PureLink PureTools PT-HDBT-200 Manuel utilisateur

User Manual

PT-HDBT-200

User Manual

HDBaseT Extender, 4K (60Hz 4:4:4) HDR with VLC

Model PT-HDBT-200

Designed in Germany

User Manual

PT-HDBT-200

Preface

Read this user manual carefully before using this product. Pictures shown in this

manual are for reference only. Different model layouts and specifications are subject

to the physical product.

This manual is for operation instructions only, not for any maintenance usage.

In the constant effort to improve our product, we reserve the right to make changes in

functions or parameters without prior notice or obligation.

Trademarks

Product model and logo are trademarks. Any other trademarks mentioned in this

manual are acknowledged as the properties of the trademark owner. No part of this

publication may be copied or reproduced without the prior written consent.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. It has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in

a commercial installation.

Operation of this equipment in a residential area is likely to cause interference, in

which case the user at their own expense will be required to take whatever measures

may be necessary to correct the interference.

Any changes or modifications not expressly approved by the manufacture would void

the user’s authority to operate the equipment.

User Manual

PT-HDBT-200

REACH | 1907/2006/EU

ROHS | 2011/65/EU

PureLink hereby declares that this product PureTools PT-HDBT-200 complies with

Directives 1907/2006/EU und 2011/65/EU.

EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)

PureLink GmbH hereby declares that this product PureTools PT-HDBT-200 complies

with Directives 2014/30/EU and 2014/35/EU. The full text of the EU Declaration of

Conformity is available at the following Internet address:

http://www.purelink.de/ce/4251364706787_CE.pdf

User Manual

PT-HDBT-200

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before

using the device. Save this manual for further reference.

Unpack the equipment carefully and save the original box and packing material

for possible future shipment

Follow basic safety precautions to reduce the risk of fire, electrical shock and

injury to persons.

Do not dismantle the housing or modify the module. It may result in electrical

shock or burn.

Using supplies or parts not meeting the products’ specifications may cause

damage, deterioration or malfunction.

Refer all servicing to qualified service personnel.

To prevent fire or shock hazard, do not expose the unit to rain, moisture or install

this product near water.

Do not put any heavy items on the extension cable in case of extrusion.

Do not remove the housing of the device as opening or removing housing may

expose you to dangerous voltage or other hazards.

Install the device in a place with fine ventilation to avoid damage caused by

overheat.

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage.

If an object or liquid falls or spills on to the housing, unplug the module

immediately.

Do not twist or pull by force ends of the optical cable. It can cause malfunction.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power

to the device before cleaning.

Unplug the power cord when left unused for a long period of time.

Information on disposal for scrapped devices: do not burn or mix with general

household waste, please treat them as normal electrical wastes.

User Manual

PT-HDBT-200

Introduction to PT-HDBT-200

The PT-HDBT-200 is an ultra-thin HDMI2.0 Extender consist of PT-HDBT-200-TX

transmitter and PT-HDBT-200-RX receiver. It extends 1080p/4K HDMI signal over

CAT5e/CAT6a cable up to 70m /40m (PoC), and enables IR and RS232 pass-through to

control source or display device remotely. It also adopt a visually lossless video

compression technology (VLC) to ensure the HD lossless transmission of HDR and

4K@60Hz/4:4:4 over CAT5e/CAT6a cable.

Feature

Supports 4K/UHD/60Hz/4:4:4.

Supports HDMI2.0 & HDCP2.2, and is backward compatible to the previous

version.

Maximum transmission distance is up to 40m for 4Kx2K, and 70m for 1080p.

Supports CEC, IR and RS232 pass-through for long-distance control.

Supports bi-directional PoC for simplified wiring.

Supports HDR.

Features DIP switch for choosing mode from: Control, Update A, Update B.

Package List

1 x PT-HDBT-200-TX Transmitter

1 x PT-HDBT-200-RX Receiver

4 x Mounting Ears & 4 x Screws

8 x Plastic Cushions

2 x 3-pin Phoenix Connector

1 x Power Adaptor (12VDC, 2A)

1 x User Manual

Panel Description

Transmitter

CTRL

UPDATE B UPDATE A

Tx Rx DC 12V

IROUT

IRIN

HDBT OUT

HDMIIN

12345678

User Manual

PT-HDBT-200

Receiver

No.

Name

Description

①

MODE Switcher

CTRL: RS232 pass-through control mode.

UPDATE A: Update Valens IC program, connect a PC

to the RS232 port, and then double-click the

update file (.bat).

UPDATE B: Update compression IC program, the

upgrade method is the same as the above UPDATE

②

Power LED

RED: DC power present.

③

HDMI IN (Transmitter)

Connect with HDMI source.

HDMI OUT(Receiver)

Connect with HDMI display.

④

3-pin Terminal Block

If one is connected with control device (e.g. PC), and

the other should be connected with the third-party

that need to be controlled.

⑤

IR IN

Work with far-end IR OUT port, connect with IR

Receiver (with carrier) to collect IR signal to control

far-end display device from local.

⑥

IR OUT

Work with far-end IR IN port, connect with IR Emitter

to send IR signal to control input source device from

remote.

⑦

HDBT

OUT(Transmitter)

Connect to the HDBT IN socket on Receiver via

CAT5e/6a cable.

HDBT IN (Receiver)

Connect to the HDBT OUT socket on Transmitter

CAT5e/6a cable.

⑧

DC 12V Power Port

Support bi-directional PoC, either ports should be

connected with 12V DC 2A power adaptor.

CTRL

UPDATE B UPDATE A

DC 12V

Tx Rx

HDMIOUT

HDBT IN

IROUT

IRIN

12345678

User Manual

PT-HDBT-200

Specification

PT-HDBT-200-TX Transmitter

Input

HDMI IN

Output

HDBT OUT

Control Ports

IR IN, IR OUT, RS232

PT-HDBT-200-RX Receiver

Input

HDBT IN

Output

HDMI OUT

Control Ports

IR IN, IR OUT, RS232

General

Transmission Mode &

Distance

HDBaseT; 1080p ≤ 70m; 4K×2K ≤ 40m

Resolution

Up to 4K×2K@60Hz 4:4:4

Bandwidth

18Gbps

HDMI Standard

HDMI2.0 & HDCP2.2

Power Consumption

14W (max)

Operation Temperature

0 ~ +40℃

Storage Temperature

-10 ~ +50℃

Relative Humidity

0% ~ 90%

External Power Supply

Input: 100VAC~240VAC, 50/60Hz; Output: 12VDC 2A

Dimension (W*H*D)

115mm x 16 mm x 84mm

Net Weight (g)

Transmitter: 150g; Receiver: 153g

User Manual

PT-HDBT-200

System Diagram

IR Emitter

4K Blu-Ray Laptop

TV Remote

IR Receiver

Transmitter Receiver

IR Emitter

HDTV

Blu-Ray

Remote

IR Receiver

HDMI:

IR:

RS232:

CATx:

Power:

4K 40m,1080P 70m

PoC

User Manual

PT-HDBT-200

After-Sales Service

If there appear some problems when running the product, please check and deal with

the problems referring to this user manual. Any transport costs are borne by the users

during the warranty.

1) Product Limited Warranty: This product will be free from defects in materials and

workmanship for two years (The purchase invoice shall prevail).

Proof of purchase in the form of a bill of sale or receipted invoice which is

evidence that the unit is within the Warranty period must be presented to obtain

warranty service.

2) What the warranty does not cover (servicing available for a fee):

Warranty expiration.

Factory applied serial number has been altered or removed from the product.

Damage, deterioration or malfunction caused by:

Normal wear and tear.

Use of supplies or parts not meeting our specifications.

No certificate or invoice as the proof of warranty.

The product model showed on the warranty card does not match with the

model of the product for repairing or had been altered.

Damage caused by force majeure.

Servicing not authorized by distributor.

Any other causes which does not relate to a product defect.

Delivery, installation or labor charges for installation or setup of the product.

3) Technical Support: For any questions or problems, contact your distributor or

reseller and tell them the respective product name and version, the detailed

failure situation as well as the formation of the cases.

User Manual

PT-HDBT-200
