Siemens CP 5613 A3 Manuel utilisateur
CP 5613 A3 / CP 5614 A3
_
_________________
_
_
_________________
_
_
_______________
_
__
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
SIMATIC NET
PG/PC - PROFIBUS
CP 5613 A3 / CP 5614 A3
Operating Instructions
10/2012
C79000-G8976-C277-01
Preface
Description of the device
1
Software installation
2
Hardware installation
3
Configuration
4
Technical specifications
5
Approvals
A
Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the relevant information is not taken into account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
Order number: C79000-G8976-C277
Ⓟ 06/2012 Technical data subject to change
Copyright © Siemens AG 2012.
All rights reserved
CP 5613 A3 / CP 5614 A3
Operating Instructions, 10/2012, C79000-G8976-C277-01 3
Preface
What the consignment contains
The following components are supplied with the CP 5613 A3 / CP 5614 A3:
● Communications processor CP 5613 A3 or communications processor CP 5614 A3
● SIMATIC NET DVD including
– SIMATIC NET PC software
– Manual Collection
● Certificate of license
Please check that the consignment you have received is complete. If it is not complete,
please contact your supplier or your local Siemens office.
Validity of this documentation
These operating instructions are valid for the following products:
● CP 5613 A3
order number: 6GK1 561-3AA02
● CP 5614 A3
order number: 6GK1 561-4AA02
Content of this documentation
These operating instructions contain information about the installation and configuration of
the 5613 A3 and CP 5614 A3 communications processors.
Updated operating instructions on the Internet
You will find the current version of these operating instructions on the Product Support pages
under the following entry ID:
58826514 (http://support.automation.siemens.com/WW/view/en/58826514)
Further documentation
The documents listed below contain more detailed information on commissioning and using
the communications processor. You will find this documentation on the Product Support
pages on the Internet under the following entry link:
Support (http://support.automation.siemens.com/WW/view/en)
Enter the entry ID shown below of the relevant manual as the search item.
Preface
CP 5613 A3 / CP 5614 A3
4 Operating Instructions, 10/2012, C79000-G8976-C277-01
● Configuration manual Commissioning PC Stations
This provides you with detailed information on commissioning and configuring SIMATIC
NET PROFIBUS communications modules.
Entry ID:
13542666 (http://support.automation.siemens.com/WW/view/en/13542666)
● System manual SIMATIC NET Industrial Communication with PG/PC
– Volume 1– Basics
Entry ID:
42783968 (http://support.automation.siemens.com/WW/view/en/42783968)
– Volume 2– Interfaces
Entry ID:
42783660 (http://support.automation.siemens.com/WW/view/en/42783660)
The system manuals introduce the topic of industrial communication and explain the
communications protocols used. There is also a description of the OPC interface as
user programming interface.
● Installation manual SIMATIC NET PC Software
This document contains detailed information on installing the SIMATIC NET
PC software.
Entry ID:
42784913 (http://support.automation.siemens.com/WW/view/en/42784913)
● System manual PROFIBUS Network Manual
In this document you will find detailed information about setting up a PROFIBUS network.
Entry ID:
35222591 (http://support.automation.siemens.com/WW/view/en/35222591)
SIMATIC NET documentation
You will find the entire SIMATIC NET documentation on the pages of Product Support:
10805878 (http://support.automation.siemens.com/WW/view/en/10805878)
Go to the required product group and make the following settings:
→ Entry list → Entry type "Manuals / Operating Instructions"
Online support
In addition to our product documentation, the comprehensive online information platform
supports you in all aspects of our Service & Support at any time and from any location in the
world. You will find this on the Internet at the following address:
(http://support.automation.siemens.com/WW/llisapi.dll?func=cslib.csinfo2&aktprim=99&lang=
en)
Preface
CP 5613 A3 / CP 5614 A3
Operating Instructions, 10/2012, C79000-G8976-C277-01 5
Here, you will find the following information:
● Support news, newsletter
● Product information, Product Support, Applications & Tools
● Technical Forum
● Access to other features of our Service & Support offer:
– Technical Consulting
– Engineering Support
– Field Service
Phone: +49 (0)911 895 7444
– Spare parts and repairs
Phone: +49 (0)911 895 7448
– Optimization and modernization
– Technical Support
Expert advice on technical questions with a wide range of demand-optimized services
for all our products and systems.
Phone: +49 (0)911 895 7222
(https://support.automation.siemens.com/WW/llisapi.dll?func=cslib.csinfo&lang=en&ob
jid=38718979&caller=view)
You will find contact data on the Internet at the following address:
(http://www.automation.siemens.com/partner/guiwelcome.asp?lang=en)
SITRAIN - Siemens training for automation and industrial solutions
With over 300 different courses, SITRAIN covers the entire Siemens product and system
spectrum in the field of automation and drive technology. Advanced training tailored to your
needs is also available. In addition to our classic range of courses, we also offer a
combination of various training media and sequences. You can, for example, use self-study
programs on CD-ROM or on the Internet as preparation or to consolidate training.
You will find detailed information on our training curriculum and how to contact our customer
consultants at the following Internet address:
(www.siemens.com/sitrain)
Preface
CP 5613 A3 / CP 5614 A3
6 Operating Instructions, 10/2012, C79000-G8976-C277-01
CP 5613 A3 / CP 5614 A3
Operating Instructions, 10/2012, C79000-G8976-C277-01 7
Table of contents
Preface ...................................................................................................................................................... 3
1 Description of the device ........................................................................................................................... 9
1.1 Properties of the CP 5613 A3 ........................................................................................................9
1.2 Properties of the CP 5614 A3 ......................................................................................................10
1.3 PROFIBUS interface....................................................................................................................11
1.4 Meaning of the LED display.........................................................................................................13
2 Software installation................................................................................................................................. 15
2.1 Installing the SIMATIC NET PC software ....................................................................................15
2.2 Uninstalling the SIMATIC NET PC software................................................................................15
3 Hardware installation ............................................................................................................................... 17
3.1 Safety notices...............................................................................................................................17
3.2 Installing hardware.......................................................................................................................18
3.3 Hardware compatibility.................................................................................................................19
4 Configuration ........................................................................................................................................... 21
5 Technical specifications........................................................................................................................... 23
A Approvals................................................................................................................................................. 25
Index........................................................................................................................................................ 27
Table of contents
CP 5613 A3 / CP 5614 A3
8 Operating Instructions, 10/2012, C79000-G8976-C277-01
CP 5613 A3 / CP 5614 A3
Operating Instructions, 10/2012, C79000-G8976-C277-01 9
Description of the device 1
1.1 Properties of the CP 5613 A3
Properties
The CP 5613 A3 is a communications processor for connecting PCs (personal computers) or
PGs (programming devices) to PROFIBUS and MPI networks. The essential properties are
as follows:
● Transmission speeds up to 12 Mbps.
● Floating RS-485 connector.
● Linking of up to 32 devices (PC, PG, SIMATIC S7 or ET 200) to form a network segment.
– By linking several segments with repeaters, up to 124 nodes can be connected.
● The additional interface signals for a direct link to a PLC (Programmable Logic Controller)
are supported up to 187.5 Kbps.
● Installation in PGs and PCs with a PCI slot. The following is supported:
– PCI, 33 MHz / 66 MHz, 32 bits / 64 bits
– Plug and play
● Optimized for fast DP master operation (DP Base) with up to 124 DP slaves with full data
consistency.
● Relief of the PC/PG with event mechanisms.
– Automatic detection of data changes.
● Fast logic support regardless of the user program.
– Automatic linking of input and output data can be set by the user program.
● Measurement of own operating temperature with temperature sensor.
● Display of the total operating hours with operating hours counter.
Description of the device
1.2 Properties of the CP 5614 A3
CP 5613 A3 / CP 5614 A3
10 Operating Instructions, 10/2012, C79000-G8976-C277-01
Appearance
The following graphic shows the CP 5613 A3 communications processor:
&3
$
3%
1 LEDs
2 PROFIBUS interface PB1 (master or slave)
1.2 Properties of the CP 5614 A3
Properties
The CP 5614 A3 is a communications processor for connecting PCs (personal computers) or
PGs (programming devices) to PROFIBUS and MPI networks. In addition to the properties of
the CP 5613 A3, the CP 5614 A3 also has the following features:
● Additional PROFIBUS connection as DP slave to a second DP network.
● DP master and DP slave can be operated at the same time.
● Program-controlled data transfer between master and slave module for setting up
hierarchical PROFIBUS networks.
Autres manuels pour CP 5613 A3
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Siemens Matériel informatique
Siemens
Siemens SIMATIC S7-1200 CP 1243-8 IRC Manuel utilisateur
Siemens
Siemens SIMATIC NET CP 5614 A2 Manuel utilisateur
Siemens
Siemens SIMATIC PG 760 Manuel
Siemens
Siemens Fujitsu D1159 Manuel utilisateur
Siemens
Siemens SIMATIC CP 340 Manuel utilisateur
Siemens
Siemens 928B Guide de l'utilisateur
Siemens
Siemens Gigaset USB adapter 54 Manuel utilisateur
Siemens
Siemens CP 1612 A2 Manuel utilisateur
Siemens
Siemens Simatic S7-1500 Manuel utilisateur
Siemens
Siemens Simatic S7-300 CP 341 Manuel utilisateur
Siemens
Siemens CP 1243-8 IRC Manuel utilisateur
Siemens
Siemens SIMATIC NET CP 5613 A2 Manuel utilisateur
Siemens
Siemens Simatic M7-400 Manuel utilisateur
Siemens
Siemens SIMATIC NET CP 5512 Manuel utilisateur
Siemens
Siemens SIMATIC NET CP 443-5 Extended Manuel utilisateur
Siemens
Siemens PAD-5-CLSA Manuel utilisateur
Siemens
Siemens Simatic S7-300 31xC Series Manuel utilisateur
Siemens
Siemens SIMATIC CP 341 Manuel utilisateur
Siemens
Siemens SIMATIC NET CP 443-1 Advanced Manuel utilisateur
Siemens
Siemens SIMATIC NET CP 243-1 IT Manuel utilisateur
Manuels Matériel informatique populaires d'autres marques
EMC2
EMC2 VNX Series Manuel du propriétaire
Panasonic
Panasonic DV0PM20105 Manuel utilisateur
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuel utilisateur
Raidon
Raidon iT2300 Manuel utilisateur
National Instruments
National Instruments PXI-8186 Manuel utilisateur
