ST 32F429IDISCOVERY Manuel utilisateur

July 2020 UM1670 Rev 4 1/32

UM1670

User manual

Discovery kit with STM32F429ZI MCU

Introduction

The 32F429IDISCOVERY Discovery kit allows users to easily develop applications with the

STMicroelectronics Arm®Cortex®-M4 core-based STM32F429 high-performance

microcontroller. It includes an ST-LINK/V2-B embedded debug tool, a 2.4" QVGA TFT LCD,

an external 64-Mbit SDRAM, an ST MEMS gyroscope, a USB OTG Micro-AB connector,

LEDs and push-buttons.

The board comes with the STM32 comprehensive free software libraries and examples

available with the STM32CubeF4 MCU Package, as well as direct access to the Arm®Mbed

Enabled™resources at the http://mbed.org website.

Figure 1. STM32F429 Discovery board

Picture is not contractual.

www.st.com

Contents UM1670

2/32 UM1670 Rev 4

Contents

1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Codification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 Development environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.1 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.2 Development toolchains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.3 Demonstration software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4 Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5 Quick start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5.1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6 Hardware layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

6.1 STM32F429 Discovery board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

6.2 Mechanical drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.3 Embedded ST-LINK/V2-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

6.3.1 Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6.3.2 ST-LINK/V2-B firmware upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6.3.3 VCP configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6.3.4 Using ST-LINK/V2-B to program/debug

the STM32F429ZIT6 on board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6.3.5 Using ST-LINK/V2-B to program/debug

an external STM32 application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

6.4 Power supply and power selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

6.5 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

6.6 Push-buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

6.7 USB OTG supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

6.8 Gyroscope MEMS (ST-MEMS I3G4250D) . . . . . . . . . . . . . . . . . . . . . . . . 19

6.9 TFT LCD (Thin-film-transistor liquid-crystal display) . . . . . . . . . . . . . . . . 19

6.10 64-Mbit SDRAM (1Mbit x 16-bit x 4-bank) . . . . . . . . . . . . . . . . . . . . . . . . 19

6.11 JP3 (Idd) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

UM1670 Rev 4 3/32

UM1670 Contents

6.12 OSC clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

6.12.1 OSC clock supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

6.12.2 OSC 32 kHz clock supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

6.13 Solder bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

6.14 Extension connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

7 32F429IDISCOVERY information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

7.1 Product marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

7.2 Board revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

7.2.1 MB1075 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

7.3 Known limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

7.3.1 MB1075-F429 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

List of tables UM1670

4/32 UM1670 Rev 4

List of tables

Table 1. Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Table 2. Codification explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Table 3. ON/OFF conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Table 4. Jumper states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Table 5. Debug connector CN2 (SWD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table 6. Solder bridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Table 7. STM32 pin description versus board functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 8. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

UM1670 Rev 4 5/32

UM1670 List of figures

List of figures

Figure 1. STM32F429 Discovery board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Figure 2. Hardware block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Figure 3. Top layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 4. Bottom layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 5. STM32F429 Discovery board mechanical drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 6. Updating the list of drivers in Device Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 7. STM32F429 Discovery board connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 8. ST-LINK/V2-B connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Features UM1670

6/32 UM1670 Rev 4

1 Features

•STM32F429ZIT6 microcontroller featuring 2 Mbytes of Flash memory, 256 Kbytes of

RAM in an LQFP144 package

•2.4" QVGA TFT LCD

•USB OTG with Micro-AB connector

•I3G4250D, ST MEMS motion sensor 3-axis digital output gyroscope

•Six LEDs:

– LD1 (red/green) for USB communication

– LD2 (red) for 3.3 V power-on

– Two user LEDs: LD3 (green), LD4 (red)

– Two USB OTG LEDs: LD5 (green) VBUS and LD6 (red) OC (over-current)

•Two push-buttons (user and reset)

•64-Mbit SDRAM

•Extension header for LQFP144 I/Os for a quick connection to the prototyping board

and an easy probing

•On-board ST-LINK/V2-B

•USB functions:

– Debug port

– Virtual COM port

– Mass storage

•Mbed Enabled™ (see http://mbed.org)

•Board power supply: through the USB bus or from an external 5 V supply voltage

•Comprehensive free software including a variety of examples, part of STM32CubeF4

MCU Package or STSW-STM32138, for using legacy standard libraries

UM1670 Rev 4 7/32

UM1670 Ordering information

2 Ordering information

To order the Discovery kit with the STM32F429ZI microcontroller, refer to Table 1. Additional

information is available from the datasheet and reference manual of the target

microcontroller.

2.1 Codification

The meaning of the codification is explained in Tabl e 2.

The order code is mentioned on a sticker placed on the top or bottom side of the board.

Table 1. Ordering information

Order code Board reference Target STM32

STM32F429I-DISC1(1)

1. Mbed Enabled™ STM32F429I-DISC1 with ST-LINK/V2-B replaces obsolete STM32F429I-DISCO with

ST-LINK/V2.

MB1075 STM32F429ZIT6

Table 2. Codification explanation

32XXYYZDISCOVERY Description Example: 32F429IDISCOVERY

32XX MCU series in STM32 32-bit Arm

Cortex MCUs STM32F4 Series

YY MCU product line in the series STM32F429

ZSTM32 Flash memory size:

– I for 2 Mbytes 2 Mbytes

DISCOVERY Discovery kit Discovery kit

Development environment UM1670

8/32 UM1670 Rev 4

3 Development environment

3.1 System requirements

•Windows® OS (7, 8 and 10), Linux® 64-bit or macOS®(a)

•USB Type-A to Mini-B cable

3.2 Development toolchains

•IAR Systems - IAR Embedded Workbench®(b)

•Keil®- MDK-ARM(b)

•STMicroelectronics - STM32CubeIDE

•Arm® Mbed™(c) online (see http://mbed.org)

3.3 Demonstration software

The demonstration software, included in the STM32Cube MCU Package corresponding to

the on-board microcontroller, is preloaded in the STM32 Flash memory for easy

demonstration of the device peripherals in standalone mode. The latest versions of the

demonstration source code and associated documentation can be downloaded from

www.st.com.

4 Conventions

Table 3 provides the definition of some conventions used in the present document.

a. macOS®is a trademark of Apple Inc. registered in the U.S. and other countries.

b. On Windows®only.

c. Arm and Mbed are registered trademarks or trademarks of Arm Limited (or its subsidiaries) in the US and

or elsewhere.

Table 3. ON/OFF conventions

Convention Definition

Jumper JPx ON Jumper fitted

Jumper JPx OFF Jumper not fitted

Solder bridge SBx ON SBx connections closed by solder

Solder bridge SBx OFF SBx connections left open

UM1670 Rev 4 9/32

UM1670 Quick start

5 Quick start

The STM32F429 Discovery is a low-cost and easy-to-use development kit to quickly

evaluate and start development with an STM32F4 microcontroller.

Before installing and using the product, accept the Evaluation Product License Agreement

from www.st.com/stm32f4-discovery.

For more information on the STM32F429 Discovery board and for demonstration software,

visit www.st.com/stm32f4-discovery.

5.1 Getting started

Follow the sequence below to configure the STM32F429 Discovery board and launch the

DISCOVER application:

1. Ensure that the jumpers JP3 and CN4 are set ON (Discovery mode).

2. Connect the STM32F429 Discovery board to a PC using a USB cable Type-A/Mini-B

through the USB ST-LINK connector CN1, to power the board, the LEDs LD2 (PWR)

and LD1 (COM).

3. The following applications are available on the screen:

– Clock/Calendar and Game

– Video Player and Image Browser (play videos and view images from the USB

mass storage connected to CN6)

– Performance monitor (watch the CPU load and run a graphical benchmark)

– System Info

4. The demonstration software, as well as other software examples, are available at the

www.st.com/stm32f4-discovery web page.

5. Develop applications starting from the examples.

Hardware layout UM1670

10/32 UM1670 Rev 4

6 Hardware layout

The STM32F429 Discovery board has been designed around the STM32F429ZIT6

microcontroller in a 144-pin LQFP package.

Figure 2 illustrates the connections between the STM32F429ZIT6 and its peripherals

(ST-LINK/V2-B, push-buttons, LEDs, USB OTG, ST-MEMS gyroscope, accelerometer,

magnetometer, and connectors).

Figure 3 and Figure 4 show the location of these features on the STM32F429 Discovery

board.

Figure 5 shows the mechanical dimensions of the STM32F429 Discovery board.

Figure 2. Hardware block diagram

MSv32376V3

Embedded

ST-LINK/V2-B

STM32F429ZIT6

I/O I/O

I/O RESET

LEDs

LD3...LD6

SDRAM

64 Mbits

RESET

USER

I3G4250D

Micro USB

Mini USB

SWD

Header

2.4" QVGA

TFT LCD

I2C ext

Table des matières

Autres manuels ST Microcontrôleur

ST STEVAL-BFA001V1B Manuel utilisateur

ST STM32H7 3 Series Instructions d'installation et d'utilisation

ST STM32F429I-DISCO Manuel utilisateur

ST STM32F4DISCOVERY Manuel utilisateur

ST STM32H74xI/G Manuel utilisateur

ST PSD4256G6V Manuel utilisateur

ST STM32F746IGT6 Manuel utilisateur

ST EVLKST8500GH868 Manuel utilisateur

ST STM8S Manuel utilisateur

ST STM8L Instructions d'installation et d'utilisation

ST STM32U575I-EV Manuel utilisateur

ST STM8A-DISCOVERY Manuel utilisateur

ST STEVAL-BCN002V1B Manuel utilisateur

ST UM2708 Manuel utilisateur

ST SPC56A Series Manuel utilisateur

ST STM32F423 Series Manuel utilisateur

ST Flash ST7 Manuel de service

ST STM32W-SK Manuel utilisateur

ST ST10F276E Manuel utilisateur

ST Turbo+ mPSD DK3400 Manuel utilisateur

ST STM32F072 Manuel utilisateur

ST STM32F7 Series Supplément

ST UM1932 Manuel utilisateur

ST STM32F105 series Instructions d'installation et d'utilisation

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
