SMC7204BRA

4-port ADSL Router with

built-in ADSL Modem (Annex A)

Model Number: SMC7204BRA

Quick Installation Guide

Guide d’installation rapide

Guía de inicio rápido

Beknopte installatiehandleiding

Manual de instalação rápida

4-port ADSL Router with built-in ADSL Modem

Routeur ADSL 4 ports avec modem ADSL intégré

Router ADSL de 4 puertos con módem ADSL integrado

4-poorts ADSL-router met ingebouwde ADSL-modem

Router ADSL de 4 Portas com Modem ADSL Integrado

English

Contents

•One ADSL BarricadeTM.

•One Power adapter.

•One RJ-45 Ethernet cable.

•One RJ-11 Standard phone/DSL line cable.

•One Installation utility and Documentation CD.

•Quick Installation Guide.

Note: ADSL splitters/microfilters are included with some models.

Package Contents

English 2 - 21

Français 22 - 41

Español 42 - 61

Nederlands 62 - 81

Português 82 - 101

Compliances & Information 102 - 110

Contents

Front Panel

English

Hardware Description

English

System Requirements

In order to use the ADSL BarricadeTM, you must have

the following:

•ADSL service up and running on your telephone line,

with at least one public Internet address for your LAN.

•One or more computers, each containing an Ethernet

10/100 Base-T network interface card (NIC).

•An Ethernet hub/switch, if you are connecting the device

to more than one computer on an Ethernet network.

•For system configuration using the supplied web-based

program: a web browser such as Internet Explorer V5.0

or later, or Netscape V6.1 or later.

LED Label

Color Status

Green Steady

Green Blink

Yellow Steady

Yellow Blink

OFF

Power

Green

Power On

N/A

Power Off

Link

Green

ADSL line

is trained.

Training

N/A

Connection

TX/RX

Green

DSL Transmitting/

Receiving

TX/RX

N/A

No TX/RX

Ethernet

1 2 3 4

Green / 100 Mbps

Yellow / 10 Mbps

Link

Transmitting/

Receiving

Link

Transmitting/

Receiving

No Connection

English

This Quick Installation Guide provides basic instructions for

connecting the ADSL BarricadeTM to a computer or LAN and to the

Internet.

•Section 1 describes how to set up the hardware.

•Section 2 describes how to configure Internet properties on

your computer(s).

•Section 3 shows you how to configure ISP settings using

Auto Setup utility.

This Guide assumes that you have already established an ADSL

service with your Internet service provider (ISP). These

instructions provide a basic configuration that should be

compatible with your home or small office network setup.

Rear Panel

Description

12V, 1.2A

If depressed for 1-2 seconds: reset.

If depressed for 5 seconds or more:

reset to factory default.

RJ-11 phone connector

Four 10/100M RJ-45 connectors

Rear Panel

Connector

Power Supply

Reset and Restore

Factory Defaults

Button

DSL Port

Ethernet Port

English

Connecting the Hardware

Warning: Before you begin, turn the power off for all devices.

These include your computer(s), your LAN hub/switch

(if applicable), and the ADSL BarricadeTM.

Step 1. Connect the ADSL cable

Connect one end of the provided phone cable (RJ-11) to the port

labeled DSL on the Rear Panel of the device. Connect the other

end to your ADSL Microfilter/Splitter*.

*Note: ADSL splitters/microfilters are included with some models.

Step 2. Connect the Ethernet cable

If you are connecting a LAN to the ADSL BarricadeTM, attach one

end of a provided Ethernet cable to hub/switch port and the other

to the Ethernet port on the ADSL BarricadeTM. If you are using the

ADSL BarricadeTM with a single computer and no hub, you must use

an Ethernet cable to attach the PC directly to the device.

Step 3. Attach the power connector

Connect the AC power adapter to the Power connector on the back

of the device and plug in the adapter to a wall outlet or power

strip.

Step 4. Power up your systems

Turn on and boot up your computer(s) and any LAN device such

as hubs or switches.

English

910

English

3. In the [LAN or High-Speed Internet] window, right-click on

the icon corresponding to your network interface card (NIC)

and select [Properties]. (Often, this icon is labeled [Local

Area Connection].) The [Local Area Connection] dialog box

displays a list of currently installed network items.

4. Ensure that the check box to the left of the item labeled

[Internet Protocol TCP/IP] is checked, and click [Properties].

5. In the [Internet Protocol (TCP/IP) Properties] dialog box,

click the radio button labeled [Obtain an IP address

automatically]. Also click the radio button labeled [Obtain

DNS server address automatically].

6. Click [OK] twice to confirm your changes, and close

the [Control Panel].

This section provides instructions for configuring the Internet

settings on your computers to work with the ADSL BarricadeTM.

Before you begin

By default, the ADSL BarricadeTM automatically assigns all required

Internet settings to your PCs. You need only to configure the PCs

to accept the information when it is assigned. Follow the

instructions that correspond to the operating system installed

on your PC.

Windows® XP

1. In the Windows task bar, click the [Start] button,

and then click [Control Panel].

2. Double-click the [Network Connections] icon.

Configuring

Your Computers

English

Windows 2000

First, check for the IP protocol and, if necessary, install it.

1. In the Windows task bar, click the [Start] button,

point to [Settings], and then click [Control Panel].

2. Double-click the [Network and Dial-up Connections] icon.

3. In the [Network and Dial-up Connections] window, right-click

the [Local Area Connection] icon, and then select

[Properties]. The [Local Area Connection Properties] dialog

box displays a list of currently installed network components.

If the list includes [Internet Protocol (TCP/IP)], then the

protocol has already been enabled. Skip to Step 10.

4. If [Internet Protocol (TCP/IP)] does not appear as

an installed component, click [Install…].

5. In the [Select Network Component Type] dialog box,

select [Protocol], and then click [Add…].

6. Select [Internet Protocol (TCP/IP)] in the [Network Protocols]

list, and then click [OK]. You may be prompted to install files

from your Windows 2000 installation CD or other media.

Follow the instructions to install the files.

7. If prompted, click [OK] to restart your computer with the new

settings. Next, configure the PCs to accept IP information

assigned by the ADSL BarricadeTM.

8. In the [Control Panel], double-click the [Network and Dial-up

Connections] icon.

English

9. In the [Network and Dial-up Connections] window, right-click

the [Local Area Connection] icon, and then select

[Properties].

10. In the [Local Area Connection Properties] dialog box, select

[Internet Protocol (TCP/IP)], and then click [Properties].

11. In the [Internet Protocol (TCP/IP) Properties] dialog box,

click the radio button labeled [Obtain an IP address

automatically]. Also click the radio button labeled [Obtain

DNS server address automatically].

12. Click [OK] twice to confirm and save your changes, and then

close the [Control Panel].

Windows 98/Me/SE

1. In the Windows task bar, click the [Start] button,

point to [Settings], and then click [Control Panel].

2. Double-click the [Network and Dial-up Connections] icon.

3. In the [Network and Dial-up Connections] window, right-click

the [Network] icon, and then select [Properties]. The [Network

Properties] dialog box displays a list of currently installed

network components. If the list includes [Internet Protocol

(TCP/IP)], then the protocol has already been enabled. Skip to

Step 11.

English

9. In the [Control Panel], double-click the [Network and Dial-up

Connections] icon.

10. In the [Network and Dial-up Connections] window, right-click

the [Network] icon, and then select [Properties].

11. In the [Network Properties] dialog box, select [TCP/IP],

and then click [Properties].

12. In the [TCP/IP Settings] dialog box, click the radio button

labeled [Server assigned IP address]. Also click the radio

button labeled [Server assigned name server address].

13. Click [OK] twice to confirm and save your changes,

and then close the Control Panel.

Note: For Windows 95 and NT, please see the installation

instructions in the User Guide contained on the CD Rom.

4. If [Internet Protocol (TCP/IP)] does not appear as

an installed component, click [Add…].

5. In the [Select Network Component Type] dialog box,

select [Protocol], and then click [Add…].

6. Select [Microsoft] in the [Manufacturers] box.

7. Select [Internet Protocol (TCP/IP)] in the [Network Protocols]

list, and then click [OK]. You may be prompted to install files

from your Windows Me installation CD or other media. Follow

the instructions to install the files.

8. If prompted, click [OK] to restart your computer with the new

settings. Next, configure the PCs to accept IP information

assigned by the ADSL BarricadeTM.

English

This section provides instructions on how to use the Auto Setup

utility for configuration of the ADSL BarricadeTM for your ISP.

1. Insert the Installation utility and Documentation CD into

your CD drive.

2. Browse to the location of your CD drive and run AutoSetup.exe.

This will start the Auto Setup utility, which provides an easy

way to configure the ADSL BarricadeTM for your ISP.

3. Click [Yes, I agree] to accept terms of license agreement

and continue with the setup.

Configuring

the ADSL BarricadeTM

4. Select your country from the drop down list, then click [Next]

to continue. If your country is not listed, click [Custom] and

skip to section Custom.

5. Select your ISP/Network provider from the drop down list, then

click [Next] to continue. If your ISP/Network Provider is not

listed, click [Custom] and skip to section Custom.

6. Enter the Username and password supplied by your ISP, then

click [Next] to continue.

Note: You will only be required to enter a username and password if

your ISP uses protocol PPPoA or PPPoE. If your ISP uses

RFC1483 Bridging no further input is required, simply click

[Next] to continue.

If your ISP uses RFC1483 Routed after clicking [Next] you

will be required to enter the IP address, Netmask, Gateway

address, Primary and Secondary DNS address supplied by

your ISP. Click [Next].

Autres manuels pour Barricade SMC7204BRA

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels SMC Networks Routeur réseau

SMC Networks

SMC Networks SMC-EZ1026DT Manuel utilisateur

SMC Networks

SMC Networks SMC6752AL2 Manuel utilisateur

SMC Networks

SMC Networks TIGERSWITCH 10/100 Manuel de programmation

SMC Networks

SMC Networks WUSB32 Manuel utilisateur

SMC Networks

SMC Networks GS501 Manuel utilisateur

SMC Networks

SMC Networks 7204BRB Manuel utilisateur

SMC Networks

SMC Networks KER25U Manuel utilisateur

SMC Networks

SMC Networks SMC108DT Manuel utilisateur

SMC Networks

SMC Networks Barricade SMC7401BRA Manuel utilisateur

SMC Networks

SMC Networks 2304WBR-AG Manuel utilisateur

SMC Networks

SMC Networks 7824M/VSW Manuel utilisateur

SMC Networks

SMC Networks Barricade SMC7904BRA Manuel utilisateur

SMC Networks

SMC Networks Barricade SMC7204BRA Manuel utilisateur

SMC Networks

SMC Networks SMC Barricade Plus SMC7004WFW Manuel utilisateur

SMC Networks

SMC Networks SMCFS1601 - FICHE TECHNIQUE Instructions d'utilisation et de sécurité

SMC Networks

SMC Networks 7401BRA V.2 Manuel utilisateur

SMC Networks

SMC Networks SMCGS501P Manuel utilisateur

SMC Networks

SMC Networks Barricade SMC7004ABR Manuel utilisateur

SMC Networks

SMC Networks SMCWEBT-G Manuel utilisateur

SMC Networks

SMC Networks FS8 - FICHE TECHNIQUE Instructions d'utilisation et de sécurité

SMC Networks

SMC Networks 7724M/VSW - annexe 1 Manuel utilisateur

SMC Networks

SMC Networks SMCGS502 - FICHE TECHNIQUE Instructions d'utilisation et de sécurité

SMC Networks

SMC Networks Barricade SMC7004ABR Manuel utilisateur

SMC Networks

SMC Networks 8708L2 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
