Oil Burner Controls LAL...

Oil burner controls

•With or without air pressure supervision for checked air damper control

•Flame supervision

– with photoresistive detector QRB1...

– or blue-flame detector QRC1...

– or selenium photocell detector RAR...

The LAL... and this Data Sheet are intended for OEMs which integrate the oil

burner controls in their products!

Use

-For the control and supervision of oil atomization burners

-For burners of medium to high capacity

-For intermittent operation (at least one controlled shutdown every 24 hours)

-Can be universally used with multistage or modulating burners

-Suited for use with stationary air heaters

LAL1... - Yellow- and blue-flame burners without air pressure supervision

LAL2... - Yellow-flame burners with air pressure supervision

LAL3.25 - For special applications, e.g. burners of incinerator plant

(for details, refer to «Type summary» and «Notes»)

LAL4... - Yellow- and blue-flame burners with air pressure supervision

For burner controls used in connection with burners for continuous operation, refer to

Data Sheet 7785 (LOK16...).
