSafe 5.25” eSATA/USB 2.0 SATA Optical

Drive Enclosure. This versatile solution provides a cost-effective way to turn any SATA or

SATA II 3.5" hard drive, or 5.25" optical drive into an external solution. Equipped with both

USB 2.0 and eSATA interfaces for maximum data transfer capability and convenient

connectivity to the host computer, SAT5210U2E protects installed drives with a sturdy yet

attractive aluminum casing and a 40mm fan to help cool the drive for optimal performance.

IInnttrroodduuccttiioonn

•Aluminum casing and 40mm fan for maximum heat dissipation

Features

Package contents:

•1 x Drive Enclosure

This package should contain:

•Equipped with USB 2.0 and eSATA interface connections to host computer

•Full plug and play support through USB 2.0 interface

•1 X USB Cable

•1 x Power Adapter

•1 x Manual

•1 x Driver CD

•Stereo headphone jack for computer free CD playback

System Requirements

•A host computer with an available eSATA or USB port

•Operating system: Windows 98SE/ME/2000/XP/VistaTM/ Mac OS 9x and up

•1 X Screw Kit

Instruction Manual

HHaarrddwwaarreeGGuuiiddee

Rear Panel

C FDB E

ARetaining Screw

B40mm Cooling Fan

CDC Power Port

DPower Switch

EeSATA Port

FUSB Port

IInnssttaallllaattiioonn

Installing a Drive in the Enclosure

1. Loosen the Retaining Screws, on the rear panel. Please note that these screws do

not need to be removed, rather loosened enough to allow the Hard Drive Tray to slide

out from the enclosure.

2. Slide the Drive Tray out from the Enclosure.

WARNING: Hard drives require careful handling, especially when being

transported. If you are not careful with your hard disk, lost data may result.

Always handle your hard drive and storage device with caution.

WARNING: Hard drives, like all computer equipment can also be severely

damaged by static electricity. Be sure that you are properly grounded before

opening your computer case or touching any components. StarTech.com

recommends that you wear an anti-static strap when installing any computer

equipment. If an antistatic strap is unavailable, discharge yourself of any static

electricity build-up by touching a large grounded metal surface (such as the

computer case) for several seconds.

Instruction Manual

3. Connect the drive you wish to install (hard drive, optical drive) to the SATA data and

power cables provided by the circuit board attached to the Drive Tray:

4. Once the drive interface connection has been made, please fasten the drive (label side

up) to the Drive Tray using the screws provided:

5. If you are installing an optical drive:

Once the SATA connections to the drive have been secured, and the drive has been

fastened to the Drive Tray, remove the plastic cover from the Front Panel as pictured

below, to allow access to an installed optical drive.

If you are installing a 3.5” hard drive, please skip to step #6.

5. b) Apply gentle pressure from

left to right (with Enclosure

facing you) to loosen the

plastic cover

5. c) Once loosened, gently pry

the plastic cover away from

the Enclosure.

Instruction Manual

6. Slide the Drive Tray (with drive installed) into the Drive Enclosure, and tighten the

Retaining Screws (loosened in step #1) on the front panel to secure the tray within the

Enclosure. Installation is now complete:

SAT5210U2E with DVD-ROM

Drive installed

Connecting the Enclosure to the Host Computer

Once the drive has been secured within the enclosure, it can be connected to the host

computer while the host computer is powered on:

1. If you will be using an eSATA connection, insert one of the connectors provided by an

eSATA cable (not provided - please see Accessory Products from StarTech.com for

a solution), or the USB type B connector provided by a USB A-B cable (provided), into

the corresponding port on the rear panel of the Drive Enclosure.

2. Connect the remaining end of the cable used in step #1 to an available eSATA or USB

type A port on the host computer as necessary.

3. Insert the cylindrical, metal connector provided by the Power Adapter (included) into

AC Input

DC 12V Output

To PC USB/eSATA Port

USB Port

eSATA Port

Instruction Manual

the DC Power Port located on the rear panel of the Enclosure. Connect the remaining

end of the Power Adapter to an available power outlet.

4. Move the Power Switch on the rear panel of the Enclosure to the ON position. If the

Enclosure is connected to a host computer that is running Windows ME or above, or

Mac OS 9x or higher, the operating system on the host computer will detect that the

connection is present, and install the necessary drivers. If the host computer is running

Windows 98, please follow the instructions listed in the next section, titled Driver

Installation.

If you are installing an optical drive, such as a CD/DVD-ROM drive etc., you may be

required to install software that is specific to the drive. If this is the case, please ensure

you have the files available from the drive manufacturer. For further information on this

step, please consult the documentation that accompanied the optical drive.

Driver Installation

If the host computer to which SAT5210U2E is connected is running Windows 98, additional

driver installation is required for the operating system to recognize that a USB device has

been connected.

To install the necessary drivers, insert the Driver CD (included) into the CD/DVD-ROM

drive:

1. When the Add New Hardware Wizard

appears, please click on Next.

2. Select Search for the best driver for

your device (Recommended) and click

on Next.

Instruction Manual

4. Once Windows has located the necessary

file, click on Next.

3. You will be asked to specify the location of

the Windows 98 driver. Please ensure that

Specify a location and CD-ROM drive are

selected (with checkmarks) and click on

Browse to locate the driver file

(D:\JM20336_Win98 driver), where D:

designates the CD/DVD-ROM drive. Once

the file has been located, click on Next.

5. Once Windows finishes installing the

software that your hardware device

requires, click on Finish to conclude

installation.

Instruction Manual

2. Once the connected hard drive activity has terminated, it is safe to power down and

remove the enclosure from the host computer, by disconnecting the USB cable from

the host computer.

DDiissccoonnnneeccttiinnggaannEExxtteerrnnaallHHaarrddDDrriivvee

WARNING: Do not disconnect any cables or power sources while the hard drive

is active. This can result in data loss and possible damage to the hard drive.

1. In Windows, click on the Safe Remove icon located in the taskbar, and select the

connected enclosure from the menu provided, then click Stop. From the menu that

appears next (pictured below), select the device to disconnect, and click OK.

*Safe Remove

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

ESATA3

3 Ft Shielded External eSATA Cable M/M

ESATA6

6 Ft Shielded External eSATA Cable M/M

ESATAPLATE1

1 ft eSATA Data Internal to External Slot Plate
