ST X-NUCLEO-OUT02A1 Manuel utilisateur

Version 1.0 (Nov, 2018)

Quick Start Guide

Industrial digital output expansion board based on ISO8200AQ for STM32

Nucleo

(X-NUCLEO-OUT02A1)

Quick Start Guide Contents 2

X-NUCLEO-OUT02A1: Industrial digital output expansion board

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

Industrial digital output expansion board

Hardware Overview (1/2) 3

ISO8200AQ

X-NUCLEO-OUT02A1 Hardware Description

•The X-NUCLEO-OUT02A1 industrial digital output expansion board for

STM32 Nucleo is based on the ISO8200AQ galvanic isolated octal high-side

smart power solid state-relay.

•It provides an affordable and easy-to-use solution for the development of 8-

channel digital output modules, letting you easily evaluate the ISO8200AQ

communication and industrial load driving features.

•The X-NUCLEO-OUT02A1 can be connected to a NUCLEO-F401RE or

NUCLEOF334R8 development board via Arduino™ UNO R3 connectors.

•You can also evaluate the 16-channel digital output modules by connecting

two X-NUCLEO-OUT02A1 expansion boards and activating the daisy

chaining feature.

•The X-NUCLEO-OUT02A1 interfaces with the STM32 controller via SPI and

GPIO pins and is compatible with the Arduino™ UNO R3 (default

configuration) and ST morpho (optional, not mounted) connectors.

•Industrial PLC functionality with 8 inputs and 16 outputs can be added with

the X-NUCLEO-PLC01A1 expansion board.

Features

•Based on the ISO8200AQ Galvanic Isolated Octal High Side Smart Power

Solid State Relay with SPI interface

•10.5 to 33 V operating voltage range

•Green LED (x8) for output on/off status

•Red LED for process supply power good fault

•Red LED for overload and overheating

•Supply reverse polarity protection

•EMC compliance according to IEC61000-4-2, IEC61000-4-3, IEC61000-4-5

•Compatible with STM32 Nucleo boards

•Equipped with Arduino™ UNO R3 connectors

•CE certified

•RoHS and China RoHS compliant

•WEEE compliant

Digital outputs 24V Supply Rail

Arduino connectors

Key Products on board

ISO8200AQ:

Galvanic Isolated Octal High Side Smart Power Solid State Relay with SPI interface

Latest info available at www.st.com

X-NUCLEO-OUT02A1

Industrial digital output expansion board

Software Overview 4

Overall Software Architecture

Latest info available at www.st.com

X-CUBE-OUT2

X-CUBE-OUT2 Software Description

•The X-CUBE-OUT2 expansion software package for

STM32Cube runs on the STM32 and includes a driver for the

ISO8200AQ.

•The software provides an affordable and easy-to-use solution

for the development of 8-channel digital output modules,

letting you easily evaluate the ISO8200AQ communication

and industrial load driving features.

•The expansion is built on STM32Cube software technology to

ease portability across different STM32 microcontrollers.

•The software comes with a sample implementation of the

driver running on the X-NUCLEO-OUT02A1 expansion board

connected to a NUCLEO-F401RE or NUCLEO-F334R8

development board.

•You can also perform evaluation of 16-channel digital output

modules by connecting two X-NUCLEO-OUT02A1 and

activating the daisy chaining feature.

Key features

•Complete software to build applications for the ISO8200AQ

galvanic isolated octal high-side smart power solid state-relay

•GPIOs, SPI, PWMs and IRQs configuration

•Fault and power good interrupt handling

•Daisy chaining support

•Sample implementation available on the X-NUCLEO-

OUT02A1 expansion board when connected to a NUCLEO-

F401RE or NUCLEO-F334R8 development board

•Easy portability across different MCU families, thanks to

STM32Cube

•Free, user-friendly license terms

Quick Start Guide Contents 5

X-NUCLEO-OUT02A1: Industrial digital output expansion board

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

Setup & Demo Examples

HW prerequisites (1/2) 6

USB type A to Mini-B cable

X-NUCLEO-OUT02A1 plugged on to a

compatible STM32 Nucleo board

•1x STM32 Nucleo Industrial digital output expansion board

(X-NUCLEO-OUT02A1)

•1x STM32 Nucleo development board

(NUCLEO-F401RE or NUCLEO-F334R8)

•1x USB type A to Mini-B cable

•1x Laptop/PC running Microsoft Windows™ 7 or above

•1x External power supply at 24 V

X-NUCLEO-OUT02A1

NUCLEO-F401RE

NUCLEO-F334R8

Setup & Demo Examples

HW prerequisites 2/2 7

•The STM32F401RE has to be supplied by USB cable or by external supply connected to X-NUCLEO-

OUT02A1:

1. By USB cable of the STM32 Nucleo development board (DEFAULT)

a) CLOSE JP5 to U5V position on the STM32 Nucleo development board

2. By external supply of the X-NUCLEO-OUT02A1

b) Connect the external supply (from 7 to 12V) to CN2 of X-NUCLEO-OUT02A1

c) CLOSE JP5 to E5V position on the STM32 Nucleo development board

USB

JP5

Setup & Demo Examples

SW prerequisites 8

•STSW-LINK009: ST-LINK/V2-1 USB driver

•STSW-LINK007: ST-LINK/V2-1 firmware upgrade

•X-CUBE-OUT2:

•Copy the .zip file content into a folder on your PC

•The package contains the source code example (Keil, IAR, SW4STM32) based on

NUCLEO-F401RE or NUCLEO-F334R8

•STSW-IFAPGUI or STSW-IOLINKGUI

•This a GUI designed to drive interface with X-CUBE-OUT2 and to simplify the

access to the feature of the X-NUCLEO-OUT02A1.

•Install and launch the GUI on your Laptop/PC

•Connect the USB cable to the NUCLEO-F401 or NUCLEO-F334R8 stacked with

the X-NUCLEO-OUT02A1.

•USB scanning procedure starts and, after board has been detected, an STM32

blue icon appears on the GUI control window.

•Click on the STM32 blue icon (icon becomes green) to activate the panel of the X-

NUCLEO-OUT02A1.

•Supply the X-NUCLEO-OUT02A1 by 24V.

•Start your evaluation.

Quick start-up procedure

(see HW and SW prerequisites)

X-CUBE-OUT2

Start coding in just a few minutes with X-CUBE-OUT2 10

Download & unpack

Go to www.st.com/x-nucleo

www.st.com

X-CUBE-OUT2

Select

Generic Nucleo Docs

Open project example

Download and install ST-

LINK/V2-1 USB driver

X-NUCLEO-OUT02A1

ISO8200AQ drivers

Application example

Modify and build application
