SC&T HE02EIP Manuel utilisateur

Smart Cabling & Transmission Corp.

V1.0_150819M

HDMI over HDBaseT Extender

User Manual

Model : HE02EIP

4K HDMI & IR/PoH CAT5e Extender 70M

User Manual

HE02EIP

Introduction

HE02EIP is a 4K HDMI over HDBaseT™ extender that can use an Ethernet cable to send uncompressed

HDMI and IR signals with resolution up to 4K@60Hz 4:2:0 and transmission distance up to 70M. The

extender also supports PoH (Power over HDBaseT), designed to provide power from one side (TX/ RX) to

another.

Features

Resolution up to 4K@60Hz 4:2:0.

Signal extension up to 70M over one CAT5e/6 cable.

Supports PoH (Power over HDBaseT™), no power required for RX unit.

Supports bi-directional IR transmission, EDID and CEC pass through.

Installation view

LED Indication

Power: Green ON/OFF

HDMI:

Blue ON: With HDMI signal

Flash: HDMI signal without HDCP

OFF: No HDMI signal

HDBaseT:

Blue ON: HDBaseT link

Flash: Low power mode

OFF: HDBaseT unlink

IR receive/emit LED:

Blue Flash: IR signal transmission

OFF: No IR signal

User Manual

HE02EIP

Cable

Link cable recommend use high quality Cat.5e、Cat.6、Cat.6a、Cat.7 UTP / STP or FTP cable. Poor quality

cable or network connection or improper construction will cause unstable connection, video or sound

disruptions, picture noise appears.

HDBaseT Distance Chart by Different Cable

Cable Type

Range

Pixel Clock Rate

Video Data Rate

Supported Video

CAT.5e / CAT.6

70 M

≦225MHz

≦5.3Gbps(Full HD Video)

1080p 60Hz 36 bit

CAT.5e / CAT.6

35 M

> 225MHz

> 5.3Gbps(Ultra HD Video)

1080p 60Hz 48 bit

1080p 60Hz 3D

4K x 2K 24Hz

CAT.6a / CAT.7

40 M

If connection through the wall socket, the cable length must less 5 meters between HDMI extender and

wall jack, as below drawing:

Panel View

HE02EIPT

HE02EIPR

Low-power Mode

When there is no HDMI video signal input or TV is not connected or power off, this product will enter a

low-power mode to save power consumption; under a low power mode still provides IR and CEC of

signal transmission.

Transmitter

Wall Jack

Receiver

CAT6 70M

< 5M

User Manual

HE02EIP

RJ45 Define

Video Link (TIA/EIA-568-B)

1. Orange-white DATA0 +

2. Orange DATA0 -

3. Green-white DATA1 +

4. Blue DATA2 +

5. Blue-white DATA2 -

6. Green DATA1 -

7. Brown-white DATA3 +

8. Brown DATA3 –

Caution

1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone,

microwave, radio equipment, fluorescent lamp, high voltage power lines.

2. The cable must pull in straight to avoid any crosstalk interference and the transmission stability.

3. This device HDBaseT port is not general Ethernet signal; do not connect with Network devices to

avoid damage.

4. IR transmitter do not put near from receiver to avoid mutual interference.

5. The receiver unit working temperature is higher which is in normal condition.

HE02EIP Package Include

HE02EIPT HDM Transmitter x 1 pcs

HE02EIPR HDMI Receiver x 1 pcs

IR Emitter Cable x 2 pcs

IR Receiver Cable x 2 pcs

Mounting Screw pack x 1 bags

DC12V 1Amp Power Adapter x 1 pcs

User Manual

HE02EIP

Specification

ITEM NO.

HE02EIPT

HE02EIPR

Support

Compliance

HDMI 1.4, HDCP, 3D

Max. Video Resolution

4K@24Hz

Max. Transmission Distance

70M at 1080p, 40M at 4K

Video Bandwidth

10.2 Gbps

Audio Format

LPCM 7.1 192KHz, Dolby Trued, DTS-HD MA

IR Support

30-60Khz, ±15°, 5M, Bi-directional

30-60Khz, ±55°, 5M, Bi-directional

Ports & Interfaces

Video Input

1 x HDMI Type A

1 x HDBaseT

Video Output

1 x HDBaseT

1 x HDMI Type A

Power

Power Supply

DC 24V 1.25A

Power Consumption

11.4W (Max), 1.8W(Low Power)

Ambient Temperature

Operation

0 to 55℃

Storage

-20 to 85℃

Humidity

up to 95%

Physical Characteristics

Dimensions

67 x 95 x 27mm

Weight

155g

165g
