Digital input module DI 8xNAMUR (6ES7131-6TF00-0CA0)

ET 200SP

02/2014Edition

Answers for industry.

SIMATIC

DI 8xNAMUR HF digital input module

(6ES7131-6TF00-0CA0)

___________________

SIMATIC

ET 200SP

DI 8xNAMUR HF

digital input module

(6ES7131-6TF00-0CA0)

Manual

02/2014

A5E03894478

-01

Preface

Guide to documentation

Product overview

Wiring

Parameters/address space

Interrupts/diagnostics alarms

Technical specifications

Parameter data record

Siemens AG

Industry Sector

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E03894478-01

Ⓟ

02/2014 Technical data subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by

personnel qualified

for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)

Manual, 02/2014, A5E03894478-01 3

Preface

Purpose of the documentation

This device manual complements the system manual ET 200SP distributed I/O system

(http://support.automation.siemens.com/WW/view/en/58649293). Functions that generally

relate to the system are described in this manual.

The information provided in this manual and in the system/function manuals supports you in

commissioning the system.

Conventions

Please also observe notes marked as follows:

Note

A note contains important information on the product described in the documentation, on the

handling of the product and on the section of the documentation to which particular attention

should

be paid.

Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, solutions, machines, equipment and/or networks. They are

important components in a holistic industrial security concept. With this in mind, Siemens’

products and solutions undergo continuous development. Siemens recommends strongly

that you regularly check for product updates.

For the secure operation of Siemens products and solutions, it is necessary to take suitable

preventive action (e.g. cell protection concept) and integrate each component into a holistic,

state-of-the-art industrial security concept. Third-party products that may be in use should

also be considered. You can find more information about industrial security on the Internet

(http://www.siemens.com/industrialsecurity).

To stay informed about product updates as they occur, sign up for a product-specific

newsletter. You can find more information on the Internet

(http://support.automation.siemens.com).

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)

4Manual, 02/2014, A5E03894478-01

Table of contents

Preface ................................................................................................................................................... 3

1 Guide to documentation .......................................................................................................................... 5

2 Product overview .................................................................................................................................... 7

2.1 Properties...................................................................................................................................... 7

3 Wiring ..................................................................................................................................................... 9

3.1 Pin assignment.............................................................................................................................. 9

3.2 Block diagram ............................................................................................................................. 10

4 Parameters/address space ................................................................................................................... 11

4.1 Parameters.................................................................................................................................. 11

4.2 Explanation of parameters .......................................................................................................... 13

4.3 Pulse stretching........................................................................................................................... 16

4.4 Address space ............................................................................................................................ 18

5 Interrupts/diagnostics alarms................................................................................................................. 19

5.1 Status and fault displays ............................................................................................................. 19

5.2 Interrupts ..................................................................................................................................... 22

5.3 Diagnostics alarms...................................................................................................................... 24

5.4 Diagnostics for changeover contact sensor type ........................................................................ 25

5.5 Chatter monitoring....................................................................................................................... 26

6 Technical specifications ........................................................................................................................ 29

6.1 Technical specifications .............................................................................................................. 29

A Parameter data record .......................................................................................................................... 32

A.1 Dependencies when configuring with GSD files ......................................................................... 32

A.2 Parameter assignment and structure of parameter data record ................................................. 33

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)

Manual, 02/2014, A5E03894478-01 5

Guide to documentation

Introduction

This modular documentation of the SIMATIC products covers diverse topics concerning your

automation system.

The complete documentation for the ET 200SP distributed I/O system consists of a system

manual, function manuals and product manuals.

The STEP 7 information system (online help) also supports you during the configuration and

programming of your automation system.

Overview of documentation for digital input module DI 8×NAMUR HF

The following table shows additional documentation that you need for using the

DI 8×NAMUR HF digital input module.

Table 1- 1 Documentation for the DI 8×NAMUR HF digital input module

Topic

Documentation

Key contents

System description System manual ET 200SP distributed

I/O system

(http://support.automation.siemens.co

m/WW/view/en/58649293)

•Application planning

•Installation

•Wiring

•Commissioning

Designing interference-

free controllers

Function manual Designing

interference-free controllers

(http://support.automation.siemens.co

m/WW/view/en/59193566)

•Basics

•Electromagnetic compatibility

•Lightning protection

System diagnostics Function manual

Diagnostics

(http://support.automation.siemens.co

m/WW/view/en/59192926)

•Overview

•Diagnostics evaluation of

hardware/software

BaseUnits Manual ET 200SP BaseUnits

(http://support.automation.siemens.co

m/WW/view/en/58532597/133300)

Technical specifications

Amendments and special

features of the

ET 200SP I/O system

ET 200SP Product information

(http://support.automation.siemens.co

m/WW/view/en/73021864)

Current information not yet

documented in the system

manuals, function manuals, or

product manuals.

Guide to documentation

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)

6Manual, 02/2014, A5E03894478-01

SIMATIC manuals

All current manuals for SIMATIC products are available to download free of charge on the

Internet (http://www.siemens.com/simatic-tech-doku-portal).

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)

Manual, 02/2014, A5E03894478-01 7

Product overview

2.1

Properties

Order number

6ES7131-6TF00-0CA0

View of the module

Figure 2-1 View of the DI 8×NAMUR HF module

Product overview

2.1 Properties

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)

8Manual, 02/2014, A5E03894478-01

Properties

The module has the following technical properties:

●8 digital inputs each with a value status (quality information)

●8.2 VDC sensor supply for individual connection and disconnection (PROFIenergy)

●Selectable diagnostics (per channel)

●Suitable for connecting NAMUR sensors and connected and unconnected mechanical

contacts

The module supports the following technology functions:

●Pulse stretching

●Chatter monitoring

●Diagnostics for changeover contact sensor type

The module supports the following functions:

●Firmware update

●Identification data I&M0 to I&M3

●Reconfiguration in RUN

You can configure the module with STEP 7 (TIA Portal) and with a GSD file.

Accessories

The following accessories can be ordered separately:

●Labeling strips

●Color identification labels

●Reference identification label

●Shield connection

You can find additional information on the accessories in the ET 200SP distributed

I/O system (http://support.automation.siemens.com/WW/view/en/58649293) system manual.
