INTRODUCTION

CRYSTALVIEW PLUS USB INSTALLATION AND OPERATIONS MANUAL

Disclaimer

While every precaution has been taken in the preparation of this manual, the

manufacturer assumes no responsibility for errors or omissions. Neither

does the manufacturer assume any liability for damages resulting from the

use of the information contained herein. The manufacturer reserves the

right to change the specifications, functions, or circuitry of the product

without notice.

The manufacturer cannot accept liability for damages due to misuse of the

product or other circumstances outside the manufacturer’s control. The

manufacturer will not be responsible for any loss, damage, or injury arising

directly or indirectly from the use of this product.

System introduction

Thank you for choosing the Rose ElectronicsCrystalView PlusUSB

enhanced KVM station extender. The CrystalView Plus USB is the result of

Rose Electronics commitment to providing state-of-the-art solutions for

today’s demanding workplace. The CrystalView Plus USB has proven to be

a valuable investment for any business, big or small, that has a need to

access CPUs from Remote locations.

The CrystalView Plus USB is available in a single or dual video model.

Serial/Audio features are also an option on all models. The single and dual

video models have local and remote access. The local access allows an

additional KVM station to be connected to the Local Unit.

The CrystalView Plus USB system consists of two Units, a Local Unit and a

Remote Unit. The Local Unit connects to your CPU with one or two video

sources or to a Rose switch. The Remote Unit connects to a USB keyboard,

one or two video monitors and a USB mouse. The Local and Remote Units

are connected together with industry standard CAT-5, CAT-5e, or CAT-6

shielded or unshielded, solid core twisted-pair cable terminated with RJ45

connectors. All models can extend the distance from the CPU up to 1,000

feet. CAT-x cable can be ordered from Rose Electronics in 25-1,000 foot

lengths.

Using the CrystalView Plus USB to remotely access your computer has

several applications that make it convenient for the users. You can locate

your computers in a secure area and access them from other unsecured

areas. Computers used in hazardous industrial environments can be

accessed remotely, keeping the users safe and unexposed to any hazards.

CRYSTALVIEW PLUS USB INSTALLATION AND OPERATIONS MANUAL

Features

Available in single and dual video models

Extend a KVM station from a CPU using a single CAT-x cable. (Up to

650 feet at resolutions of 1600 x 1200 @ 60Hz,

1,000 feet for the resolutions of 1280 x 1024 @ 75Hz.)

Supports Serial, and full stereo audio

Operates as a full-speed composite USB device, compatible with any

USB 1.1 or 2.0 host

Supports a maximum of 7 USB HID devices including USB hubs

The CrystalView Plus USB uses a microprocessor to emulate the

keyboard and mouse for plug and play operation. The keyboard and

mouse on the Remote Unit do not have to be connected for the PC to

boot; only the Local Unit must be connected to the PC

Integrated skew compensation adjusts all colors

Low frequency (LF) and high frequency (HF) equalization adjustments

for optimum video tuning

Compatible with Rose Electronics family of KVM switches such as

ServeView Pro, UltraView Pro and UltraMatrix

Compatible with Windows, Windows NT, OS/2, Unix, Linux and other

operating systems

Fully automatic KVM sharing on a first-come first-serve basis

The computers video is displayed on both the local and remote KVM

stations monitors except in the private mode

Local or Remote KVM station can inhibit the other

Serial and Bi-directional full stereo audio options. Stereo audio can be

transmitted in either direction across the CAT-x link simultaneously

Many serial devices like a Touchscreen can plug directly into the

Remote Unit

Status indicator LEDs on each RJ45 connector

Surge protection on each RJ45 port

All settings and video tuning performed from the remote unit and saved

in flash memory

Remote unit is flash upgradeable

Rack mount kits available in 19”, 23” and 24” sizes

CRYSTALVIEW PLUS USB INSTALLATION AND OPERATIONS MANUAL

Compatibility

Computers

PCs with standard USB keyboards and

USB mice

Monitors

VGA to UXGA

HV, Composite, Sync-on-green,

Keyboards

USB type keyboard.

Mouse

USB Wheel mouse

Serial Devices

(Serial/Audio model

only)

Touchscreens, Graphic Tablets,

Serial printers/plotters, Computer terminals

Serial mice, Other standard asynchronous

serial devices.

Audio Devices

(Serial/Audio model

only)

Compatible sound cards

Amplified or non-amplified microphone

Amplified computer stereo speakers

Other audio devices that transmit/receive

signals less than 5 volts peak-to-peak.

USB Devices

(7 maximum

HID ONLY)

Composite keyboard/mouse devices

PS/2 to USB converters

USB Hubs

Package contents

The package contents consist of the following:

The CrystalView Plus USB Units as ordered

Power adapter for Remote Unit. (Auto-switching transformer)

Gender changer (factory installed)

Installation and operations manual.

Video, serial, audio and CAT-x cables are usually ordered separately.

Rose Electronics web site

Visit out web site at www.rose.com for additional information on the

CrystalView Plus USB and other products that are designed for data center

applications, classroom environments and other applications.

About this manual

This manual covers the installation and operation of the CrystalView Plus

USB, single and dual video models.

MODELS

CRYSTALVIEW PLUS USB INSTALLATION AND OPERATIONS MANUAL

Dual video Local models

Front view

Rear view

Figure 1. Dual Video (Local models)

Connectors:

Front

RJ45 (2) CATx cable connection (front panel)

Rear

HD15F CPU video connection.

(2) to CPU Video card / (2) to local monitors

USB USB Type B

NOTE: The CrystalView Plus USB is available with single or dual video,

Local KVM access, and serial / audio options

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rose electronics Extenseur

Rose electronics

Rose electronics CrystalView HDT Manuel utilisateur

Rose electronics

Rose electronics CrystalLink CLK-1U1TP-40M Manuel utilisateur

Rose electronics

Rose electronics CrystalView Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB2.0 CATx Manuel utilisateur

Rose electronics

Rose electronics ORION Manuel utilisateur

Rose electronics

Rose electronics CRK-2DTPPDVI Manuel utilisateur

Rose electronics

Rose electronics Crystal View Manuel utilisateur

Rose electronics

Rose electronics CrystalView HDMI 4K60 Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB3.1 Fiber Dual Port Manuel utilisateur

Rose electronics

Rose electronics CrystalView CAT5 Rack CRV-12SLP Manuel utilisateur

Rose electronics

Rose electronics CRK-1P1V Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI Fiber CRK-2DFMPD1D Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB3.1 Fiber Dual Port Manuel utilisateur

Rose electronics

Rose electronics CrystalView CAT5 Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB2.0 CATx Manuel utilisateur

Rose electronics

Rose electronics Xcion XCK-2DTXUD1D Manuel utilisateur

Rose electronics

Rose electronics CrystalView Rack CRV-12SLP Manuel du propriétaire

Rose electronics

Rose electronics CrystalView CrystalView TWISTED PAIR KVM... Manuel utilisateur

Rose electronics

Rose electronics CRK-2DTPPDVI Manuel utilisateur

Rose electronics

Rose electronics CrystalView USB2 Manuel utilisateur

Rose electronics

Rose electronics CrystalView EX DVI Multi CRK-1DTXT2DM-2T-EX6 Manuel utilisateur

Rose electronics

Rose electronics CrystalView fiber CRK-1DFM/SUN Manuel utilisateur

Rose electronics

Rose electronics CRK-1P1V Manuel utilisateur

Rose electronics

Rose electronics CrystalView fiber CRK-1DFM/SUN Manuel du propriétaire

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
