SIMATIC

S7-1500

CPU 1511-1 PN

(6ES7511-1AK00-0AB0)

Manual

01/2013

A5E31264526-AA

Preface

Documentation guide

Product overview

Wiring

Interrupts, diagnostics, error,

and system messages

Technical specifications

Dimensional drawing

Siemens AG

Industry Sector

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E31264526-AA

Ⓟ 01/2013 Technical data subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

Manual, 01/2013, A5E31264526-AA 3

Preface

Purpose of the documentation

This device manual supplements the system manual of the S7-1500 automation system

and the function manuals. All cross-system functions are described in the system manual.

The information provided in this device manual and the system manual enables you to

commission the CPU 1511-1 PN.

Conventions

Please also observe notes marked as follows:

Note

A note contains important information on the product described in the documentation,

on the handling of the product and on the section of the documentation to which particular

attention should be paid.

Note on IT security

Siemens offers IT security mechanisms for its automation and drive product portfolio in order

to support the safe operation of the plant/machine. We recommend that you inform yourself

regularly on the IT security developments regarding your products. You can find information

on this on the Internet (http://support.automation.siemens.com).

You can register for a product-specific newsletter here.

For the safe operation of a plant/machine, however, it is also necessary to integrate the

automation components into an overall IT security concept for the entire plant/machine,

which corresponds to the state-of-the-art IT technology. You can find information on this

on the Internet (http://www.siemens.com/industrialsecurity).

Products used from other manufacturers should also be taken into account here.

Preface

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

4 Manual, 01/2013, A5E31264526-AA

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

Manual, 01/2013, A5E31264526-AA 5

Table of contents

Preface ...................................................................................................................................................... 3

1 Documentation guide................................................................................................................................. 7

2 Product overview ....................................................................................................................................... 9

2.1 Properties.......................................................................................................................................9

2.2 Operating and display elements ..................................................................................................12

2.2.1 Front view of the module with front panel ....................................................................................12

2.2.2 Front view of the module without front panel...............................................................................14

2.2.3 Rear view of the module ..............................................................................................................15

2.3 Mode selector switch ...................................................................................................................15

2.4 Functions......................................................................................................................................16

2.4.1 PROFINET IO ..............................................................................................................................16

2.4.2 PROFIenergy ...............................................................................................................................17

2.4.3 Memory reset ...............................................................................................................................17

2.4.4 Restoring the factory settings of the CPU....................................................................................19

3 Wiring ...................................................................................................................................................... 21

4 Interrupts, diagnostics, error, and system messages............................................................................... 25

4.1 Status and error display of the CPU ............................................................................................25

5 Technical specifications........................................................................................................................... 29

A Dimensional drawing ............................................................................................................................... 39

Table of contents

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

6 Manual, 01/2013, A5E31264526-AA

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

Manual, 01/2013, A5E31264526-AA 7

Documentation guide 1

Introduction

The documentation of the SIMATIC products has a modular structure and covers

a range of topics concerning your automation system.

The complete documentation for the S7-1500 system consists of a system manual,

function manuals and device manuals.

The STEP 7 information system (Online Help) also helps you to configure and program

your automation system.

Overview of the documentation for CPU 1511-1 PN

The following table lists additional documents which supplement this description

of CPU 1511-1 PN and are available on the Internet.

Table 1- 1 Documentation for CPU 1511-1 PN

Topic Documentation Most important contents

System

description

S7-1500 Automation System

(http://support.automation.siemens.com/

WW/view/en/59191792) system manual

•Application planning

•Installation

•Wiring

•Commissioning

Power supplies

(http://support.automation.siemens.com/

WW/view/en/57251228) device manual

Properties of the

modules

Signal modules

(http://support.automation.siemens.com/

WW/view/en/59174020) device manual

•Wiring

•Parameter assignment/

addressing

•Interrupts, diagnostics, error,

and system messages

•Technical specifications

•Dimensional drawing

System

diagnostics

System diagnostics

(http://support.automation.siemens.com/

WW/view/en/59192926) function

manual

•Overview

•Hardware/software diagnostic

evaluation

Documentation guide

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

8 Manual, 01/2013, A5E31264526-AA

Topic Documentation Most important contents

Communication

(http://support.automation.siemens.com/

WW/view/en/59192925) function

manual

•Overview

PROFINET with STEP 7 V12

(http://support.automation.siemens.com/

WW/view/en/49948856) function

manual

•PROFINET basics

•PROFINET functions

•PROFINET diagnostics

Communication

Web server

(http://support.automation.siemens.com/

WW/view/en/59193560) function

manual

•Function

•Operation

Designing

interference-free

controllers

Designing interference-free controllers

(http://support.automation.siemens.com/

WW/view/en/59193566) function

manual

•Basics

•Electromagnetic compatibility

•Lightning protection

•Housing selection

Memory concept Structure and use of the CPU memory

(http://support.automation.siemens.com/

WW/view/en/59193101) function

manual

•Setup

•Function principle

•Use

Cycle and

response times

Cycle and response times

(http://support.automation.siemens.com/

WW/view/en/59193566) function

manual

•Basics

•Calculations

Analog value

processing

Analog value processing

(http://support.automation.siemens.com/

WW/view/en/59193559) function

manual

•Wiring options

•Tables of measured values

SIMATIC manuals

All current manuals for SIMATIC products are available for download free of charge from

the Internet (http://www.siemens.com/automation/service&support).

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

Manual, 01/2013, A5E31264526-AA 9

Product overview 2

2.1 Properties

Order number

6ES7511-1AK00-0AB0

View of the module

The following figure shows a CPU 1511-1 PN.

Figure 2-1 CPU 1511-1 PN

Product overview

2.1 Properties

CPU 1511-1 PN (6ES7511-1AK00-0AB0)

10 Manual, 01/2013, A5E31264526-AA

Properties

The module has the following technical properties:

● Communication:

– Interfaces

The CPU 1511-1 PN has a PROFINET interface with two ports. The two ports have

the same IP address and form the interface to the fieldbus level (switch functionality).

– Integrated Web server

The CPU status query is independent of a software installation. Graphically visualized

process variables and user-defined websites facilitate information acquisition.

● Trace functionality

– All CPUs of the S7-1500 automation system support trace functionality.

Trace functionality is independent of the technology and supports you in

debugging/optimizing the user program. It is particularly useful for Motion Control

and control applications.

● Integrated technology:

– Standard Motion Control

PLC Open blocks for programming motion functionality by means

of PROFINET IO IRT and PROFIdrive interface.

The functionality supports speed-controlled axes, positioning axes

and external encoders.

– Integrated control functionality

Universal PID controllers or 3-point controllers with integrated tuning.

Integrated temperature controller

● Integrated system diagnostics:

– System diagnostics is automatically generated and consistently displayed.

● Integrated security:

– Know-how protection

User programs can be securely protected against unauthorized access and

modification.

– Copy protection

User program blocks are linked to the serial number of the SIMATIC memory card

or of the module. User programs cannot run without the corresponding

SIMATIC memory card or module.

– Access protection

Extended access protection provides comprehensive protection against unauthorized

configuration changes. Authorization levels can be used to assign separate rights to

different user groups.

– Integrity protection

The system protects the data transferred to the CPU from unauthorized manipulation.

Altered or external transmission of engineering data is reliably detected by the CPU.

Autres manuels pour Simatic S7-1500

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Siemens Matériel informatique

Siemens

Siemens SIMATIC NET CP 5603 Manuel utilisateur

Siemens

Siemens CPU 412-1 Manuel utilisateur

Siemens

Siemens Fujitsu D1159 Manuel utilisateur

Siemens

Siemens SPEEDSTREAM SS1021 Manuel utilisateur

Siemens

Siemens Simatic S7-300 31xC Series Manuel utilisateur

Siemens

Siemens CP 5613 A3 Manuel utilisateur

Siemens

Siemens Gigaset PC Card 108 Manuel utilisateur

Siemens

Siemens CP 5623 Manuel utilisateur

Siemens

Siemens PAD-5 Series Manuel utilisateur

Siemens

Siemens LMV50 series Manuel utilisateur

Siemens

Siemens SIMATIC S7-1200 CP 1243-8 IRC Manuel utilisateur

Siemens

Siemens SIMATIC NET CP 1411 Manuel utilisateur

Siemens

Siemens SIMATIC NET 6GK7 443-5FX02-0XE0 Manuel utilisateur

Siemens

Siemens CP 1612 A2 Manuel utilisateur

Siemens

Siemens SIMATIC CP 541 Manuel utilisateur

Siemens

Siemens Gigaset USB adapter 54 Manuel utilisateur

Siemens

Siemens Simatic S7-300 Manuel d'instructions

Siemens

Siemens TC65 Manuel utilisateur

Siemens

Siemens SIMATIC CP 341 Manuel utilisateur

Siemens

Siemens DP/AS-Interface Link 20E Manuel utilisateur

Siemens

Siemens SIMATIC NET CP 5512 Manuel utilisateur

Siemens

Siemens SIMATIC CP 340 Manuel utilisateur

Siemens

Siemens SPCN910 Manuel utilisateur

Siemens

Siemens CPU 31 Series Manuel d'instructions

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
