Ruijie Reyee RG-ES105D Series Manuel d'installation et d'exploitation

RG-ES105D, RG-ES105GD,

RG-ES108D, RG-ES108GD

Series Switch

Hardware Installation and Reference Guide

Document

Version: V1.2

Date: 2023-02-15

All rights arereserved in this documentandthis statement.

Without the priorwritten consentof RuijieNetworks,anyorganization orindividualshallnotreproduce,extract,

back up, modify, or propagatethecontent of this documentin any mannerorin anyform, or translateit into

other languagesoruse some orallparts of the documentforcommercialpurposes.

,, andother Ruijienetworks logos are

trademarks ofRuijieNetworks.

All othertrademarks orregisteredtrademarksmentionedinthis documentare ownedbytheir respective

owners.

Disclaimer

The products,services,orfeatures you purchase are subjecttocommercialcontracts andterms,andsomeor

allof the products,services,orfeatures describedinthis documentmaynotbe availablefor you to purchase or

use.Except for the agreementinthe contract,RuijieNetworks makes noexplicitorimplicitstatementsor

warranties withrespecttothe content of this document.

The content of this documentwillbeupdated from timeto timedue to productversionupgrades orother

reasons,RuijieNetworksreserves therightto modifythe contentof the documentwithoutanynotice or prompt.

This manualis designedmerelyas auserguide.RuijieNetworks has triedits bestto ensurethe accuracyand

reliabilityof the content when compilingthis manual,butit does notguaranteethat the content of the manual is

completelyfree of errors or omissions,andall the information in this manual doesnotconstituteanyexplicit or

implicitwarranties.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Preface

Thank you for usingourproducts.This manualwillguide youthroughtheinstallation ofthe device.

This manual describes the functional and physical features and provides the device installation steps, hardware

troubleshooting,module technicalspecifications,andspecifications andusage guidelines forcables andconnectors.

Audience

It is intended for the users who have some experience in installing and maintaining network hardware. Moreover,it is

assumedthattheusers are alreadyfamiliarwiththerelatedterms andconcepts.

Obtaining Technical Assistance

RuijieNetworks website:https://www.ruijienetworks.com/

Technicalsupportwebsite:https://ruijienetworks.com/support

Caseportal:http://caseportal.ruijienetworks.com

Community:http://community.ruijienetworks.com

Technicalsupportemail:service_rj@ruijienetworks.com

Skype: service_rj@ruijienetworks.com

Related Documents

Document

Description

ConfigurationGuide

Describes network protocols and related mechanisms that

supportedbythe product,with configurationexamples.

CommandReference

Describes the related configuration commands, including

command modes, parameter descriptions, usage guides, and

relatedexamples.

Conventions

1. GUI Symbols

Interface

symbol

Description

Example

Boldface

1. Button names

2. Window names, tab name, field name

andmenu items

3. Link

1. Click OK.

2. Select Config Wizard.

3. Click the Download File link.

Multi-level menus items

ChooseSystem >Time.

2. Signs

The signs usedinthis documentaredescribedas follows:

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Warning

An alert that calls attentionto importantrules and information thatif not understoodorfollowedcanresultin

data loss orequipmentdamage.

Caution

An alert that calls attention to essentialinformation thatifnot understoodorfollowedcanresultin function

failureor performance degradation.

Note

An alert that contains additionalorsupplementaryinformationthatifnot understoodorfollowed willnotlead to

serious consequences.

Specification

An alert that contains a descriptionofproductor versionsupport.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

1 Product Overview

The RG-ES100series switchincludesthefollowingmodels.

Model

10/100 Base-T Auto-

sensing Ethernet Port

10/100/1000 Base-T

Auto-sensing

Ethernet Port

1000Base-X SFP

Port

Console

Port

RG-ES105D

N/A

RG-ES108D

N/A

RG-ES105GD

N/A

RG-ES108GD

N/A

1000Base-Tis backwardcompatiblewith100Base-Tand 10Base-T.

1.1 RG-ES105D

Technical Specifications

Model

RG-ES105D

Ports

Five 10/100Base-TXEthernetports

Power Supply

AC input

Ratedvoltage range: 100V AC to 240V AC

Maximum voltage range: 90V AC to 264 V AC

Frequency: 50/60 Hz

Ratedcurrent: 0.3 A

Adapter output

Ratedvoltage range: 5 V DC

Ratedcurrent range:1 A

EEE

Not supported

PoE

Not supported

Power Consumption

5 W

Operating

Temperature

0°C to 40°C (32°Fto 104°F)

Storage Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

10%to 90% RH

Storage Humidity

5% to 95%RH

Fan

Not supported

TemperatureWarning

Not supported

Accessing Optical

Module Information

Not supported

Certification

Earth Leakage Current

≤1.5 mA

Dimensions

119mmx 75 mmx 24 mm(4.69in. x 2.95 in. x 0.94in.)

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

(W x D x H)

Weight

(With Package)

0.25 kg (0.55lbs)

Device operation in a residentialenvironmentmaycauseradiointerference.

Product Appearance

On the front panel,the RG-ES105DEthernet switchprovides five 10/100Base-TXEthernetports andoneDC powerport.

Figure1-1 Appearance of the RG-ES105D

Front Panel

Figure 1-2 Front Panel of the RG-ES105D

Note:

1. System status LED

2. Port status LED

3.10/100Base-TXEthernet port

4. DC powerport

5. Nameplate onthe bottom of the device

Back Panel

Figure 1-3 Back Panelof the RG-ES105D

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Note:

1. Grounding hole

Heat Dissipation

The RG-ES105D adopts natural heat dissipation, thereby ensuring normal operation. You must maintain a minimum

clearance of 100 mm (3.94 in.) aroundthe RG-ES105D. Itis recommended thatyou clean the RG-ES105D once every3

months to avoid dustfrom blocking vents.

LEDs

LED

Panel Identification

State

Meaning

System status LED

Status

Off

The switchis poweredoff.

Solidgreen

The switchis operational.

RJ45port status LED

1-5

Off

The port is not connected.

Solidgreen

The port is connected at a rate of 10/100Mbps.

Blinkinggreen

The port is receiving or sending traffic at a rateof

10/100 Mbps.

1.2 RG-ES105GD

Technical Specifications

Model

RG-ES105GD

Ports

Five 10/100/1000Base-TEthernetports

Power Supply

AC input

Ratedvoltage range: 100V AC to 240V AC

Maximum voltage range: 90V AC to 264 V AC

Frequency: 50/60 Hz

Ratedcurrent: 0.3 A

Adapter output

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Ratedvoltage range: 5 V DC

Ratedcurrent range:1 A

EEE

Not supported

PoE

Not supported

Power

Consumption

5 W

Operating

Temperature

0°C to 40°C (32°F to 104°F)

Storage

Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

10%to 90%RH

Storage Humidity

5% to 95%RH

Fan

Not supported

Temperature

Warning

Not supported

Accessing Optical

Module Information

Not supported

Certification

Earth Leakage

Current

≤1.5 mA

Dimensions

(W x D x H)

119mmx 75 mmx24 mm(4.69in. x 2.95 in. x 0.94in.)

Weight

(With Package)

0.25 kg (0.55lbs)

Device operationina residentialenvironmentmaycauseradio interference.

Product Appearance

On the frontpanel,theRG-ES105GD Ethernetswitchprovides five10/100/1000Base-T Ethernetports and oneDCpower

port.

Figure1-4 Appearance of the RG-ES105GD

Front Panel

Figure1-5 Front Panel of the RG-ES105GD

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Note:

1. System status LED

2. Port status LED

3. 10/100/1000Base-TEthernetport

4. DC powerport

5. Nameplateon thebottom of the device

Back Panel

Figure1-6 Back Panelof the RG-ES105GD

Note:

1. Groundinghole

Heat Dissipation

The RG-ES105GD adopts turbine fans for heat dissipation, thereby ensuring normal operation. You must maintain a

minimum clearance of 100 mm (3.94 in.) around the RG-ES105GD. It is recommended that you clean the device once

every 3 months toavoid dustfrom blocking vents.

LEDs

LED

Panel Identification

State

Meaning

System status LED

Status

Off

The switchis poweredoff.

Solidgreen

The switchis operational.

RJ45port status LED

1-5

Off

The port is not connected.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Solidgreen

The port is connected at a rate of 10/100/1000

Mbps.

Blinkinggreen

The port is receiving or sending traffic at a rate of

10/100/1000Mbps.

1.3 RG-ES108D

Technical Specifications

Model

RG-ES108D

Ports

Eight 10/100Base-TXEthernetports

Power Supply

AC input

Ratedvoltage range: 100V AC to 240V AC

Maximum voltage range: 90V AC to 264 V AC

Frequency: 50/60 Hz

Ratedcurrent: 0.3 A

Adapter output

Rated voltage range: 5 V DC

Ratedcurrent range:1 A

EEE

Not supported

PoE

Not supported

Power

Consumption

5 W

Operating

Temperature

0°C to 40°C (32°Fto 104°F)

Storage

Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

10%to 90%RH

Storage Humidity

5% to 95%RH

Fan

Not supported

Temperature

Warning

Not supported

Accessing Optical

Module Information

Not supported

Certification

Earth Leakage

Current

≤1.5 mA

Dimensions

(W x D x H)

160mmx 62 mmx24 mm(6.30 in. x 2.44 in. x 0.94 in.)

Weight

(With Package)

0.35 kg (0.77lbs)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ruijie Changer

Ruijie

Ruijie RG-CS86-20XS Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S5750-S Series Manuel d'installation et d'exploitation

Ruijie

Ruijie XS-S1930J Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-NBS6002 Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S7800 Series Manuel

Ruijie

Ruijie RG-S2928G-E Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-PF2920-DPBOX-P Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-IF2920U-12GT1XS Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S2600E Series Manuel utilisateur

Ruijie

Ruijie RG-EG210G-P Manuel utilisateur

Ruijie

Ruijie RG-S5750-H Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6520 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-NBS7003 Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-IF2920U-12GT1XS-DC Series Manuel d'installation et d'exploitation

Ruijie

Ruijie HS2310-16GH2GT1XS Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S3760E Series Manuel utilisateur

Ruijie

Ruijie RG-S6000C-48GT4XS-E Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-CS83 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6000C-48GT4XS-E-AC DCN Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6930-2C Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S2900G-E Series Manuel utilisateur

Ruijie

Ruijie RG-S6980-64QC Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6250-48XS8CQ Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6510-32CQ Manuel d'installation et d'exploitation

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
