Rose electronics CrystalView DVI Plus Manuel utilisateur

CrystalView DVI Plus™

Digital Fiber KVM USB Extender

10707 Stancliff Road

Houston, Texas 77099

800-333-9343

www.rose.com

INSTALLATION

AND

OPERATIONS MANUAL

CRK-1DFMT1SL / CRK-1DFMT2SL

CRK-1DFMH1SL / CRK-1DFMH1SL

LIMITED WARRANTY

No part of this manual may be reproduced, stored in a retrieval system, or transcribed in any form or any

means, electronic or mechanical, including photocopying and recording, without the prior written permission of

Rose Electronics.

Rose Electronics Part # MAN-CRVDVIPlus

Printed In the United States of America – Revision 1.8

Rose Electronics warrants the CrystalView DVI Plus to be in good working order for one year from the

date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good

working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair

or replace the Unit as set forth below. Repair parts and replacement units will be either reconditioned or

new. All replaced parts become the property of Rose Electronics. This limited warranty does not include

service to repair damage to the Unit resulting from accident, disaster, abuse, or unauthorized

modification of the Unit, including static discharge and power surges.

Limited Warranty service may be obtained by delivering this unit during the one-year warranty period to

Rose Electronics or an authorized repair center providing a proof of purchase date. If this Unit is

delivered by mail, you agree to insure the Unit or assume the risk of loss or damage in transit, to prepay

shipping charges to the warranty service location, and to use the original shipping container or its

equivalent. You must call for a return authorization number first. Under no circumstances will a unit be

accepted without a return authorization number. Contact an authorized repair center or Rose

Electronics for further information.

ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT INCLUDING THE WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN

DURATION TO A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE, AND NO

WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD. SOME

STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE

ABOVE LIMITATION MAY NOT APPLY TO YOU.

IF THIS PRODUCT IS NOT IN GOOD WORKING ORDER AS WARRANTED ABOVE, YOUR SOLE

REMEDY SHALL BE REPLACEMENT OR REPAIR AS PROVIDED ABOVE. IN NO EVENT WILL

ROSE ELECTRONICS BE LIABLE TO YOU FOR ANY DAMAGES INCLUDING ANY LOST PROFITS,

LOST SAVINGS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE

USE OF OR THE INABILITY TO USE SUCH PRODUCT, EVEN IF ROSE ELECTRONICS OR AN

AUTHORIZED DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR FOR

ANY CLAIM BY ANY OTHER PARTY.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE MAY NOT APPLY

TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE

OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

IBM, AT, and PS/2 are trademarks of International Business Machines Corp. Microsoft and Microsoft

Windows are registered trademarks of Microsoft Corp. Any other trademarks mentioned in this manual

are acknowledged to be the property of the trademark owner.

FCC/CE STATEMENTS, EU DECLARATION OF CONFORMITY

FEDERAL COMMUNICATIONS COMMISSION

AND INDUSTRY CANADA

RADIO-FREQUENCY INTERFERENCE STATEMENTS

Models:

CRK-1DFMT1SL

CRK-1DFMH1SL

CRK-1DFMT2SL

CRK-1DFMH2SL

CRK-1DFMT1DL

CRK-1DFMH1DL

This equipment generates, uses and can radiate radio frequency energy and

if not installed and used properly, that is in strict accordance with the

manufacturer’s instructions may cause interference to radio communication.

It has been tested and found to comply with the limits for a Class A digital

device in accordance with the specifications of Part 15 of FCC rules, which

are designed to provide reasonable protection against such interference when

the equipment is operated in a commercial environment. Operation of this

equipment in a residential area is likely to cause interference, in which case

the user at his own expense will be required to take whatever measures may

be necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Le présent appareil numérique n’émet pas de bruits radioélectriques

dépassant les limites applicables aux appareils numériques de la classe A

prescrites dans le Règlement sur le brouillage radioélectrique publié par

Industrie Canada.

EURPOEAN UNION DECLARATION OF CONFORMITY

This equipment is in conformity with the

Council Directives 89/336/EEC

The Declaration of Conformity is based upon

compliance of the product with the following

standards:

EN55022 2006 Class A

IEC61000-4-2: 2001

IEC61000-4-3: 2006

IEC61000-4.4: 2004

The device was tested in a typical configuration with a PC.

LASER SAFETY

Laser Safety Precautions

The CrystalView DVI Plus models can be operated in a non-restricted area

and requires no laser warning labeling. The optical transceivers used in all

models have a typical output power of approximately 5 mW. This

corresponds to Hazard Class 1M as per EN 60825-2 (safety of optical fiber

communications systems).

As a safety precaution, the laser ports on all models will be switched off if the

fiber plugs are removed the sockets. Even with this safety precaution you

should never view directly into the fiber connectors.

TABLE of CONTENTS

Contents Page #

Disclaimer.........................................................................................................1

System introduction..........................................................................................1

Compatibility..................................................................................................1

Features........................................................................................................2

Rose Electronics web site.............................................................................2

Package Contents.........................................................................................2

About this manual .........................................................................................2

Models ..............................................................................................................3

Installation – Singlelink / Single Video..............................................................4

Installation – Singlelink / Dual Video ................................................................5

Installation – Duallink / Single Video ................................................................6

Diagnostic LEDs ...............................................................................................7

DDC Information...............................................................................................8

Troubleshooting................................................................................................9

Service Information.........................................................................................10

Maintenance and Repair.............................................................................10

Technical Support .......................................................................................10

Safety..............................................................................................................11

Figures Page #

Figure 1. Models...............................................................................................3

Figure 2. Installation – Singlelink / Single Video ..............................................4

Figure 3, Installation – Singlelink / Dual Video.................................................5

Figure 4. Installation - Duallink / Single Video..................................................6

Appendices Page #

Appendix A – General specifications..............................................................13

Appendix B – Part Numbers...........................................................................14

INTRODUCTION

CrystalView DVI Plus Installation and Operations Manual 1

Disclaimer

While every precaution has been taken in the preparation of this manual, the

manufacturer assumes no responsibility for errors or omissions. Neither

does the manufacturer assume any liability for damages resulting from the

use of the information contained herein. The manufacturer reserves the

right to change the specifications, functions, or circuitry of the product

without notice.

The manufacturer cannot accept liability for damages due to misuse of the

product or other circumstances outside the manufacturer’s control. The

manufacturer will not be responsible for any loss, damage, or injury arising

directly or indirectly from the use of this product.

System introduction

Thank you for choosing the Rose ElectronicsCrystalViewDVI Plus Fiber

KVM station extender. The CrystalViewDVI Plus is the KVM extender of

choice for businesses that need to extend and operate a computer, server,

or KVM switch from a great distance. The CrystalViewDVI Plus makes

this possible by the use of multimode fiber cable. You can fully operate and

control a computer or server and your USB peripherals from as far away as

1/4 mile using 50µm multimode fiber. The CrystalViewDVI Plus supports

all combinations of DVI-D monitors and video cards. Models are available

with USB keyboard and mouse connectors, single video or dual video, USB

2.0 support, and all models use multimode fiber.

The extenders support DVI graphical interfaces in an uncompressed mode.

The uncompressed transfer of DVI data results in a display with no picture

corruption or frame dropping at full speed. Video movements are smooth

even at the highest resolution.

The system consists of two Units, a transmitter and a receiver. The

transmitter connects to your CPUs USB connector and the DVI monitor

connector. The receiver connects to a USB keyboard, mouse, DVI video

monitor and supported USB peripherals. The transmitter and receiver are

connected together with fiber optic cable. The receiver can be up to 1,300

feet from the transmitter using 50.0µm Multimode-Fiber.

Compatibility

Video – DVI-D Singlelink (3x1.6 Gbit/sec – Max resolution 1920 x 1200)

DVI-D Duallink (6x1.6 Gbit/sec – Max resolution 2560 x 2048)

Keyboard – All standard USB keyboards / USB keyboards with built-in hub

Mouse – All standard 2, 3, and wheel mice

USB Peripherals – Compatible USB 2.0 compliant devices

2 CrystalView DVI Plus Installation and Operations Manual

Features

Supports:

DVI-D graphic interfaces in a uncompressed mode

DVI-D Singlelink graphic cards

DVI-D Duallink graphic cards

USB keyboard USB mouse

USB 2.0 compliant devices

Max Resolution – DVI Singlelink :1920x1200@60Hz / 1280x1024@75Hz

DVI Duallink: 2560x2048@60Hz



Transparent USB 2.0 (Cameras, scanners, printers, other USB 2.0

compliant devices

Supports all USB 2.0 compliant devices (Printers, scanners, projectors)

24 Bit color depth

Max distance – 1,300 feet (400M) using Multimode 50µm fiber cable

650 feet (200m) using Multimode 62.5µm fiber cable

(Multimode data transfer cable only)

LED status indicators

Optional remote monitor DDC loading from the remote monitor

Rack mount options for mounting in a 19” rackmount shelf (3 wide)

Rose Electronics web site

Visit our web site at www.rose.com for additional information on the

CrystalView DVI Plus and other products designed for data center

applications, classroom environments, and many other applications.

registrationform.htm

Package Contents

The CrystalView DVI Plus model as ordered

Local and remote unit power adapters / power cords (2)

DVI-I MM cable (2)

USB Type A to Type B cable (1)

Product documentation CD

About this manual

This manual covers the installation, operation, and troubleshooting of the

CrystalView DVI Plus models.

MODELS

CrystalView DVI Plus Installation and Operations Manual 3

Models

Singlelink – Duallink / Single Video

Local / Remote

Front View

Connectors

2- SC Type fiber

(USB + KVM)

Local

Rear View

Connectors

DVI-D

USB Type A

Power

Remote

Rear View

Connectors

DVI-D

4-USB Type B

Power

Singlelink / Dual Video

Local / Remote

Front View

Connectors

3- SC Type fiber

(USB + KVM +

Video)

Local Rear View

Connectors

2-DVI-D

2-USB Type B

Power

Remote Rear View

Connectors

2-DVI-D

4-USB Type A

Power

Figure 1. Models

INSTALLATION

4 CrystalView DVI Plus Installation and Operations Manual

Installation – Singlelink / Single Video

The example in figure 2 shows a typical installation for the Singlelink / Single Video

model. It is recommended that all equipment be turned off. The cables needed for

this installation are:

1- DVI-D MM video cable

1-USB Type A to Type B

2-Multimode fiber cables 50µm or 62.5µm. E.g. I-V(ZN)H 2G50

(In house patch cable) or I-V(ZN)HH 2G62.5 (In house Breakout cable)

or I/AD(ZN)H 4G50 (In house OR Outdoor Breakout cable, stress

resistant) or A/DQ(ZN)B2Y 4G62.5 (Outdoor cable, stress resistant with

protection against animal biting)

A point to point connection is required for the fiber cables. Having one or

more patch panels in the line is possible and allowed. Not allowed is a

connection from the fiber link interface to any other products, especially

telecommunications or network equipment.

Figure 2. Installation – Singlelink / Single Video

1. Connect a DVI-D MM video cable from the DVI-D video card connector

to the corresponding connector on the local unit.

2. Connect a USB Type A to Type B cable from the USB connector on the

computer to the USB Type A connector on the local unit.

3. Connect a DVI monitor, USB keyboard and USB mouse to the

corresponding connectors on the remote unit.

4. Connect two fiber cables from the local unit to the remote unit.

5. Attach your USB 2.0 compatible devices to the USB connectors on the

remote unit.

6. Plug-in the two supplied power adapters to the local and remote units

(5V / 2.4A to transmitter, 5V / 4A to receiver)

7. Power on the monitor, remote unit, local unit, and the computer

Local Remote

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rose electronics Extenseur

Rose electronics

Rose electronics CrystalLink USB-3-2-1 Fiber Manuel utilisateur

Rose electronics

Rose electronics CrystalView CAB-MD6M2MD6F Manuel utilisateur

Rose electronics

Rose electronics CrystalView CrystalView TWISTED PAIR KVM... Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI EX Manuel utilisateur

Rose electronics

Rose electronics CrystalView Plus Manuel utilisateur

Rose electronics

Rose electronics CLK-4U2FM-500M Manuel utilisateur

Rose electronics

Rose electronics CrystalView CRK-1DTXT-HD5 Manuel utilisateur

Rose electronics

Rose electronics Xcion DVI/VGA over CATx Manuel utilisateur

Rose electronics

Rose electronics XtendVue Manuel utilisateur

Rose electronics

Rose electronics CrystalView HDMI 4K60 Manuel utilisateur

Rose electronics

Rose electronics CrystalView Rack CRV-12SLP Manuel du propriétaire

Rose electronics

Rose electronics CrystalLink USB3.1 Fiber Dual Port Manuel utilisateur

Rose electronics

Rose electronics CrystalView Mini Manuel utilisateur

Rose electronics

Rose electronics CrystalView EX5 Manuel utilisateur

Rose electronics

Rose electronics ORION Manuel utilisateur

Rose electronics

Rose electronics CrystalLink CAT5 Serial Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI Quad Guide de configuration

Rose electronics

Rose electronics ViewLink CATx Manuel utilisateur

Rose electronics

Rose electronics CRK-1DFMPDVI/SF Manuel utilisateur

Rose electronics

Rose electronics CrystalView EX HDMI Multi CRV-SRDTXT2D-2T-HD6... Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI CAT Series Manuel utilisateur

Rose electronics

Rose electronics CRK-2DTPPDVI Manuel utilisateur

Rose electronics

Rose electronics CrystalView fiber CRK-1DFM/SUN Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB3.1 Fiber Dual Port Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
