Preface

The following operating instructions contain all the required information required for

commissioning and operating a device from the SIMATIC family.

Basic knowledge required

A prerequisite for understanding this manual is knowledge of how to use a PC. Basic

knowledge of automation technology as well as IoT technologies is also recommended.

Scope of this document

These operating instructions apply to the SIMATIC FDE Gateway device.

MLFB: 6ES7617-0BA01-0AB0

FDE conventions

The following generic terms are used in this documentation:

Generic term

Specific designation

Device

SIMATIC FDE Gateway

Change directory

The following versions of these operating instructions have been published:

Edition

Comment

05/2023

First edition

SIMATIC FDE Gateway V1

6Equipment Manual, 05/2023, A5E52683268-AB

Siemens Industry Online Support

You can find current information on the following topics quickly and easily here:

•Product support

All the information and extensive know-how on your product, technical specifications,

FAQs, certificates, downloads, and manuals.

•Application examples

Tools and examples to solve your automation tasks – as well as function blocks,

performance information and videos.

•Services

Information about Industry Services, Field Services, Technical Support, spare parts and

training offers.

•Forums

For answers and solutions concerning automation technology.

•mySupport

Your personal working area in Industry Online Support for messages, support queries, and

configurable documents.

This information is provided by the Siemens Industry Online Support in the Internet

(https://support.industry.siemens.com).

SIMATIC FDE Gateway V1

Equipment Manual, 05/2023, A5E52683268-AB 7

Introduction

3.1 Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, systems, machines and networks.

In order to protect plants, systems, machines and networks against cyber threats, it is

necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial

security concept. Siemens’ products and solutions constitute one element of such a concept.

Customers are responsible for preventing unauthorized access to their plants, systems,

machines and networks. Such systems, machines and components should only be connected

to an enterprise network or the internet if and to the extent such a connection is necessary

and only when appropriate security measures (e.g. firewalls and/or network segmentation)

are in place.

For additional information on industrial security measures that may be implemented, please

visit (https://www.siemens.com/industrialsecurity).

Siemens' products and solutions undergo continuous development to make them more

secure. Siemens strongly recommends that product updates are applied as soon as they are

available and that the latest product versions are used. Use of product versions that are no

longer supported, and failure to apply the latest updates may increase customers' exposure to

cyber threats.

To stay informed about product updates, subscribe to the Siemens Industrial Security RSS

Feed visit (https://www.siemens.com/cert).

3.2 IT security on the northbound side

Ensure sufficient IT security on the northbound side. "Control activities" have a special risk.

We urgently recommend not making the web interface available at any location other than at

the production network.

Note

Proper user administration required

Select one dedicated access token / login information per device.

Introduction

3.3 IT security on the southbound side

SIMATIC FDE Gateway V1

8Equipment Manual, 05/2023, A5E52683268-AB

3.3 IT security on the southbound side

The FDE Gateway provides field data in IT environments.

Ensure that the outputs of the device are not used to control automation processes, but

solely for signaling purposes.

Make sure to protect the southbound connection in accordance with currently recognized

security guidelines. This prevents spying on the field data. More information and application

notes can be found here: (https://www.siemens.com/industrialsecurity)

3.4 Personal data

During the configuration of the FDE gateway, it is possible to store user-specific data such as

certificates, usernames, and access passwords. This data is stored on the device and, if

necessary, used service-specifically during operation. To erase this data, it is necessary to

reset the device to factory settings, see (Page 49).

SIMATIC FDE Gateway V1

Equipment Manual, 05/2023, A5E52683268-AB 9

Overview of the technical documentation

The documents listed below are a selection to support you with the planning, installation,

and commissioning, up to the analysis of your application. For more documents on other

hardware or specific information, please visit SIEMENS SiePortal.

(https://sieportal.siemens.com/)

4.1 SIMATIC products

You can find an overview of the SIMATIC documentation available in Siemens Industry Online

Support here:

Industry Online Support International

(https://support.industry.siemens.com/cs/ww/en/view/109742705)

4.2 SINAMICS products

SIMATIC FDE Gateway enables connection to the following drives:

•SINAMICS V20

•SINAMICS G120 series (except G120D)

•MICROMASTER 420/430/440

The connection is established via USS/RS232.

SINAMICS G120C low voltage converter

Operating instructions

The operating instructions (https://support.industry.siemens.com/cs/ww/en/view/109782995)

also contain information for special applications. Since sound prior knowledge of the

configuration and parameter assignment of these applications can be assumed, the

information is given in a concise form. This applies, for example, to operation with fieldbus

systems.

List Manual

The List Manual (https://support.industry.siemens.com/cs/ww/en/view/109817922) contains a

detailed description of all parameters and a series of function charts as well as error and

alarm messages.

Overview of the technical documentation

4.2 SINAMICS products

SIMATIC FDE Gateway V1

10 Equipment Manual, 05/2023, A5E52683268-AB

MICROMASTER 440 frequency converter

Operating instructions

The operating instructions (https://support.industry.siemens.com/cs/ww/en/view/24294529)

provide information about characteristics of the MICROMASTER 440 as well as the

installation, commissioning, control modes, system parameter structure, troubleshooting,

technical specifications, and options.

Parameter list

The parameter list (https://support.industry.siemens.com/cs/ww/en/view/23708204) contains

a detailed description of all parameters, ordered by function. It also contains a series of

function charts as well as error and alarm messages.

MICROMASTER 430 frequency converter

Operating instructions

The operating instructions (https://support.industry.siemens.com/cs/ww/en/view/24479264)

provide information about characteristics of the MICROMASTER 430 as well as the

installation, commissioning, control modes, system parameter structure, troubleshooting,

technical specifications, and options.

Parameter list

The parameter list (https://support.industry.siemens.com/cs/ww/en/view/24479411) contains

a detailed description of all parameters, ordered by function. In addition, the parameter list

contains function charts with graphical representations of the converter functions.

MICROMASTER 420 frequency converter

Operating instructions

The operating instructions (https://support.industry.siemens.com/cs/ww/en/view/24523400)

provide information about characteristics of the MICROMASTER 420 as well as the

installation, commissioning, control modes, system parameter structure, troubleshooting,

technical specifications, and options.

Parameter list

The parameter list (https://support.industry.siemens.com/cs/ww/en/view/24525275) contains

a detailed description of all parameters, ordered by function. In addition, the parameter list

contains function charts with graphical representations of the converter functions.

SINAMICS V20 frequency converter

Operating instructions

The operating instructions (https://support.industry.siemens.com/cs/ww/en/view/109811111)

contain information on the installation, commissioning, operation, and maintenance of the

SINAMICS V20 frequency converter.

Autres manuels pour SIMATIC FDE

Autres manuels Siemens Porte

Siemens

Siemens SIMATIC PN/J1939 LINK Manuel utilisateur

Siemens

Siemens Gigaset Optical LAN Adapter Duo Manuel utilisateur

Siemens

Siemens NK8237 MP4.81-02 Guide rapide

Siemens

Siemens NK8237 MP4.40 Manuel de la liste des pièces

Siemens

Siemens HiPath HG 1500 Manuel utilisateur

Siemens

Siemens FDCW221 Manuel utilisateur

Siemens

Siemens FDCW241 Manuel utilisateur

Siemens

Siemens Gigaset SE568 Manuel utilisateur

Siemens

Siemens SMG 71 Manuel utilisateur

Siemens

Siemens A53457 Guide de maintenance et de service

Siemens

Siemens SIMATIC NET IE/WSN-PA Link Guide de l'administrateur

Siemens

Siemens SIMATIC IOT2050 Manuel utilisateur

Siemens

Siemens Gigaset SX686 WiMAX Manuel utilisateur

Siemens

Siemens SpeedStream 6500 Series Manuel utilisateur

Siemens

Siemens GAMMA 5WG1 143-1AB01 Manuel de service

Siemens

Siemens SpeedStream 6500 Series Manuel utilisateur

Siemens

Siemens DESIGO RXC Manuel utilisateur

Siemens

Siemens SpeedStream 6500 Series Manuel utilisateur

Siemens

Siemens Instabus/DALI Gateway N 141 Manuel utilisateur

Siemens

Siemens SIMATIC Manuel utilisateur

Siemens

Siemens SIMATIC IOT2050 Manuel utilisateur

Siemens

Siemens SIMATIC IOT Manuel utilisateur

Siemens

Siemens HG 3500 V4 Manuel utilisateur

Siemens

Siemens SIMATIC IOT Gateway MQTT Guide de l'utilisateur

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
