Operation

The CERBERUS PYROTRONICSTM Model LP-30

Remote Station (Leased Line) module, is designed to

transmit Alarm and Trouble signals from a protected

property to a fire headquarters, central station, or

other similar supervised control center, via leased

telephone lines. It meets the requirements of NEMA

Standards and NFPA Standard No. 72C for remote

station protective signaling systems so that it may be

used with a CERBERUS PYROTRONICSTM Model

LLA-5 receiving unit or with any other annunciator

designed to these same two standards. Actuation of

the module is from an alarm output signal from any

type ZU Zone Module or type TS Two Stage module,

along with that from the main control panel.

The module contains solid state circuitry to supply 24

VDC power for the alarm signal and supervision of the

dedicated lines. The unit, which has built-in surge

protection, operates on the polarity reversal principle.

Under normal operating conditions the supervisory or

alarm signal current is held between 3mA and 9mA

DC. The total maximum load resistance of the leased

line circuit, including the receiving equipment, is 5K

ohms. Two input activation terminals are provided for

flexibility of programming. The LP-30 must be used

with an LLM-1.

The module also contains a manually operated

disconnect switch which prevents an alarm signal from

being transmitted over the leased lines when desired

or during system tests. Operation of the switch will

illuminate the yellow Disconnect LED and cause a

system trouble condition. The LED will remain illumi-

nated during an alarm condition, and can be lamp

tested by operating the disconnect switch.

Installation

1. Mount the module to the horizontal mounting

brackets in the control enclosure.

2. Install the Model JA-5 (5 in long) bus connector

cable assembly between receptacle P2 of the

module and receptacle P1 of the module or

control panel immediately preceding it on the

bus.

Note: If the preceding module is on another row

in the enclosure, a JA-24 (24 in long) bus

connector cable assembly will be re-

quired.

3. Modules are to be bus-connected from right to

left. For two-row enclosures, the modules in the

lower row are to be connected from left to right.

Succeeding rows are to be alternately con-

nected, right to left, left to right, etc.

4. If a module is the last module in the system,

install either a JS-30 (30 in long) or JS-64 (64 in

long) bus connector assembly from the unused

receptacle of the last module to terminal 41* of

the CP-35 control panel. This completes the

module supervision circuit.

5.Wire terminals as shown in the Typical Wiring

illustration on the back of this sheet.

Troubleshooting

If a trouble condition is indicated in the LP-30, be sure

the disconnect switch is returned to Normal position.

*Terminal 17 of CP-30

Terminal 15 of CP-31

P/N 315-021309-5

Cerberus Division

Operation and Installation Instructions

CERBERUS PYROTRONICSTM

Model LP-30

Remote Station Module

Siemens Building Technologies, Inc.

8 Fe nwood Road

Flo ham Pa k, New Je sey 07932

Siemens Building Technologies, Ltd.

50 East Pea ce St eet

Richmond Hill, Onta io L4B 1B7 CN

P/N 315-021309-5
