Renault WIND Manuel utilisateur

QUICK GUIDE

WIND

ENG_UD15266_1

Edito (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Detailed information regarding your vehicle’s use, maintenance and warranty, as well as videos and simulators are all

only a click away in the e-Guide for your new vehicle, accessible from the website www.e-guide.renault.com.

Translated from French. Copying or translating, in part or in full, is forbidden unless prior written permission has been obtained from RENAULT, 92 100 Billancourt

2 009.

This document does not replace the driver’s handbook.

Please read the complete driver’s handbook for more detailed information on your vehicle’s equipment.

The reference guide covers all existing equipment (both standard and optional) for all models of this vehicle. Whether the equipment is fitted to the vehicle depends

on the version, the options selected and the country where the vehicle is sold.

WELCOME ABOARD YOUR VEHICLE

Note

Congratulations on your choice and thank you for your purchase.

Your new vehicle was designed by the RENAULT design team to provide you with a versatile model offering a unique style.

Enjoy the exceptional open-air driving experience afforded by your new vehicle and learn about its main features in this document.

RENAULT wishes you happy driving.

A.S.R. (antipatinage) ................................................................................... (page courante)

ENG_UD15267_1

sommaire (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Front and engine compartment

Passenger side

Rear of the vehicle

Rotating hard roof

Accessing the vehicle

Starting/Stopping the engine

Driving position

Dashboard

Instrument panel

Lighting/Wipers

Cruise control/Speed limiter

Multimedia systems

Heating and air conditioning system

Gadgets

eco2

ENG_UD15268_1

Avant et compartiment moteur (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Front and engine compartment

FRONT AND ENGINE COMPARTMENT

Coolant level

The level indicated on tank 2should be between

the “MINI" and "MAXI" markings.

When this level must be topped up, always do so

with the engine cold, switched off and with the ve-

hicle on level ground.

Screen washer fluid level

With the engine switched off, top up the fluid in

reservoir 3if necessary.

Opening the bonnet

To open, pull unlocking handle 1and push the

bonnet catch tab to the left. Lift the bonnet and

secure it using the stay.

Closing the bonnet

Check that nothing has been left in the engine

compartment. To close the bonnet, replace the stay

in its mounting, lower the bonnet to approximately

20 cm above the closed position and release it.

It will latch automatically under its own weight.

Check that it is locked.

Engine oil level

To check the oil level, use dipstick 5.

The level indicated on dipstick 5should be between

the MINI and MAXI marks.

If the oil level is at minimum, unscrew filler cap 4

to top up the oil.

You must observe the service intervals and the oil

grades recommended for your engine. Refer to the

Maintenance Service document for your vehicle,

and to Section 4 of the vehicle handbook for the

precautions to take when filling with oil.

ENG_UD15269_1

Côté passager (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Passenger side

PASSENGER SIDE

Deactivating the front

passenger air bag

If you wish to fit a rear-facing child seat on the

front passenger seat, you must deactivate the air

bag: with the vehicle stationary, push and turn

switch 1to OFF.

With the ignition on, warning light 2,

lights up orange on the instrument panel.

Activation of the front

passenger air bag

You should reactivate the air bag as soon as you

remove the child seat from the front passenger seat

to ensure the protection of the front passenger in

the event of an impact.

To reactivate the air bag: when the vehicle is sta-

tionary, push and turn lock 1to the ON position.

With the ignition on, it is essential to check that

warning light 2

on the instrument panel

is off.

Accessories socket

It is located in the glove box.

It is designed for connecting accessories approved

by RENAULT's Technical Department with a maxi-

mum power rating of 120 Watts (12 V).

Immediately reposition the lock to ON as soon

as you stop using the child seat.

Refer to the driver’s handbook for specific infor-

mation on child safety.

ENG_UD15271_1

Arrière (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Rear of the vehicle

Tyre pressure kit/

emergency spare wheel

Depending on the vehicle, in the event of a punc-

ture, there is an emergency spare wheel or a tyre

inflation kit. Depending on the vehicle, you may

have a storage compartment. To access it, lift lug-

gage compartment carpet A.

Refer to Section 5 of your driver’s handbook.

Fuel tank

Your vehicle is fitted with a flap and a cap.

– To open the flap, place your finger in recess 1

and pull the flap;

– remove the cap;

– when driving, when the low fuel level warning

light

comes on, fill the tank as soon as

possible.

– After the warning light comes on, you have ap-

proximately 30 miles (50 km) left, driving at

moderate speed.

The fuel tank capacity is approximately 40 litres.

REAR OF THE VEHICLE

Anchorage points

Hooks 2located on either side of the luggage com-

partment allow the load to be secured.

Luggage compartment

volume

When the roof is folded back in its compartment,

you still have the entire volume of the luggage

compartment.

ENG_UD15291_1

Toit ouvrant (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Rotating hard roof

R O T A T I N G H A R D R O O F

Opening the rotating hard

roof

With the engine running and the handbrake en-

gaged.

Unlock the roof by pulling and turning control 1

clockwise.

Do not lift the roof.

Lower control 2(movement B) until the message

“roof open” appears on the instrument panel and

a beep sounds. The side windows and roof cover

open.

The roof folds into its housing and the roof cover

closes.

Closing the rotating hard

roof

With then engine running and the handbrake en-

gaged, raise control 2(movement A) until the

message “lock handle” appears on the instrument

panel and a beep sounds.

The side windows and roof cover open.

The roof and its cover close.

Lock the roof by turning control 1anticlockwise.

Do not move handle 1when driving.

ENG_UD15272_1

Accès au véhicule (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Accessing the vehicle

ACCESSING THE VEHICLE

Locking/unlocking the

vehicle

RENAULT REMOTE CONTROL KEY A OR B

Press:

‡

to unlock;

…

to lock.

In all situations:

– Two flashes of the direction indicator lights con-

firm vehicle locking;

– One flash of the direction indicator lights con-

firms vehicle unlocking.

SPECIAL FEATURES OF KEY A

To release key Afrom its housing, press button 1,

it will come out automatically.

To reinsert it in its housing, press button 1and

move key Auntil it is locked away.

SPECIAL FEATURES

– Never leave a key in the vehicle;

–

…

depending on the vehicle, pressing this

button twice in succession prevents the vehicle

from being opened, even from the inside.

ENG_UD15273_1

Démarrage/Arrêt du moteur (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Starting/Stopping the engine

STARTING/STOPPING THE ENGINE

Starting the engine

With the key in the ignition switch 1, turn it fully

on. Once the engine has started, release it.

Stopping the engine

With the engine idling, turn the key towards you.

Accessing functions

Turn the key through two positions to be able to

use certain functions (radio, wipers…)

Depending on the case, these functions will

switch off at the latest when the vehicle is

locked.

ENG_UD15274_1

Poste de conduite : sièges (E33 - X33 - Renault)ENG_RP_910-1_E33_Renault_0

Driving position

DRIVER’S POSITION: SEATS

Manual seat adjustment

MOVING THE SEAT FORWARDS OR BACKWARDS

Lift handle 1to release. Release the handle once

the seat is in the correct position and ensure that

the seat is fully locked into position.

RAISING OR LOWERING THE SEAT

Depending on the vehicle, lift handle 2.

TILTING THE SEATBACK

Move the lever 4and tilt the seatback to the re-

quired position.

Heated seats

With the ignition on, press switch 3.

The system, which has a thermostat, decides

whether or not the heating is needed.

Door mirrors with

electrical adjustment:

REAR VIEW MIRROR WITH BUTTON 5

Select the rear view mirror using button 5, then

adjust it to the required position.

HEATED DOOR MIRRORS

Depending on the vehicle, the door mirrors may

be heated. To activate this function, refer to the

information on the “Heating and air conditioning

system” in Section 3 of your driver’s handbook.
