SMC Networks EZ Switch SMCGS1610 Manuel utilisateur

USER GUIDE

EZ SwitchTM 10/100/1000

16/24-Port Gigabit Ethernet Plus Switch

SMCGS1610/SMCGS2410

No. 1, Creation Road III,

Hsinchu Science Park,

30077, Taiwan, R.O.C.

TEL: +886 3 5638888

Fax: +886 3 6686111

EZ SwitchTM 10/100/1000

User Guide

From SMC’s EZ line of low-cost workgroup LAN solutions

SMCGS1610/SMCGS2410

E112013-AP-R02

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate

and reliable. However, no responsibility is assumed by SMC for its use, nor for

any infringements of patents or other rights of third parties which may result

from its use. No license is granted by implication or otherwise under any patent

or patent rights of SMC. SMC reserves the right to change specifications at any

time without notice.

SMC Networks, Inc.

No. 1, Creation Road III,

Hsinchu Science Park,

30077, Taiwan, R.O.C.

Trademarks:

SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are

trademarks of SMC Networks, Inc. Other product and company names are

trademarks or registered trademarks of their respective holders.

– 4–

ARRANTY

AND

RODUCT

EGISTRATION

To register SMC products and to review the detailed warranty statement, please

refer to the Support Section of the SMC Website at http://www.smc.com.

– 5 –

COMPLIANCES AND SAFETY

STATEMENTS

FCC - CLASS A

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the

interference at his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

◆This device may not cause harmful interference.

◆This device must accept any interference received, including interference

that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

CE MARK DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC)

This is a class A product. In a domestic environment, this product may cause

radio interference, in which case the user may be required to take adequate

measures.

Declaration of Conformity (DoC) can be obtained from www.smc.com -> support

-> download

– 6 –

ABOUT THIS GUIDE

PURPOSE

This guide details the hardware features of the switch, including the physical and

performance-related characteristics, and how to install the switch.

AUDIENCE

The guide is intended for use by network administrators who are responsible for

installing and setting up network equipment; consequently, it assumes a basic

working knowledge of LANs (Local Area Networks).

CONVENTIONS

The following conventions are used throughout this guide to show information:

REVISION HISTORY

This section summarizes the changes in each revision of this guide.

NOVEMBER 2013 REVISION

This is the second revision of this guide. It includes the following change:

◆Updated the front panel image.

OTE

Emphasizes important information or calls your attention to

related features or instructions.

AUTION

Alerts you to a potential hazard that could cause loss of data,

or damage the system or equipment.

ARNING

Alerts you to a potential hazard that could cause personal

injury.

BOUT

HIS

UIDE

– 7 –

OCTOBER 2013 REVISION

This is the first revision of this guide.

– 8 –

CONTENTS

WARRANTY AND PRODUCT REGISTRATION 4

COMPLIANCES AND SAFETY STATEMENTS 5

ABOUT THIS GUIDE 6

CONTENTS 8

NTRODUCTION 10

Overview 10

Features 11

2HARDWARE DESCRIPTION 15

Front Panel 15

Port and System Status LEDs 15

RJ-45 Ports 16

Smart Button 16

Rear Panel 17

AC Power Socket 17

3INSTALLING THE SWITCH 18

Package Contents 18

Precautions 19

Safety Requirements 19

Location Requirements 19

Installation 20

Desktop Installation 20

Rack Installation 21

How to Connect to AC Power 22

Powering On 23

ONTENTS

– 9 –

Connecting Network Devices 24

Cabling Guidelines 24

Connecting to PCs, Servers, Hubs and Switches 24

ATROUBLESHOOTING 25

Diagnosing Switch Indicators 25

The Power LED is Off 25

The Link/Act LED is Off when a Device is Connected to the Corre-

sponding Port 25

Power and Cooling Problems 25

Installation 26

BSPECIFICATIONS 27

Physical Characteristics 27

– 10 –

1INTRODUCTION

OVERVIEW

The SMCGS1610 and SMCGS2410 are the first available unmanaged switches

that can be transformed into a smart switch with the use of a single button.

DHCP prevention combined with loopback detection and prevention, improves

the network environment and reduces network maintenance costs. The switches

also provide DoS attack protection, minimizing virus attacks and increasing

network uptime.

The SMCGS1610 and SMCGS2410 switches feature a non-blocking switching

architecture that forwards and filters packets at full wire-speed for maximum

throughput. The switches are compatible with all 10, 100, and 1000 Mbps

Ethernet devices because they are standard-based. The switches protect your

existing network investments while providing you with a straightforward

migration path to faster Gigabit speeds.

The SMCGS1610 and SMCGS2410 switches are plug-and-play devices; no

configuration is required. Auto MDI/MDI-X cable detection on all ports eliminates

the need for crossover cables. Each port can be used as an end-node or uplink

port, and any port can be simply plugged into a server, hub, router, or switch,

using straight-through or crossover cable. Diagnostic LEDs, which display link

status and activity, allow you to quickly detect and correct problems on the

network.
