SOYO SY-7SBB Manuel utilisateur

SY-7SBB

Motherboard

****************************************************

Socket 370 CeleronProcessor supported

SIS600 Motherboard

66/100 MHz Front Side Bus supported

Baby AT Form Factor

****************************************************

User's Manual

SOYO™SY-7SBB

Trademarks:

Soyo is the registered trademark of Soyo Computer Inc. All trademarks are the

properties of their owners.

Product Rights:

All names of the product and corporate mentioned in this publication are used for

identification purposes only. The registered trademarks and copyrights belong to

their respective companies.

part of this manual may be reproduced, transmitted, transcribed, translated into any

other language, or stored in a retrieval system, in any form or by any means, such

as by electronic, mechanical, magnetic, optical, chemical, manual or otherwise,

without permission in writing from Soyo Computer Inc.

Disclaimer:

Soyo Computer Inc. makes no representations or warranties regarding the contents

of this manual. We reserve the right to amend the manual or revise the

specifications of the product described in it from time to time without obligation to

notify any person of such revision or amend. The information contained in this

manual is provided to our customers for general use. Customers should be aware

that the personal computer field is subject to many patents. All of our customers

should ensure that their use of our products does not infringe upon any patents. It is

the policy of Soyo Computer Inc. to respect the valid patent rights of third parties

and not to infringe upon or to cause others to infringe upon such rights.

Restricted Rights Legend:

Use, duplication, or disclosure by the Government is subject to restrictions set

forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer

Software clause at 252.277-7013.

About This Guide:

This Quick Start Guide can help system manufacturers and end users in setting up

and installing the Motherboard. Information in this guide has been carefully

checked for reliability; however, to the correctness of the contents there is no

guarantee given. The information in this document is subject to amend without

notice.

For further information, please visit our Web Site on the Internet. The address is

"http://www.soyo.com.tw".

Edition: July 1999

Version 1.0

7SBB SERIAL

CTested To Comply

With FCC Standards

FOR HOME OR OFFICE USE

POST CONSUMER

RECYCLED PAPER

100%

Table of Contents SY-7SBB

iii

Table of Contents

CHAPTER 1 MOTHERBOARD DESCRIPTION.................................1

1-1 INTRODUCTION............................................................1

1-2 KEY FEATURES.............................................................1

1-3 HANDLING THE MOTHERBOARD..............................2

1-4 ELECTROSTATIC DISCHARGE PRECAUTIONS .........2

1-5 SY-7SBB MOTHERBOARD LAYOUT...........................3

1-6 SY-7SBB MOTHERBOARD COMPONENTS.................4

CHAPTER 2 HARDWARE INSTALLATION ......................................6

2-1 PREPARATIONS.............................................................6

2-2 UNPACKING THE MOTHERBOARD............................7

2-3 INSTALLATION GUIDE.................................................8

2-3.1 CPU Installation.......................................................................9

2-3.2 SDRAM Memory Module Installation...................................11

2-3.3 Motherboard Connector ...........................................................13

2.3.4 CMOS Clear(JP5)....................................................................28

2-3.5 Power On..................................................................................28

2.3.6 Quick BIOS Setup...................................................................29

2-3.7 Troubleshooting at First Start.................................................31

2-3.8 Power Off.................................................................................32

CHAPTER 3 BIOS SETUP UTILITY.................................................33

3-1 SOYO COMBO SETUP.................................................35

3-2 STANDARD CMOS SETUP..........................................39

3-3 BIOS FEATURES SETUP..............................................42

3-4 CHIPSET FEATURES SETUP.......................................46

3-5 POWER MANAGEMENT SETUP ................................51

3-6 PNP/PCI CONFIGURATION SETUP.............................55

3-7 LOAD SETUP DEFAULTS............................................58

3-8 INTEGRATED PERIPHERALS.....................................59

3-9 SUPERVISOR PASSWORD...........................................63

Table of Contents SY-7SBB

3-10 USER PASSWORD........................................................65

3-11 IDE HDD AUTO DETECTION .....................................66

CHAPTER 4 DRIVERS INSTALLATION ............................................67

Motherboard Description SY-7SBB

Chapter 1

MOTHEBOARD DESCRIPTION

1-1 INTRODUCTION

The SY-7SBB AGP/PCI Motherboard is a high-performance Socket 370

Baby AT form-factor system board. SY-7SBB uses the SIS600 Chipset

technology and supports Socket 370 processors. This Motherboard is fully

compatible with industry standards and adds many technical

enhancements.

1-2 KEY FEATURES

ØSupports Intel Celeronprocessors (300A-500MHz)

ØAuto-detect CPU voltage

ØPC98, ACPI, Ultra DMA/33

ØSupports system memory up to 768MBytes

ØSOYO COMBO Setup

ØPower-on by modem or alarm

ØSupports Wake-On-LAN (WOL)

ØSupports onboard hardware monitoring and includes Hardware

monitor utility

ØSupports Keyboard Power On/Off.

Ø1 x 32-bit AGP slot

Ø3 x 32-bit bus mastering PCI slots

Ø2 x 16-bit ISA slot

Ø2 x USB ports onboard

Ø1 x IrDA port

ØSupports multiple-boot function

ØAT & ATX power connectors

ØY2K Compliant

Motherboard Description SY-7SBB

1-3 HANDLING THE MOTHERBOARD

To avoid damage to your Motherboard, follow these simple rules while

unpacking:

ØBefore handling the Motherboard, ground yourself by touching an

unpainted portion of the system's metal chassis.

ØRemove the Motherboard from its anti-static packaging. Hold the

Motherboard by the edges and avoid touching its components.

ØCheck the Motherboard for damage. If any chip appears loose, press

carefully to seat it firmly in its socket.

Warning: Do not apply power if the Motherboard appears

damaged. If there is damage to the board, contact your dealer

immediately.

1-4 ELECTROSTATIC DISCHARGE PRECAUTIONS

Make sure to ground yourself before handling the Motherboard or other

system components. Electrostatic discharge can easily damage the

components. Note that you must take special precautions when handling

the Motherboard in a dry or air-conditioned environment.

To protect your equipment from electrostatic discharge, take the following

precautions:

ØDo not remove the anti-static packaging until you are ready to install.

ØGround yourself before removing any system component from its

protective anti-static packaging. (To ground yourself, touch the expansion

slot covers or other unpainted portions of the computer chassis.)

ØFrequently ground yourself while working or use a grounding strap.

ØHandle the Motherboard by its edges and avoid touching its

components.

Motherboard Description SY-7SBB

1-5 SY-7SBB MOTHERBOARD LAYOUT

SY-7SBB Platform

Flash BIOS

AGP Slot

PRT 1

Connector

PS/2 Mouse

Connector

ATX Power

AT Power

COM 2

FDC

IDE 1

IDE 2

Lithium

Battery

COM 1

SiS

8661

CHAFAN

PCI Slot #2

PCI Slot #1

PCI Slot #3

USB1

Socket 370

DIMM 2

DIMM 1

DIMM 3

5595

600

ISA Slot #1

ISA Slot #2

CPU FAN

JP44

(PC-PCI)

SB-LINK

SiS

ITE

Speaker

Keylock

Power

LED

ACPI

LED HDD

LED

Reset

PWRBT

JP5

CMOS Clear

IR1

Motherboard Description SY-7SBB

1-6 SY-7SBB MOTHERBOARD COMPONENTS

Motherboard Description SY-7SBB

A16-bit ISA Slot

BUSB Connector

CSerial Infrared Device Header

DWake-On-LAN (WOL) Header

EITE 8661 I/O Controller

FCOM1/COM2 Connectors

GPrinter Connector

HPS/2 mouse Connector

IKeyboard Connector

JATX Power Supply Connector

KCPU Cooling Fan Connector

LAT Power Supply Connector

M370-Pin PGA Socket

NDIMM Socket

OSiS 600 Chipset

PBus Mastering IDE/ATAPI Ports

QFloppy Disk Drive (FDD) Port

R32-bit AGP Slot

S3V Lithium Battery

T32-bit PCI Mastering Slots

UCMOS Clear Jumper

VChassis Cooling Fan

WFront panel connectors

XPCI Audio Card Header

YFlash ROM

ZSiS 5595 Chip

Hardware Installation SY-7SBB

Chapter 2

HARDWARE INSTALLATION

Congratulations on your purchase of the SY-7SBB Motherboard. This

chapter will help you install and connect your new Motherboard.

Note: Do not unpack the Motherboard from its protective anti-

static packaging until you have made the following preparations.

2-1 PREPARATIONS

Gather and prepare all the following hardware equipment to complete the

installation successfully:

1. Celeron processor with CPU cooling fan.

2. DIMM memory module

3. Computer case and chassis with adequate power supply unit

4. Monitor

5. Keyboard

6. Pointing Device (mouse)

7. Speaker(s) (optional)

8. Disk Drives: HDD, CD-ROM, Floppy drive…

9. External Peripherals: Printer, Plotter, and Modem (optional)

10. Internal Peripherals: Modem and LAN cards (optional)
