Rexing MTC1 Manuel utilisateur
User Manual
MTC1
Motorcycle
Dash Cam
The information in this manual is subject to change without notice.
Rexing All Rights Reserved
www.rexingusa.com
We hope you love your new products as much as we do. If you need assistance, or
have any suggestions to improve it, please contact us.
Our support team will respond you as soon as possible.
Always a surprise in Rexing.
•https://www.facebook.com/rexingusa/
•https://www.instagram.com/rexingdashcam/
•https://www.rexingusa.com/support/registration/
Overview
Thank you for choosing REXING!
Check us out here.
Facebook Instagram Site Product Support
(877) 740-8004
1
What’s in the box?
1
5
2
3
7 8
4
6
2
1. Monitor
2. Front camera
3. Rear Camera
4. Hardwire Kit Cable
5. GPS Logger
6. USB Cable
7. Monitor Stand Installation Kit
8. Remote Control
9. Zip Ties X 5
10. Adhesives
11. Screws X 4
12. User Manual
13. Safety Guide
10 11 12 13
User Manual
MTC1
Motorcycle
Dash Cam
Theinformation in this manual is subject to change without notice.
RexingAll Rights Reserved
www.rexingusa.com
3
9
Safety Guide
安全ガイド
www.rexingusa.com
4
Installation
Various Motorcycles models require different installation instructions. For you and
your bikes own safety, please consider consulting a local professional for installation.
Warning
This is for reference only, please adjust installation method based on
your own motorcycle model.
If you would like to purchase other accessories (Camera Extending
Cable, Extra parts), please feel free to contact us.
After you confirm the correct quantity and code of terminals, please
make sure your cables and terminals are connected completely.
Moreover, if a terminal is broken, it will have a poor connection,
therefore it will not work properly.
!
5
Rear camera Remote Monitor GPS Logger
Front camera
000
08:55
KM/H
6
1. Front and Rear Cameras Installation
Use a screw driver to loose/fix
screw. After the screw is
released, you can adjust the lens
angle to up to 270 degrees.
1Remove the 3M adhesive
to stick the camera to the
right place.
Dash cam lens’s terminal
connection port.
Dash cam lens connection
ring. When you verify the
display on your screen, turn
the cylinder-shaped lens
body 360 degree.
3
42
Note:
Please repeat the same installation steps for both front and rear camera.
7
Warning
Different motorcycles can have different
positioning point for your lenses. In some
cases, you can stick your lenses upside
down. If this is the case, you need to
adjust the recording angle.
1. Unscrew the lens support fix.
2. Turn the cylinder-shaped lens body 360 degree.
3. You can adjust lens vertical angle up to 270 degrees.
• Lenses are Water Proof (IP67)
• If cleaning is necessary, please use a gentle cloth to clean lenses
• Please clean any water, oil stain, or dust before sticking your 3M
Adhesive Pad. If you relocate your lenses repeatedly, the 3M Glue
ability to stick will weaken, and your lens may fall.
• When you accelerate, the image quality may not be very stable,
this is the character of CMOS sensors. Please be aware, this is
not part of agreement.
!
8
2. Monitor Installation
Place your motorcycle’s handle in the middle of the ring, then use a screw driver
to tide the ring
Screw the dash cam monitor into the socket
Socket
3. Install a Micro SD Card
9
Make sure your
camera’s power is off,
and make sure you
insert card correctly,
push the card into the
card slot until you
hear a click.
Make sure your camera’s power is
off, push the card in the card slot
until you hear a click, then you are
safe to remove your micro SD card.
• Please use 8GB to 128GB micro SD card.
• Please use “Class 10 UHS-1” or higher standard card and higher speed card. If you
use class 10 or lower standard cards, the camera may not able to film.
• Please format your micro SD card before use.
Note:
1. Format will delete all contents in your SD card, please backup your files before
formatting.
2. Do not release your finger before removing the memory card.
3. Format regularly. We recommend once a month.
4. If you are removing or inserting micro SD card while power on, it may damage
your data or your camera.
Micro SD card installation
Micro SD card removal
000
08:55
KM/H
000
08:55
KM/H
