Contents

1 Instructions 58

1.1 General safety instructions 58

1.2 Manufacturer liability 59

1.3 Appliance purpose 59

1.4 Disposal 59

1.5 Identification plate 60

1.6 This user manual 60

1.7 How to read the user manual 60

2 Description 61

2.1 General Description 61

2.2 Control panel 61

2.3 Other parts 62

2.4 Available accessories 63

3 Use 64

3.1 Instructions 64

3.2 First use 64

3.3 Using the accessories 65

3.4 Using the removable drawer 65

3.5 Using the oven 66

3.6 Cooking advice 70

3.7 Special functions 75

3.8 Preset recipes 83

3.9 Personal recipes 89

3.10 Settings 94

4 Cleaning and maintenance 99

4.1 Instructions 99

4.2 Cleaning the surfaces 99

4.3 Ordinary daily cleaning 99

4.4 Food stains or residues 99

4.5 Removing the door 99

4.6 Cleaning the door glazing 100

4.7 Cleaning the inside of the oven 100

4.8 Pyrolytic: automatic cleaning 101

4.9 Extraordinary maintenance 104

5 Installation 106

5.1 Electrical connection 106

5.2 Cable replacement 107

5.3 Positioning 107

We advise you to read this manual carefully, which contains all the instructions for

maintaining the appliance’s aesthetic and functional qualities.

For further information on the product: www.smeg.com

Instructions

1 Instructions

1.1 General safety instructions

Risk of personal injury

• During use the appliance and its

accessible parts become very hot.

• Never touch the heating elements

during use.

• Keep children under eight years

of age at a safe distance if they

are not constantly supervised.

• Children must never play with the

appliance.

• Never rest metallic objects such

as knives, forks, spoons and lids

on the appliance during use.

• Switch off the appliance

immediately after use.

• Never try to put out a fire or

flames with water: Turn off the

appliance and smother the flames

with a fire blanket or other

appropriate cover.

• The appliance must never be

cleaned by unsupervised children.

• Have qualified personnel carry

out installation and assistance

interventions according to the

standards in force.

• Do not modify this appliance.

• Do not insert pointed metal

objects (cutlery or utensils) into the

slots in the appliance.

• Do not try to repair the appliance

yourself or without the intervention

of a qualified technician.

• If the power supply cable is

damaged, contact technical

support immediately and they will

replace it.

Risk of damaging the appliance

• Do not use abrasive or corrosive

detergents on glass parts (e.g.

powder products, stain removers

and metallic sponges).

• Use wooden or plastic utensils.

• Do not seat on the appliance.

• Do not use steam jets to clean the

appliance.

• Do not obstruct ventilation

openings and heat dispersal slots.

• Never leave the appliance

unattended during cooking

operations where fats or oils

could be released.

• Never leave objects on the

cooking surface.

• Do not use the appliance to heat

rooms for any reason.

Instructions

For this appliance

• Ensure that the appliance is switched off

before replacing the bulb.

• Do not rest any weight or sit on the open

door of the appliance.

• Take care that no objects are stuck in the

doors.

1.2 Manufacturer liability

The manufacturer declines all liability for

damage to persons or property caused by:

• Use of the appliance other than the one

envisaged;

• Non-observance of the user manual

provisions;

• Tampering with any part of the

appliance;

• Use of non-original spare parts.

1.3 Appliance purpose

• This appliance is intended for cooking

food in the home environment. Every

other use is considered improper.

• This appliance may be used by children

aged at least 8 and by people of

reduced physical and mental capacity,

or lacking in experience in the use of

electrical appliances, provided that they

are supervised or instructed by adults

who are responsible for their safety.

• The appliance is not designed to

operate with external timers or with

remote-control systems.

1.4 Disposal

This appliance must be disposed of

separately from other waste

(Directives 2002/95/EC, 2002/

96/EC, 2003/108/EC). The appliance

does not contain substances in quantities

sufficient to be considered hazardous to

health and the environment, in accordance

with current European directives.

To dispose of the appliance:

• Cut the power supply cable and remove

it along with the plug.

• Deliver the appliance to the appropriate

recycling centre for electrical and

electronic equipment waste, or return it to

the retailer when purchasing an

equivalent product, on a one for one

basis.

Power voltage

Danger of electrocution

• Disconnect the main power supply.

• Disconnect the power cable from the

electrical system.

Instructions

Our appliances are packed in non-

polluting and recyclable materials.

• Deliver the packing materials to the

appropriate recycling centre.

1.5 Identification plate

The identification plate bears the technical

data, serial number and brand name of the

appliance. Do not remove the identification

plate for any reason.

1.6 This user manual

This user manual is an integral part of the

appliance and must therefore be kept in its

entirety and within the user’s reach for the

whole working life of the appliance.

Read this user manual carefully before using

the appliance.

1.7 How to read the user manual

This user manual uses the following reading

conventions:

1. Use instruction sequence.

• Standalone use instruction.

Plastic packaging

Danger of suffocation

• Do not leave the packaging or any part

of it unattended.

• Do not let children play with the

packaging plastic bags.

Instructions

General information on this user

manual, on safety and final

disposal.

Description

Description of the appliance and its

accessories.

Use

Information on the use of the

appliance and its accessories,

cooking advice.

Cleaning and maintenance

Information for proper cleaning and

maintenance of the appliance.

Installation

Information for the qualified

technician: Installation, operation

and inspection.

Safety instructions

Information

Advice

Description

2 Description

2.1 General Description

1 Control panel

2 Oven light

3 Seal

4 Door

5 Fan

6 Rack/tray support frames

7 Storage compartment

Frame shelf

2.2 Control panel

1 Return knob

Using this knob you can return to the

appliance’s previous menu item. It also lets

you manually turn the oven light on and off.

2 Display

Displays the current time, the cooking

parameters, and all the appliance’s

functions.

Description

3 Control knob

This knob allows you to turn the appliance

on and off and select the various available

functions.

Turn the knob right or left to change/select

the required item. Press to confirm.

2.3 Other parts

Shelves

The appliance features shelves for

positioning trays and racks at different

heights. The insertion heights are indicated

from the bottom upwards (see 2.1 General

Description).

Cooling fan

The fan cools the oven and comes into

operation during cooking.

The fan causes a steady outflow of air from

above the door which may continue for a

brief period of time even after the appliance

has been turned off.

Interior lighting

The appliance interior lighting comes on:

• When the door is opened

• When any function is selected, apart

from the and functions

• Turning the return knob to the right or left

when no function is selected (turn the

temperature knob to the right or left

again to switch off the internal lighting).

Keep the knob pressed in for at

least 5 seconds to immediately

complete any cooking program.

Description

2.4 Available accessories

Rack

Useful for supporting containers with food

during cooking.

Tray rack

To be placed over the top of the oven tray;

for cooking foods which may drip.

Oven tray

Useful for collecting fat from foods placed

on the rack above.

Some models are not provided

with all accessories.

The oven accessories intended to

come into contact with food are

made of materials that comply with

the provisions of current legislation.

Supplied original and optional

accessories can be requested to

Authorised Assistance Centres.

Use only original accessories

supplied by the manufacturer.

Use

3 Use

3.1 Instructions

3.2 First use

1. Remove any protective film from the

outside or inside of the appliance,

including accessories.

2. Remove any labels (apart from the

technical data plate) from the

accessories and from the oven cavity.

3. Remove and wash all the appliance

accessories (see 4 Cleaning and

maintenance).

4. Heat the empty oven at the maximum

temperature to burn off any residues left

by the manufacturing process.

High temperature inside the oven

during use

Danger of burns

• Keep the oven door closed during

cooking.

• Protect your hands wearing heat

resistant gloves when moving food

inside the oven.

• Do not touch the heating elements inside

the oven.

• Do not pour water directly onto very hot

trays.

• Do not allow children to get near the

oven when it is in operation.

High temperature inside the oven

during use

Danger of fire or explosion

• Do not spray any spray products near

the oven.

• Do not use or leave flammable materials

near the oven.

• Do not use plastic kitchenware or

containers when cooking food.

• Do not put sealed tins or containers in

the oven.

• Do not leave the oven unattended

during cooking operations where fats or

oils could be released.

• Remove all trays and racks which are

not required during cooking.

Improper use

Risk of damage to enamelled

surfaces

• Do not cover the bottom of the oven

cavity with aluminium or tin foil sheets.

• If you wish to use greaseproof paper,

place it so that it will not interfere with the

hot air circulation inside the oven.

• Do not place pans or trays directly on

the bottom of the oven cavity.

• Do not pour water directly onto very hot

trays.

Use

3.3 Using the accessories

Racks and trays

Racks and trays have to be inserted into the

side guides until they come to a complete

stop.

• The mechanical safety locks that prevent

the rack from being taken out

accidentally have to face downwards

and towards the oven back.

Tray rack

The tray rack has to be inserted into the tray.

In this way fat can be collected separately

from the food which is being cooked.

3.4 Using the removable drawer

The removable drawer is found in the lower

part of the appliance and can be used to

house some of its accessories.

To access it:

1. Press the front part of the drawer until you

hear a release “click”

2. Release the drawer and pull it towards

you to extract it from its housing

To close it again:

1. Press the front part of the drawer inside

until you hear a “click” indicating that it

has locked in place again.

Gently insert racks and trays into

the oven until they come to a stop.

Clean the trays before using them

for the first time to remove any

residues left by the manufacturing

process.

Use

3.5 Using the oven

First use

On the first use, or after a power failure,

will be flashing on the appliance's

display. In order to be able to start any

cooking program, the current time must be

set (if the oven is being turned on for the first

time, it is also recommended you set the

required language).

Press the control knob to enter the settings

menu, see “3.10 Settings”.

Memory

Press the return knob from the clock screen

to display the last preset recipes or personal

recipes used.

Deleting the memory

If you wish to delete the memory:

1. Press the return knob from the clock

screen to display the last preset recipes

or personal recipes used.

2. Press and hold down the control knob for

a few seconds.

3. Select YES if you wish to delete the

memory.

The appliance language is set to

“English” by default.

When first connecting or after the

power has been cut for a time it

will be necessary to wait a few

seconds before you can interact

with the appliance.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Smeg Four

Smeg

Smeg SA301W-5 Manuel utilisateur

Smeg

Smeg SCP750AX8 Manuel utilisateur

Smeg

Smeg FS64MF Manuel utilisateur

Smeg

Smeg Oven Manuel utilisateur

Smeg

Smeg SFPA6603NX Manuel utilisateur

Smeg

Smeg 3961I Instructions de montage

Smeg

Smeg DOSPA38X Manuel d'installation et d'exploitation

Smeg

Smeg SA304X-8 Fiche technique

Smeg

Smeg SF170 Manuel utilisateur

Smeg

Smeg TRI90 Manuel utilisateur

Smeg

Smeg SF64M3DS Manuel utilisateur

Smeg

Smeg Galileo Steam100 Manuel utilisateur

Smeg

Smeg Electric Grill S340G Manuel utilisateur

Smeg

Smeg SF7390X Manuel utilisateur

Smeg

Smeg FC66B Manuel utilisateur

Smeg

Smeg SO4303APX Manuel utilisateur

Smeg

Smeg SOPA6102TS Manuel utilisateur

Smeg

Smeg FS9010CER Manuel utilisateur

Smeg

Smeg Electric Multifunction Pizza Oven 166PZ-5 Manuel utilisateur

Smeg

Smeg SY62MX9 Manuel utilisateur

Smeg

Smeg F610AN Manuel utilisateur

Smeg

Smeg SFPA9305SPX Manuel utilisateur

Smeg

Smeg SAC578X Manuel utilisateur

Smeg

Smeg CE92GPX Manuel utilisateur

Manuels Four populaires d'autres marques

Bosch

Bosch HVA531NS0 Manuel utilisateur

Electrolux

Electrolux EOF6P46X Manuel utilisateur

NEFF

NEFF B44S32 5GB Series Manuel utilisateur

Combi

Combi BLODGETT BC142GDS Manuel utilisateur

AEG

AEG COMPETENCE 311704300 Manuel utilisateur

Falcon

Falcon DOMINATOR PLUS G3106 Series Guide de l'utilisateur

Rational

Rational SCC WE 61G Manuel utilisateur

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuel utilisateur

Miele

Miele HR 1954-2 Manuel utilisateur

KHIND

KHIND OT50 Manuel utilisateur

Henny Penny

Henny Penny Smoker Box Manuel utilisateur

Lang

Lang ECOD-AP Manuel utilisateur

AEG

AEG BEK455310M Manuel utilisateur

Frigidaire

Frigidaire FNGE90JGR Manuel utilisateur

Hotpoint

Hotpoint FE9 S831 JSH IX Manuel utilisateur

GE Advantium SCB2000 Manuel utilisateur

AEG

AEG DE401301DM Manuel utilisateur

DeLonghi

DeLonghi XA660 Manuel
